2. INSTRUMENT DESCRIPTION

2.1 DESCRIPTION
The OM 502 model series are 5 digit panel programmable instruments.
The instrument is based on 8-bit microcontroller with hight-rate 24-bit sigma-delta converter, which secures high accuracy,
stability and easy operation of the instrument.
TYPES AND RANGES
DC
PM
I
L
DU
T
LVDT
PROGRAMMABLE PROJECTION, FUNCTION
Measuring range:
Setting:
Projection:
Integration (I):
Weighing function (T): manual or automatic calibration, signalization of stabilized equilibrium, zero stabilization,
Projection (T):
LINEARIZATION
Linearization:
Linearization (LX):
DIGITAL FILTERS
Floating average:
Exponen.average:
Rounding:
MATHEMATIC FUCTIONS
Min/max. value:
Tare:
Fixed tare:
Peak value:
Mat. operations:
4 | INSTRUCTIONS FOR USE OM 502
DC Voltmeter/Ammeter
±999,99 mV; ±999,99 mV; ±9,9999 V; ±99,999 V; ±300,00 V
±999,99 µA; ±9,9999 mA; ±99,999 mA; ±999,99 mA; ±5,0000 A
Process monitor
0...5 mA/0...20 mA/4...20 mA/±2 V/±5 V/±10 V
Integrator
0...5 mA/0 ...20 mA/4...20 mA/±2 V/±5 V/±10 V
Linearizator
0...5 mA/0...20 mA/4...20 mA/±2 V/±5 V/±10 V
Display unit for linear potentiometers
Linear potentiometer (min. 500 Ω)
Weighing indicator
1...4 / 2...8 / 4...16 mV/V
Display unit for LVDT sensor
1 / 3 / 5 VAC, 2,5 / 5 / 10 kHz
adjustable (PM, I, LX) or as per order (DC, T)
manual, optional display projection may be set for both limit values of the input signal,
e.g. input 0...20 mA > 0...8500,0
±99999 (-99999...999999)
with time base 1 s, projection of integrated and current value
automatic zero monitoring, defined number of sections on the scale
±99999 (Mode - Standard)
selection of size of the section - 0,001/0,002/0,005/0,01/0,02/0,05/0,1/0,2/0,5/1/2/5/
10/20/50/100 (Mode - WEIGHT)
by linear interpolation in 50 points (solely via OM Link)
linear interpolation in 256 points and 16 tables
from 2...30 measurements
from 2...100 measurements
setting the projection step for display
registration of min./max. value reached during measurement
designed to reset display upon non-zero input signal
fixed preset tare
the display shows only max. or min. value
polynome, 1/x, logarithm, exponential, power, root, sin x
