SYMA GYRO REMOTE CONTROL SERIES User Manual page 4

Dismantling of blade:
Camera's Installation and Dismantling Methods
Installation steps for camera:
Dismantling steps for camera:
3. Attach blade cover as shown.
1. Remove the blade cover as shown.
2. Use a wrench to fasten the hexagonal
3. Remove the blade.
1. Aim the camera
at the interface
and push it as
shown.
1. Pull out the
camera cable
from the socket
as shown.
nut under the base of the main axis, then
press blade A onto the axis. Turn the
blade clockwise to loosen it. Blade B is
loosened by turning it counter-clockwise.
-3-
2. Connect the
camera cable
into the socket
as shown.
2. Press the
camera locked
button and pull
camera out at
the same time.
