TL280(R)
Internet Alarm Communicator - International
I
G
4.1
NSTALLATION
UIDE V
For installation manual visit www.dsc.com
Warning: This manual contains information on limitations regarding product use and
function and information on the limitations as to liability of the manufacturer.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL280R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC TL280R

Summary of Contents for DSC TL280R

  • Page 1 TL280(R) Internet Alarm Communicator - International NSTALLATION UIDE V For installation manual visit www.dsc.com Warning: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer.

  • Page 2: Table Of Contents

    ABLE OF ONTENTS General ............1 Communicator Installation Configuration.
  • Page 3 WARNING: I NSTALLER LEASE AREFULLY Note to Installers Motion detectors can only detect motion within the designated The warnings on this page contain vital information. As the only areas as shown in their respective installation instructions. They individual in contact with system users, it is the installer’s responsi- cannot discriminate between intruders and intended occupants.

  • Page 4: General

    • Do not stay close to the equipment during device operation. Model Information This manual covers the following model of alarm communicator: TL280 and TL280R. References to model TL280(R) throughout this manual applies to all specified models unless stated differ- ently.

  • Page 5: Communicator Installation Configuration

    Communicator Installation Configuration Internet Alarm Communicator Installation Guide EN50131-1 Installation Requirements For EN50131-1 compliant installations, the following programming options shall be set as described. Supervision Heartbeat (required for ATS4 and ATS5): • [851][004] set to 0087h (135s heartbeat). NOTE: The compatible receiver at ARC location shall have supervision window programmed for 1800s (ATS4) or 180s (ATS 5).

  • Page 6: Installing Ethernet Communicator In Panel

    Installing Ethernet Communicator in Panel Internet Alarm Communicator Installation Guide hazardous, indoor locations only. This manual shall be used with the installation manual of the panel which is connected to the Ethernet communicator. All instructions specified within the panel manual must be observed. All local rules imposed by local electrical codes shall be observed and respected during installation.
  • Page 7 3rd Party Device Communicator GND (Optional) NOTE: The GND connection is optional. DSC recommends connecting GND wire at both ends. Install Network Cable 1. Route the CAT 5 Ethernet cable through back of the panel and plug it into the communicator’s RJ45 jack.

  • Page 8: Initial Panel Programming

    Initial Panel Programming Internet Alarm Communicator Installation Guide fully communicated to all programmed receivers. If this is the first time the communicator has been powered up, the module will not be able to initiate communication until it has been programmed. NOTE: Initialization may take several minutes to complete.

  • Page 9: Communicator Troubleshooting

    Communicator Troubleshooting Internet Alarm Communicator Installation Guide Table 5: Yellow Trouble Status LED (Continued) # of # of Trouble Trouble Flashes Flashes Ethernet Trouble Module Configuration Trouble Receiver Not Available Trouble NOTE: Only the highest priority trouble (2 flashes is the highest priority trouble) is indicated. When this trouble is restored, the next highest trouble will indicate, if present.

  • Page 10: Ethernet Programming Options

    Ethernet Programming Options Internet Alarm Communicator Installation Guide Table 6: Trouble indications Trouble Trouble Possible Indicator Trouble Possible Solution indication Causes Digit • The unit is still initializing please wait while the unit gets its programming Initialization and establishes a connection to all programmed receivers. Sequence NOTE: This process may take several minutes to complete.

  • Page 11: Ethernet Programming Worksheets

    Ethernet Programming Worksheets Internet Alarm Communicator Installation Guide THERNET ROGRAMMING ORKSHEETS System Options [013] DLS Outgoing Port Default (0BFA/3066) Valid range: 0000 - FFFF. [001] Ethernet IP Address Default (000.000.000.000) |____|____|____|____| |____|____|____||____|____|____||____|____|____||____|____|____| [015] DLS Call-Up IP [002] Ethernet IP Subnet Mask Default (000.000.000.000) Default (255.255.255.000) |____|____|____||____|____|____||____|____|____||____|____|____|...
  • Page 12 Ethernet Programming Worksheets Internet Alarm Communicator Installation Guide [034] Communicator Firmware Update [105] Ethernet Receiver 1 UDP Local Successful Port Default (FF) Program 00 disable or FF enable. Default (0BF4/3060)Valid range: 0000 - FFFF. |____|____| |____|____|____|____| [035] Panel Firmware Update Begin [106] Ethernet Receiver 1 Domain Name Default (FF) Program 00 disable or FF enable.
  • Page 13 Ethernet Programming Worksheets Internet Alarm Communicator Installation Guide Receiver Diagnostic Testing [663] Integration Toggle Option 2 |____| [1] Integration Over Serial Port (ON). [901] Diagnostic Test Transmission |____| [2] Reserved. |____| [1] Ethernet 1 Default (OFF). |____| [3] Integration Over Ethernet (OFF). |____| [2] Ethernet 2 Default (OFF).
  • Page 14 Access cards or tags returned for replacement under warranty will be credited or replaced at DSC's option. Products not covered by this warranty, or otherwise out of warranty due to age, misuse, or damage shall be evaluated, and a repair esti-...
  • Page 15 If You do erned by the laws of the Province of Ontario, Canada. not agree to the terms of this EULA, DSC is unwilling to license the ARBITRATION - All disputes arising in connection with this SOFTWARE PRODUCT to You, and You have no right to use it.
  • Page 16 4. The TL280R, TL280 module uses AES128 encryption and heartbeat supervision for both the Ethernet communication path 1. The TL280R, TL280 module is monitored by the control panel and it meets security levels S2 as per EN50136-2-1 (EN50131-1). and it is programmed via the programming menu (* 8, section It also uses authentication for each message exchanged with the [851] in the control panel.
