INSTALLATION AND OPERATING MANUAL
SWA Backwater Valve for wastewater with or without sewage
®
Clean-Out
®
Training
Location
Product Advantages:
For wastewater with or without raw sewage
For installation in exposed or concrete slab piping
Self closing backwater flap during backwater / flooding (depending on model)
Also for use as clean-out for pipe access and inspection
Staufix® SWA for in the floor installation (concrete slab) offers vertically
adjustable, twistable and tiltable upper section for easy installation
Upgradable to KESSEL Staufix® FKA automated backwater valve and
KESSEL Pumpfix F backwater valve with integrated sewage pump
Offers full channel wastewater passage
Simple maintenance and service
DIN EN 13564 Type 2
Company stamp
LGA
Landesgewerbeamt Bayern
Bauart
Bauart
Bauart
geprü ü ft ft
gepr
geprüft
und überwacht
und ü ü berwacht
und
berwacht
Edition
02/2011
Nr.
010-841EN
Subject to technical amendments

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Staufix SWA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kessel Staufix SWA

Summary of Contents for Kessel Staufix SWA

  • Page 1 Staufix® SWA for in the floor installation (concrete slab) offers vertically adjustable, twistable and tiltable upper section for easy installation Upgradable to KESSEL Staufix® FKA automated backwater valve and KESSEL Pumpfix F backwater valve with integrated sewage pump Offers full channel wastewater passage...

  • Page 2: Table Of Contents

    Table of Contents 1. General Application Staufix® SWA..............Page Application Controfix® ................. Page Contents of delivery ................Page General instructions................Page 2. Installation Concrete slab installation..............Page Extended depth installation In concrete slab........Page Exposed pipe installation ..............Page Installation in moisture /Groundwater areas ........Page Operational check according to DIN EN 13564 .......

  • Page 3: Application Controfix

    1.2 Application Controfix® nage pipes with or without raw sewage. The The KESSEL Controfix® serves as the body backwater valve prevents wastewater from housing for all KESSEL Staufix® and Pumpfix backing up the drainage pipe during backwa- series backwater valves.

  • Page 4: General Instructions

    2. Installation no wastewater will be able to flow through the backwater valve meaning General instructions for installation of backwater valves According to DIN EN 12056 it is not allowed to connect all drainage fix- that the building’s own wastewater will flood out of the lowest drainage tures from a building (including those located above the backwater level fixture connected (normally in the basement) to the backwater valve.

  • Page 5: Concrete Slab Installation

    2 meters. direction. It is recommended that a conduit pipe is laid and connected to the Staufix® 2.1 Concrete slab installation of a KESSEL- SWA body in the case that the system is SW (Nr. 73100.10 S/X, 73125.10 Staufix ®...

  • Page 6: Exposed Pipe Installation

    2. Installation The second gasket must be inserted in the thinner tiles since the remaining height Connection gaskets are supplied with the cover. Important is that the sealing lip and can be built up with the tile mortar. 83071 and should be properly lubricated as centering tip are pointing up.
  • Page 7 Please install the Kautschuk flan- Moisture protective Abdichtung sub slab Unterbeton ge properly so that the pre-drillled holes in Seal seat (83023) • Counterflange ➀ KESSEL-Pumpfix ➃ DN 100 intermediate section with stain- • Sealing sheet ® F, Staufix ® FKA, Staufix...
  • Page 8 3. Commissioning Function / Sealing test according to DIN EN 13564 ➁ Manually lock the outlet side backwater flap with the ma- nual closure lever (number 3 on illustration). Unscrew the red ½ inch test plug (1) on the cover and connect the sup- plied see-thru test funnel (2).

  • Page 9: Inspection

    4. Inspection and Maintenance 4.1 Inspection The backwater valve should be checked on a monthly basis by the owner or a represen- tative of the owner. The manual closure lever should be shut, locked and re-opened multi- ple times. Please make sure that after the in- spection that manual closure lever is in the Open position.
  • Page 10 4. Inspection and Maintenance The backwater needs to be checked every six months at a minimum by a qualified and licen- sed service technician. During the inspection no wastewater should pass through the backwater valve. The following should take place during this ins- Manual closure lever pection: closed...

  • Page 11: Assembly Of Both Covers

    4. Inspection and Maintenance 4.2.1 Assembly of both covers (see Illustrations 11 and 12) Insert cover housing at an angle as shown and then push other side down. Lock cover in place with the finger clips. All 4 cover closure clips in the locked position Illustr.
  • Page 12 5. Replacement Parts Staufix® SWA for exposed pipe installations Description Art.-Nr. ➀ ➀ SWA cover (inlet side) 80013 ➁ SWA cover (outlet side) 80014 ➂ Backwater flaps 80033 ➃ Housing for backwater flap 80034 ➄ Protective cover 83031 ➅ Transition section 83032 Test funnel 70214...
  • Page 13 5. Replacement Parts Staufix® SWA for concrete slab installations Description Art.-Nr. ➀ SWA cover (inlet side) 80013 ➁ SWA cover (outlet side) 80014 ➀ ➂ Backwater flaps 80033 ➃ Housing for backwater flap 80034 Gasket set (for cover, inlet and outlet) 70318 ➃...
  • Page 14 6. Warranty 1. In the case that a KESSEL product is de- cessarily to the entire product or unit. KES- stallation and user's manual as well as the fective, KESSEL has the option of repairing SEL products are warranted for a period of corresponding norms / regulations.
  • Page 16 Notice...

  • Page 17: For Installer

    8. Commissioning Protocol for installer Type description * KESSEL order number * Date of manufacture * (* according to type plate/invoice) Object description / system operator Planner Adress / Telephone Planner Adress / Telephone Installation company involved Adress / Telephone...
  • Page 18 Notice...
  • Page 19 9. Commissioning Protocol for installion company Handover certificate (copy for the company carrying out the installation) ❏ The initial operation and instruction was carried out in the presence of the person authorised to perform the acceptance and the system operator. ❏...
