ANLEITUNG FÜR EINBAU, BEDIENUNG UND WARTUNG
KESSEL-Fettabscheider „G", „D", „D + S"
nach Euro-Norm EN 1825 zur freien Aufstellung in
frostgeschützten Räumen
KESSEL-Fettabscheider G, D
und D+S
KESSEL-Fettabscheider D+S mit Zubehör
Installation
der Anlage wurde durchgeführt von Ihrem Fachbetrieb:
Name/Unterschrift
Stand 2014/01
Inbetriebnahme
Datum
Einweisung
Ort
Bedienungsanleitung
Seite 1-18
Installation Manual
Page 19-36
Guide Installation
Page 37-54
InstruKcja zabuDowy
Strona 55-72
Produktvorteile
nach EN 1825
Zulassungs-Nr. Z-54.1-474
kompakte Bauweise
leichter Transport
einfache, schnelle Montage
absolute Dichtigkeit
100% Beständigkeit gegen-
über aggressiven Fettsäuren
recyclebar
leichte Nachrüstbarkeit
Stempel Fachbetrieb
Sach-Nr. 010-329
