4-CHANNEL REAL-TIME-TRANSMISSION POSITION HOVERING
USER MANUAL
1
MAIN FEATURES
● Utilizes the 4-axis structure, enabling the drone to be even
more flexible, speedy.It can fly indoor .
● Built-in 6-axis gyro stabilizer to ensure accurate positioning
in-flight.
● The structure uses a modular design which makes it easy to
install and repair.
● Headless function making it easy for directional control.
● Pressure-fixed-position hovering function for Auto Hover Mode.
● 360° stunt flip.
● Auto take-off and landing.
● HD wireless real-time transmission aerial for getting the fun of
different photography.
22W
REMOTE CONTROL DRONE
8+
