INSTRUCTIONS FOR USE - OM 36
4.2 SETTING THE EXCITATION
Excitation is, as a standard, set for 24 VDC.
Change in adjustment of the excitation value is performed by trimmer located over the terminal boards of the instrument (see
picture).
1 2 3 4 5 8 9 10 11
Excitation
10
