INSTRUCTIONS FOR USE
X400
4-CHANNEL HEIGHT HOLD HOVER TRANSMITTER DRONE
MAIN FEATURES
● Special 4-axis structure-fast and agile. Suitable for flying in spacious
indoor areas.
● Built-in 6-axis gyroscope ensures accurate position hold.
● Modular design for easy upgrades and maintenance.
● Capable of doing 360 degrees stunts.
● Headless mode for easy recall of the drone.
● Improved height hold stability.
● Improved auto take-off/landing function.
Notice: The company will not be held responsibly for any printing
inconsistencies and may or not inform end users regarding any new
potential updates.For further information, please visit the syma website.
14+
+1(718)312-0558(USA)
+49 335-4551-9201(Germany)
usa@symatoys.com(US)
eu@symatoys.com(EU)
http://www.symatoys.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SYMA X400
Summary of Contents for SYMA X400
- Page 1 ● Improved height hold stability. ● Improved auto take-off/landing function. Notice: The company will not be held responsibly for any printing inconsistencies and may or not inform end users regarding any new potential updates.For further information, please visit the syma website.
-
Page 2: Safety Guide
English Safety Guide 1.Please store the smaller-sized drone accessories in places that are out of reach of children. 2.This drone is very powerful. For all first-time flights, the left joystick must be slowly pushed up in order to prevent the drone from ascending too fast to avoid unnecessary collision and possible damage and injury. -
Page 3: Repair And Maintenance
English Repair and maintenance 1.Use dry and soft cloth to clean this product. 2.Avoid exposing this product to heat. 3.Do not immerse this product in water, otherwise, the electronic parts will be damaged. 4.Transformers used with the toy are to be regularly examined for damage to the cord,plug, enclosure and other parts,and that,in the event of such damage,the toys must be used with this transformer until the damage has been repaired. -
Page 4: Package Description
English Package description The following items can be found in this product package: ●Drone ● Battery ●Remote Control ● Screwdriver ●User Manual ●4 Blades ●Charging Cable ●4 Protective Gears ●Mobile Phone Retaining Clip Re-installing the blades Remove the screws Re-installing the blades * A labeled blades fit on the A labele motors. - Page 5 English Battery Changing and Charging Methods for Drone Press the battery cover and open it down, then remove the battery. Charge the battery 5V2A The charging time is about 90 minutes; Hover flight time is approximately 6.5 minutes. After charging completed, replace the battery into the drone.
- Page 6 English Inserting the remote control batteries 4 x AA Batteries Battery Cover * When installing the batteries, ensure that you match the + and – ends of the battery with the + and – signs on the controller. * During the battery installation, it must be ensured that the polarities of the batteries are matched with that of the battery box.
-
Page 7: Using The Remote Control
English Turning the aircraft off Method one Method two Method three Push the left joystick Push the left and right Press the take-off/land- downwards for 2-3 joysticks downwards ing button to make the seconds. in a V shape for 2 aircraft land seconds. -
Page 8: Trimming Operation
English Trimming operation Forward and backward trim control If the drone automatically flies forward/backward while hovering, press in the left joystick and at the same time push the right joystick backward/forward slightly to fine tune the direction. Don’t release the left joystick until the drone is flying in a stable state. - Page 9 English 3.Level Calibration Function: Place the aircraft on a level surface and move the left and right joysticks to the lower right corner for approximately 3 seconds. The indicator will flash rapidly and then stay constant to indicate that the Level calibration calibration process is complete.
- Page 10 English 7. Headless Function: ①.Defining forward direction: ●Press on the power button of the remote control. Front ●Press the power button of the drone, and adjust the specified direction of the drone’s head under the Left Right headless mode as the new forward direction. Back ●Push the left joystick (throttle) on the remote control up to the farthest position and then pull down to the...
- Page 11 8.Wireless Real-Time Transmission Function ①Downloading the installation software For Android phones, download and install the SYMA FLY APP by visiting the www.symatoys.com or by scanning the QR code. For IOS Apple phones, download and install the SYMA FLY APP by visiting the App Store or by scanning the QR code.
- Page 12 This device must not be collocated or operating in conjunction with any other antenna or transmitter.” Declaration of Conformity inserts “Hereby, GuangDong Syma model aircraft lndustrial co.,ltd, declares that this drone is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.”...
- Page 13 English Accessories /Parts List (Optional) You can choose your favourite optional accessories as below. In order to make it easier for the customers to choose and purchase, we have specially offered each and every accessory. The accessories can be purchased through the local distributors. Please Light Protective Body Blade...
-
Page 14: Product Descriptions
English Product Descriptions Component/Part Component/Part Component/Part Serial Serial Serial Quantity Quantity Quantity Name Name Name number number number Light Protective Counter-Clockwise Camera Shell Blades Cover Top Main Body Camera Protective Guard Receiver Clockwise Blades Main Body Elements Battery Storehouse Bottom Main Body Battery Elements Motor Elements -13-... -
Page 15: Main Specifications
English Main Specifications 36.8mm 166mm 166mm Drone’s Length: 166mm Drone’s Width : 179mm Drone’s Height: 36.8mm Motor’s Model : Ø7 Battery : 3.7V 400mAh lithium battery Rectification Procedures Problem Reason Solution 1. The drone has entered into The drone low-voltage protection. 1. - Page 16 English Android APP iOS APP Manufacturer: Guangdong Syma Model Aircraft Industrial Co., Ltd. Address: No 2 West Xingye Road, intersection of North Xingye Road, Laimei Industrial Park, Chenghai District, Shantou City, Guangdong Province, China. Postal Code: 515800 Sales department: +86 0754 86980668 After-sales service: +86 0754 86395095 Fax: +86 0754 86395098 Website: www.symatoys.com...
