INSTRUCTIONS FOR USE - OM 36
5.

TECHNICAL DATA

MEASURING RANGE
the range is fi xed, according to order
±199,9 mV
±1,999 V
±19,99 V
±199,9 V
±300 V
±199,9 μA
±1,999 mA
±19,99 mA
±199,9 mA
±1,999 A
±5,00 A
the range is fi xed, according to order
0...199,9 mV
0...1,999 V
0...19,99 V
0...199,9 V
0...300 V
0...1,999 mA
0...19,99 mA
0...199,9 mA
0...1,999 A
0...5,00 A
Frequency range:
40...2 500 Hz
the range is fi xed, according to order
0...5 mA
0...20 mA
4...20 mA
±2 V
±5 V
±10 V
the range is fi xed, according to order
0...199,9 Ohm
0...1,999 kOhm
0...19,99 kOhm
5...105 Ohm
Connection:
2 or 4 wire
the range is fi xed, according to order
Pt xxx
±199,9°C or -200°...850°C
Type Pt:
100/500/1 000 Ohm, platinum, 3850 ppm
Connection:
2, 3 or 4 wire
PROJECTION
Display:
±1999, red or green LED, digit height 14 mm
Decimal point:
adjustable by jumper
Brightness:
adjustable by potentiometer under the front panel
12
DC
1 MOhm
Input 1
1 MOhm
Input 1
1 MOhm
Input 1
1 MOhm
Input 2
2 MOhm
Input 2
< 260 mV
Input 1
< 260 mV
Input 1
< 260 mV
Input 1
< 200 mV
Input 1
< 200 mV
Input 1
<50 mV
Input 1
AC
1 MOhm
Input 1
1 MOhm
Input 1
1 MOhm
Input 1
1 MOhm
Input 2
2 MOhm
Input 2
< 260 mV
Input 1
< 260 mV
Input 1
< 200 mV
Input 1
< 200 mV
Input 1
< 50 mV
Input 1
PM
< 260 mV
< 260 mV
< 260 mV
1 MOhm
1 MOhm
1 MOhm
OHM
RTD
INSTRUMENT ACCURACY
TC:
100 ppm/°C
Accuracy:
±0,1 % of range
±0,3 % of range (< 100 Hz, crest faktor 1-2)
±0,2 % z range
Resolution:
0,1° or 1°C
Rate:
1,2 - 2,5 - 5 - 10 measurements/s
Overload capacity: 10x (t < 100 ms) - not for 5 A and 300 V
2x (long-term)
Calibration:
at 25°C and 40 % r.h.
ANALOGUE OUTPUTS
Type:
non-isolated,
the output corresponds with the input signal
Nonlinearity:
0,3 % of range
TC:
100 ppm/°C
Rate:
response to change of value < 100 ms
Voltage:
0...2 V, 0...5 V, 0...10 V
Current:
0...5/20 mA/4...20 mA
- compensation of conduct up to 600 Ohm
EXCITATION
Adjustable:
2...24 VDC/50 mA, isolated
POWER SUPPLY
24/110/230 VAC, 50/60 Hz, 5 VA, ±10%
12...24 VDC, max. 150 mA
12...30 VDC, max. 300 mA, isolated
MECHANIC PROPERTIES
Material:
Noryl GFN2 SE1, incombustible UL 94 V-I
Dimensions:
96 x 48 x 110 mm
Panel cut-out:
92 x 45 mm
OPERATING CONDITIONS
Connection:
con. terminal board, conductor section up to 2,5 mm
Stabilization period: within 15 minutes after switch-on
Working temp.:
0°...50°C
Storage temp.:
-10°...85°C
Shielding:
IP42, upon request IP64 - front panel only
Construction:
safety class I
Overvoltage cat.:
EN 61010-1, A2
III. - instrument power supply (300 V)
II. - input, output, excitation (300 V)
for pollution degree II
EMC:
EN 61000-3-2+A12; EN 61000-4-2, 3, 4, 5, 8, 11;
EN 550222, A1, A2
AC
OHM
RTD
DC/AC/PM
2
