  • Page 1 SB402-VG Storage Server Barebone User's Manual UM_SB402-VG_v1.2_022119...

  • Page 2: Table Of Contents

    Table of Contents Preface ������������������������������������������������������������������������������������������������� i Safety Instructions ������������������������������������������������������������������������������ ii About This Manual ������������������������������������������������������������������������������ iv Chapter 1� Product Features �������������������������������������������������������������� 1 1.1 Box Contents ................... 1 1.2 Specifications ..................2 1.3 Features ....................3 Chapter 2� Hardware Setup ���������������������������������������������������������������� 6 2.1 Central Processing Unit Setup ...............
  • Page 3 2.9 Tool-less Slide Rail Installation ............25 Chapter 3� Hardware Settings ���������������������������������������������������������� 28 3.1 Motherboard Block Diagram ..............28 3.2 Motherboard Content List ..............29 3.3 Motherboard Layout ................30 3.4 Connector and Jumper .................31 3.4.1 Connector ......................31 3.4.2 Jumper ......................37 3.5 LEDs .......................38 3.5.1 Front Panel LED Definition ................
  • Page 4 4.2.1 Menu ......................... 62 4.2.2 Startup ......................62 4.2.3 Update ......................65 4.3 Main .......................67 4.3.1 Main ........................67 4.4 Advanced ....................68 4.4.1 Peripheral Configuration ................. 68 4.4.2 Video Configuration ..................68 4.4.3 Socket Configuration ..................68 4.4.4 PCH Configuration ................... 72 4.4.5 H2o IPMI Configuration ...................
  • Page 5 Copyright © 2018 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.
  • Page 6 Document Release History Release Date Version Update Content January Released to public 2018 1. New cover 2. QIG update January 2019 3. BMC update 4. Hardware Update Febuary Safety Instruction update 2019...

  • Page 7: Preface

    Disclaimer AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 8: Safety Instructions

    Safety Instructions Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components. •...
  • Page 9 • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage. • Never open the equipment. For safety reasons, only qualified service personnel should open the equipment. • If one of the following situations arise, the equipment should be checked by service personnel: 1.

  • Page 10: About This Manual

    This document pellucidly presents a brief overview of the product design, device installation, and firmware settings for SB402-VG. For the latest version of this user's manual, please refer to the AIC website: http://www.aicipc.com/en/productdetail/20885.

  • Page 11: Chapter 1� Product Features

    SB402-VG User Manual SB402-VG User Manual Chapter 1. Product Features SB402-VG is a high density storage server that includes mother board, chassis, power supply, and HDD backplane. For more information about our product, please visit our website at http://www.aicipc.com/en. Before removing the subsystem from the shipping carton, visually inspect the physical condition of the shipping carton.

  • Page 12: 1.2 Specifications

    Dimensions Expansion Slots PCIe 3.0 (W x D x H) inches : 17 x 26.7 x 6.9 Insyde UEFI BIOS BIOS Type AIC Server Board Virgo (Page 105) Motherboard redirection Processor (Skylake and next gen. CPU) System BIOS Support BIOS...

  • Page 13: Features

    Chapter 1. Product Features 1�3 Features SB402-VG is a reliable 4U storage server barebone with 36 hotswap drives bays. This prod- uct is designed to accommodate the AIC-patented serverboard, Virgo, which supports two Intel® Xeon® Scalable Processors and 12 DDR4 DIMM to offer greater perfomance, efficiency, and utility for our customers.
  • Page 14 SB402-VG User Manual Chapter 1. Product Features Front Panel 24 x 3.5" hotwap drive tray System LED Indicator and switch Power Button System ID System Power LED System HDD Activity LED System Reset System fault LED LAN LED Rear Panel 2 x 2.5"...
  • Page 15 SB402-VG User Manual Chapter 1. Product Features Top View...

  • Page 16: Chapter 2� Hardware Setup

    Chapter 2� Hardware Setup SB402-VG User Manual Chapter 2. Hardware Setup This section describes a simple instruction guide for installing the hardware components on the serverboard system. Turn off and unplug all system and peripheral devices before proceeding. 2�1 Central Processing Unit Setup The serverboard supports dual Xeon scalable processors and Socket P0 (LGA-3647).
  • Page 17 SB402-VG User Manual Chapter 2. Hardware Setup Processor Socket Assembly: The server board includes two processor sockets (LGA-3647), supports one or two of the Intel® Xeon® Processor Scalable Family and has a Thermal Design Power (TDP) of up to 165W on selected models.
  • Page 18 SB402-VG User Manual Chapter 2. Hardware Setup PHM Screw Installation Order: The PHM sits level with the processor socket assembly. The PHM is NOT installed properly if it does not sit level with the processor socket assembly. Once the PHM is seated over the processor socket assembly, the four heat sink torque screws must be secured in the following order as shown below.

  • Page 19: Cpu Heatsink Location

    SB402-VG User Manual Chapter 2. Hardware Setup 2�1�2 CPU Heatsink Location CPU 0 CPU 1 CAUTION Avoid moving the heatsink after it has contacted the top of the CPU. Too much movement could disturb the layer of thermal compound, causing voids, and leading to ineffective heat dissipation and component damage.

  • Page 20: System Memory

    SB402-VG User Manual Chapter 2. Hardware Setup 2�2 System Memory This server board supports up to twelve DDR4 2400 and 2666 Registered ECC DRAM/ Load-Reduced DIMM. JDIMML0 JDIMML0 JDIMMK0 JDIMMK0 JDIMMJ0 JDIMMJ0 JDIMMC0 JDIMMC0 JDIMMB0 JDIMMB0 JDIMMA0 JDIMMA0 CPU 1...

  • Page 21: Dimm Installation Order

    SB402-VG User Manual Chapter 2. Hardware Setup 2�2�1 DIMM Installation Order JDIMML0 JDIMMC0 JDIMMK0 JDIMMB0 JDIMMJ0 JDIMMA0 DIMM Numbers DIMM ARRANGMENT CPU 0 CPU 0 CPU 1 CPU 1 CPU1 CPU0 2 DIMMs JDIMM_L0 JDIMM_C0 JDIMMG0 JDIMMD0 JDIMMH0 JDIMME0 JDIMMI0...
  • Page 22 SB402-VG User Manual Chapter 2. Hardware Setup JDIMML0 JDIMMC0 JDIMMK0 JDIMMB0 JDIMMJ0 JDIMMA0 CPU1 CPU0 JDIMM_L0 JDIMM_C0 CPU 0 CPU 0 CPU 1 CPU 1 JDIMM_K0 JDIMM_B0 10 DIMMs JDIMM_J0 JDIMM_A0 JDIMM_G0 JDIMM_D0 JDIMMG0 JDIMMD0 JDIMM_I0 JDIMM_F0 JDIMMH0 JDIMME0 JDIMMI0...

  • Page 23: Dimm Installation

    SB402-VG User Manual Chapter 2. Hardware Setup 2�2�2 DIMM Installation Step 1 Unlock the DIMM socket by pressing the retaining clips outward. Step 2 Insert the memory module into the slot. Make sure that the DIMM notch is accurately positioned.

  • Page 24: Removing And Installing The Top Cover

    SB402-VG User Manual Chapter 2. Hardware Setup 2�3 Removing and Installing the Top Cover 2�3�1 Removing the Top Cover Step 1 Press the release button on both sides of the system. Step 2 Pull horizontally away from the front panel and lift upward to remove.

  • Page 25: Removing And Installing The Motherboard

    SB402-VG User Manual Chapter 2. Hardware Setup 2�4 Removing and Installing the Motherboard 2�4�1 Installing the Motherboard Step 1 Push the motherboard into the system. Step 2 Secure the screw x 8 pcs on both sides (x 4 pcs on each side) of the system.

  • Page 26: Removing And Installing The Power Supply Unit Module

    SB402-VG User Manual Chapter 2. Hardware Setup 2�5 Removing and Installing the Power Supply Unit Module 2�5�1 Removing the Power Supply Unit Step 1 Push the latch inward and hold the tray handle. Step 2 Pull the tray handle to remove.

  • Page 27: Removing And Installing The Fan Module

    SB402-VG User Manual Chapter 2. Hardware Setup 2�6 Removing and Installing the Fan Module 2�6�1 Installing and removing the Fan Insert or pull the fan module to install or remove the the fan module. Make certain to align the fan module to the appropriate slot.

  • Page 28: Removing The Fan

    SB402-VG User Manual Chapter 2. Hardware Setup 2�6�2 Removing the Fan Step 1 Remove the 4 screws from both sides of the system. Step 2 Pull the motherboard tray from the rear of the chassis to reveal the bottom row of the fan.

  • Page 29: Removing And Installing The Hard Disk Drive

    SB402-VG User Manual Chapter 2. Hardware Setup 2�7 Removing and Installing the Hard Disk Drive 2�7�1 Installing and removing 2�5" Hard Disk Tray 2.7.1.2 Removing the 2.5" hard disk drive tray Step 1 Press the release button on the HDD tray lever.

  • Page 30: Installing And Removing 3.5" Hard Disk Tray

    SB402-VG User Manual Chapter 2. Hardware Setup 2�7�2 Installing and removing 3�5" Hard Disk Tray 2.7.2.1 Installing the 3.5" hard disk drive tray Push the HDD tray lever and tray into the system. 2.7.2.2 Removing the 3.5" hard disk drive tray Step 1 Press the release button on the HDD tray lever.
  • Page 31 SB402-VG User Manual Chapter 2. Hardware Setup Rear Panel 3.5 Tray This information is provided for professional technicians only.
  • Page 32 SB402-VG User Manual Chapter 2. Hardware Setup 2�7�3 Installing the 3�5" Hard Disk Drive Directly place HDD into tool-less HDD tray untli it snaps. Please check if the screw holes on HDD match the dimples on HDD tray. HDD can also be screwed on HDD tray by fastening two screws as picture showed.
  • Page 33 SB402-VG User Manual Chapter 2. Hardware Setup 2�7�4 Installing the 2�5" Hard Disk Drive Directly place HDD into tool-less HDD tray untli it snaps. Please check if the screw holes on HDD match the dimples on HDD tray. HDD can also be screwed on HDD tray by fastening two screws as picture showed.

  • Page 34: Removing And Installing The Hdd Backplane Module

    SB402-VG User Manual Chapter 2. Hardware Setup 2�8 Removing and Installing the HDD Backplane Module 2�8�1 Removing the HDD Backplane Step 1 Unplug all connectors & HDDs from HDD backplane. Step 2 Release the lock pin to remove the HDD backplane.

  • Page 35: Tool-Less Slide Rail Installation

    SB402-VG User Manual Chapter 2. Hardware Setup 2�9 Tool-less Slide Rail Installation NOTE This sections provides a basic instruction for mounting the slide rail onto the system. Tool-less rails vary per order. The rail in this manaul may not exactly match the rail for your system.
  • Page 36 SB402-VG User Manual Chapter 2. Hardware Setup 2. Place the inner rail firmly against the side of the chassis. Make sure that the hooks are straight and aligned with the holes in the inner rail. 3. Slide the inner rail forward until it clicks into the locked position.
  • Page 37 SB402-VG User Manual Chapter 2. Hardware Setup 4. Press the locking tab and push the middle rail back into the outer rail. 5. Hang the hooks of the rails on the rack holes and if necessary, secure with screws. optional screw...
  • Page 38 SB402-VG User Manual Chapter 2. Hardware Setup 6. Repeat step 5 to mount the four ends, extending the rails as necessary. 7. Pull the middle rail out of the front of the outer rail and make sure that the ball bearing shuttle is locked at the front of the middle rail.
  • Page 39 SB402-VG User Manual Chapter 2. Hardware Setup 8. Depress the locking tabs on both sides of the chassis simultaneously and push the chassis all the way into the rear of the rack. If additional security is required, secure the chassis handles to the front of the rack with two screws (optional).

  • Page 40: Chapter 3� Hardware Settings

    Chapter 3� Hardware Settings Chapter 3. Hardware Settings SB402-VG User Manual This section describes the jumpers, internal connectors and internal LEDs settings. 3�1 Motherboard Block Diagram Platform Environment Control Interface(PECI) DIMM #H0 DIMM #J0 DIMM #L0 DIMM #B0 DIMM #D0...

  • Page 41: Motherboard Content List

    SB402-VG User Manual Chapter 3. Hardware Settings 3�2 Motherboard Content List Connector/Jumper/Header Location Connector/Jumper/Header Location Power Supply JPWR1, JPWR3, Front I/O USB Header JUSB_INT Connector JPWR4 Power Supply JPWR2 SSI Front Panel Header JFRNT_SSI Connector External Thermal J2, J13, J24...

  • Page 42: Motherboard Layout

    Chapter 3. Hardware Settings SB402-VG User Manual 3�3 Motherboard Layout CPU1 CPU1 CPU0 CPU0 CPU0 19 18...

  • Page 43: Connector And Jumper

    SB402-VG User Manual Chapter 3. Hardware Settings 3�4 Connector and Jumper 3�4�1 Connector 6 SAS IOC Activity LED Header (J19) 1 Power Connector +3.3V (JPWR1, JPWR3 & JPWR4) SAS_LED_GPIO16 SAS_LED_GPIO20 SAS_LED_GPIO17 SAS_LED_GPIO21 SAS_LED_GPIO18 SAS_LED_GPIO22 SAS_LED_GPIO19 SAS_LED_GPIO23 7 SAS IOC Error LED Header (J25) 2 Power Connector (JPWR2) +3.3V...
  • Page 44 Chapter 3. Hardware Settings SB402-VG User Manual SFF-8643 Connector for PCIe (CN1) SFF-8643 Connector for PCIe (CN4) SMBDAT_MUX_6 C1 A1 CLK_100M_SSD6_P SMBDAT_MUX_4 C1 A1 CLK_100M_SSD4_P SMBCLK_MUX_6 C2 A2 CLK_100M_SSD6_N SMBCLK_MUX_4 C2 A2 CLK_100M_SSD4_N C3 A3 GND C3 A3 GND CPU1_EXP1_TX_DP_13 C4 A4 CPU1_EXP1_RX_DP_13...
  • Page 45 SB402-VG User Manual Chapter 3. Hardware Settings SFF-8643 connector for SAS (CN7) SIO1_SAS_DOUT C1 A1 N.C. C2 A2 SIO1_SAS_CLK C3 A3 GND SAS_EXP_TX_P6 C4 A4 SAS_EXP_RX_P6 SAS_EXP_TX_N6 C5 A5 SAS_EXP_RX_N6 C6 A6 GND SAS_EXP_TX_P7 C7 A7 SAS_EXP_RX_P7 SAS_EXP_TX_N7 C8 A8 SAS_EXP_RX_N7...
  • Page 46 Chapter 3. Hardware Settings SB402-VG User Manual 15 PCH SSGPIO Header (JSSGPIO) 27 Front I/O USB Header (JUSB_INT) 17 PCH GPIO Header (JPCH_GPIO) 28 SSI Front Panel Header (JFRNT_SSI) 24 SAS IOC ICE Header (J12)
  • Page 47 SB402-VG User Manual Chapter 3. Hardware Settings 32 EPSI Header (JEPSI) 34 PCIE Hot-Plug SMB Header (JPCIE_HP) 33 Debug Port Header (JLPC_DP) 35 PCIE Hot-Plug Front Panel Header (J4, J5, & J6)
  • Page 48 Chapter 3. Hardware Settings SB402-VG User Manual 38 Front COM Header (JCOM1 & JCOM4) 42 BMC Debug Port Header (JBMC_DP) 39 VROC KEY Header (JRAID_KEY) 44 BMC I2C1 header (JBMC_I2C1) I2C1SCL I2C1SDA 40 LCM Header (JLCM) 45 BMC GPIO header (JBMC_GPIO)

  • Page 49: Jumper

    SB402-VG User Manual Chapter 3. Hardware Settings 3�4�2 Jumper SATA4 Pin-7 Power Header (J10) 26 No Reboot(Watch Dog) Jumper (J26) Setting J26 (No Reboot) Setting Short SATA4 pin-7 Power Short Enable Open Normal Default Open Disable Default SATA5 Pin-7 Power Header (J11)

  • Page 50: 3.5.1 Front Panel Led Definition

    Chapter 3. Hardware Settings SB402-VG User Manual 3�5 LEDs 3.5.1 Front Panel LED Definition Yellow The system is On. The system is in Standby; System is off, but Power Blinking has AC power. System has no AC power Blue UID activity is detected.

  • Page 51: Internal Led

    SB402-VG User Manual Chapter 3. Hardware Settings 3�5�3 Internal LED LAN2 10G LED LAN1 10G LED SFP+ LAN1 1G LED LAN2 1G LED LAN4 1G/10G LED LAN3 1G/10G LED BMC Heart Beat LED SAS IOC Status LED NVME Hot-Plug LED...

  • Page 52: Hdd Backplane: 2 Bay

    Chapter 3. Hardware Settings SB402-VG User Manual 3�6 HDD Backplane: 2 Bay 3�6�1 Placement Top view Bottom view...

  • Page 53: Connector Location

    SB402-VG User Manual Chapter 3. Hardware Settings 3�6�2 Connector Location Top view HDD0 HDD0 HDD1 Bottom view SATA1 SATA0 Power Header 3�6�3 Connector BP Power (JPWR) Activity Selection (HD_ACT_SW0/HD_ACT_SW1) SASIN0 HDDIN0 Open: Standard. 1. On : And 5Hz on DAS, for SSD320.

  • Page 54: Led Indicator

    Chapter 3. Hardware Settings SB402-VG User Manual 3�6�4 LED Indicator LED0 LED0 LED1 LED1 Blue (On) Link up Blue (Blinking) Activity detected SATA HD Link Blue (Off) Link down Status(LED0,LED1) Red (On) HDD error (external control only) Red (Off) HDD Normal...

  • Page 55: Hdd Backplane: 12 Bay

    SB402-VG User Manual Chapter 3. Hardware Settings 3�7 HDD Backplane: 12 Bay 3�7�1 Placement Top view Bottom view...

  • Page 56: Connector Location

    Chapter 3. Hardware Settings SB402-VG User Manual 3�7�2 Connector Location Top view JMCU_UART JFAN1 JEXP_UART JI2C0 JFAN3 JMCU_DBG JI2C4 JPMBUS JFAN2 JI2C3 JEXP2 JFAN4 Flash Expander Sensor Sensor JPWR1 JPWR2 JFRONT SASHD3 SASHD2 SASHD1 Bottom view HDD10 HDD7 HDD4 HDD1...
  • Page 57 SB402-VG User Manual Chapter 3. Hardware Settings 3�7�3 Connectors Power Connector – JPWR1 Description Description +12V +12V +3.3V MUTE_L +5VSTBY PSU_N1 PS_ON_L Power Connector – JPWR2 Description Description +12V +12V +12V +12V...
  • Page 58 Chapter 3. Hardware Settings SB402-VG User Manual I2C Connector – JI2C0, JI2C3, JI2C4 Description I2C_CLOCK I2C_DATA FAN Connector – JFAN1, JFAN2, JFAN3, JFAN4 Description +12V TACH Console for Expander – JEXP_UART Description Description DEBUG_RXD SMART_RXD DEBUG_TXD SMART_TXD Console for MCU – JMCU_DBG...

  • Page 59: Led Indicator

    SB402-VG User Manual Chapter 3. Hardware Settings 3�7�4 LED Indicator Fail Fail Fail Fail SASHD Status LED LED2 LED1 LED5...
  • Page 60 Chapter 3. Hardware Settings SB402-VG User Manual Blue (On) HDD present HDD Activity is detected or has located HDD Activity LEDs Blue (Blinking) HDD(slow) HDD is not connect or is power off. No control bit is set or set by any of the following bits: 1.
  • Page 61 SB402-VG User Manual Chapter 3. Hardware Settings 3�7�5 Jumpers JMD_SEL JMCU_RST Open Normal, default JMCU_RST Close Reset MCU Open Normal, default JMD_SEL Close Boot loader mode 2.54mm Header for Front I/O – JFRONT • Fan number select Pin[5,6] Pin [3,4] Pin [1,2] Fan no�...
  • Page 62 Chapter 3. Hardware Settings SB402-VG User Manual • AT Mode Setting Description Remark AT_SEL_N Active Low • Mute SW Description Remark MUTE Input(-) Active Low...

  • Page 63: Drive Slot Map

    SB402-VG User Manual Chapter 3. Hardware Settings 3�7�6 Drive Slot Map...

  • Page 64: Hdd Backplane: 24 Bay

    Chapter 3. Hardware Settings SB402-VG User Manual 3�8 HDD Backplane: 24 Bay 3�8�1 Placement Top view Bottom view...

  • Page 65: Connector Location

    SB402-VG User Manual Chapter 3. Hardware Settings 3�8�2 Connector Location Top view JFAN1 JFAN4 JMCU_UART JI2C4 JEXP_UART JPMBUS JFAN3 JI2C3 JI2C0 JEXP2 JMCU_DBG JFAN2 Flash Sensor Expander Expander Sensor SASHD3 SASHD2 SASHD1 JPWR1 JPWR2 JFRONT Bottom view HDD24 HDD18 HDD7...
  • Page 66 Chapter 3. Hardware Settings SB402-VG User Manual 3�8�3 Connectors Power Connector – JPWR1 Description Description +12V +12V +3.3V MUTE_L +5VSTBY PSU_N1 PS_ON_L Power Connector – JPWR2 Description Description +12V +12V +12V +12V...
  • Page 67 SB402-VG User Manual Chapter 3. Hardware Settings I2C Connector – JI2C0, JI2C3, JI2C4 Description I2C_CLOCK I2C_DATA FAN Connector – JFAN1, JFAN2, JFAN3, JFAN4 Description +12V TACH Console for Expander – JEXP_UART Description Description DEBUG_RXD SMART_RXD DEBUG_TXD SMART_TXD Console for MCU – JMCU_DBG...

  • Page 68: Led Indicator

    Chapter 3. Hardware Settings SB402-VG User Manual 3�8�4 LED Indicator LED2 LED2 LED1 LED1 SASHD Status LED SASHD Status LED LED3 LED3...
  • Page 69 SB402-VG User Manual Chapter 3. Hardware Settings Blue (On) HDD present HDD Activity is detected or has locate HDD Activity LEDs Blue (Blinking) HDD(slow). HDD is not connected or is power off. No control bit is set or set by any of the following bits: 1.
  • Page 70 Chapter 3. Hardware Settings SB402-VG User Manual 3�8�5 Jumpers JMCU_RST JMCU_RST JMD_SEL JMD_SEL Open Normal, default JMCU_RST Close Reset MCU Open Normal, default JMD_SEL Close Boot loader mode 2.54mm Header for Front I/O – JFRONT Fan number select • Fan number select...
  • Page 71 SB402-VG User Manual Chapter 3. Hardware Settings • AT Mode Setting Description Remark AT_SEL_N Active Low • Mute SW Description Remark MUTE Input(-) Active Low...

  • Page 72: Drive Slot Map

    Chapter 3. Hardware Settings SB402-VG User Manual 3�8�6 Drive Slot Map...

  • Page 73: Chapter 4. Bios Configuration Settings

    Chapter 4. BIOS Configuration Settings SB402-VG User Manual Chapter 4 BIOS Configuration Settings This chapter demonstrates how to configure the UEFI BIOS settings in your system device. You can enter the BIOS screen during system startup. To enter BIOS configuration settings, •...

  • Page 74: Bios Setup

    Chapter 4 BIOS Configuration Settings SB402-VG User Manual 4�2 BIOS Setup 4�2�1 Menu Press  and  to select the options of the menu bar. Press Enter to access the option screen. Menu Description Main Displays basic system information and date & time.
  • Page 75 SB402-VG User Manual Chapter 4 BIOS Configuration Settings Step 2 There will be a message “Entering SETUP” displayed on the diagnostics screen. Step 3 Identify the BIOS version. NOTE For the official released version, the last digit of the BIOS version must end in a “0.“...
  • Page 76 Chapter 4 BIOS Configuration Settings SB402-VG User Manual Step 4 Load Optimal Default Setting. Step 5 Save the setting and exit the BIOS setup utility.
  • Page 77 SB402-VG User Manual Chapter 4 BIOS Configuration Settings 4�2�3 Update To identify the latest BIOS version, please check the BIOS setup.
  • Page 78 Chapter 4 BIOS Configuration Settings SB402-VG User Manual Update BIOS by INSYDE H2OFFT-D utility under DOS environment If you need to update Flash in the DOS environment, please use H2OFFT-D utility. To use this utility, you must include the flash.bat , H2OFFT-D.exe, and bin file in the same folder.
  • Page 79 SB402-VG User Manual Chapter 4 BIOS Configuration Settings 4�3 Main Main Option Key: 4�3�1 Main Option Key Description System time Configures the current time. System date Configures the current date.

  • Page 80: Peripheral Configuration

    Chapter 4 BIOS Configuration Settings SB402-VG User Manual 4�4 Advanced Advanced Option Key: 4.4.1 Peripheral Configuration Peripheral Configuration PCIe SR-IOV Enable Disable PCIe ARI Enable Disable ARI Forward Enable Disable Spread Enable Disable Spectrum Redfish On/ Enable Disable 4.4.2 Video Configuration...
  • Page 81 SB402-VG User Manual Chapter 4 BIOS Configuration Settings MSR Lock Control Enable Disable Processor Configuration Extended APIC Enable Disable 128M 256M MMCFG Size 512M Common MMIO High Base RefCode Configuration MMIO High Granularity Size 256G 1024G Disable Minimum Serial Debug Message...
  • Page 82 Chapter 4 BIOS Configuration Settings SB402-VG User Manual Check Platform Detect Enable Disable Erase-Arm NVDIMMs Enable Disable Restore NVDIMMs Enable Disable Memory Configuration Interleave NVDIMMs Enable Disable Custom Refresh Rate Min=0, Max=40 Auto 100 KHz SMB Clock Frequency 400 KHz...
  • Page 83 SB402-VG User Manual Chapter 4 BIOS Configuration Settings Single Power Enable Disable Domain (SPD) Max Performance Boot performance Max Efficient mode Set by Intel Node Manager CPU P State Control Energy Enable Disable Efficient Turbo Turbo Mode Enable Disable CPU Flex Ratio...

  • Page 84: 4.4.4 Pch Configuration

    Chapter 4 BIOS Configuration Settings SB402-VG User Manual 4.4.4 PCH Configuration PCH Configuration PCH Devices PCH state after G3 Last State SATA Controller Configure SATA as AHCI RAID Support Aggressive Link Power Enable Disable Management Alternate Device ID on Enable...
  • Page 85 SB402-VG User Manual Chapter 4 BIOS Configuration Settings Smart Response Enable Disable Technology PCH SATA Configuration 2 Seconds 4 Seconds RAID OROM prompt delay 6 Seconds 8 Seconds sSATA Controller Enable Disable Configure sSATA as AHCI RAID Support Aggressive Link Power...
  • Page 86 Chapter 4 BIOS Configuration Settings SB402-VG User Manual SLP_LAN# Low on DC Enable Disable Power K1 off Enable Disable FPK Port 1-4 Enable Management Disable PCI Delay Optimization Enable Disable Compliance Test Enable Disable Mode PCI-E ASPM Support Per individual port...
  • Page 87 SB402-VG User Manual Chapter 4 BIOS Configuration Settings Enable Disable Enable Disable Enable Disable NFER Enable Disable Enable Disable SEFE Enable Disable SENFE Enable Disable SECE Enable Disable PME SCI Enable Disable Hot Plug Enable Disable Advanced Error Enable Disable...

  • Page 88: 4.4.5 H2O Ipmi Configuration

    Chapter 4 BIOS Configuration Settings SB402-VG User Manual Auto Non Snoop Latency Manual Override Disable Non Snoop Min=0, Max=102 Latency Value PCH sSATA PCH PCIe LTR Configuration Configuration 1 ns 32 ns Non Snoop Latency 1024 ns 32768 ns Multiplier...

  • Page 89: H2O Event Log Config Manager

    SB402-VG User Manual Chapter 4 BIOS Configuration Settings 4.4.6 H2o Event Log Config Manager H2o Event Log Config Manager Console Serial Enable Disable Redirect VT_100 VT_100+ Terminal Type VT_UTF8 PC_ANSI 1200 2400 4800 9600 Baud Rate 19200 38400 57600 115200...

  • Page 90: Security

    Chapter 4 BIOS Configuration Settings SB402-VG User Manual 4�5 Security Security Option Key: 4�5�1 Security Security Current TPM Not Detected TPM 1.2 TPM 2.0 Device TrEE Protocol Version Available Hidden Availability No operation Disable and Deactivate Enable and Activate Operation...

  • Page 91: Power

    SB402-VG User Manual Chapter 5. BMC Configuration Settings 4�6 Power Power Option Key: 4�6�1 Power Power Wake on PME Enable Disable...

  • Page 92: Boot

    SB402-VG User Manual Chapter 5. BMC Configuration Settings 4�7 Boot Boot Option Key: 4�7�1 Boot Boot Boot Type Dual Boot Type Legacy Boot Type UEFI Boot Type Quick Boot Enable Disable Quiet Boot Enable Disable Network Stack Enable Disable PXE Boot to...

  • Page 93: Exit

    SB402-VG User Manual Chapter 5. BMC Configuration Settings 4�8 Exit Exit Option Key: 4�8�1 Exit Save and Exit Exit Saving Changes Exit system setup and save your changes. Save Change Without Save your changes without exiting the system. Exit Exit Discarding Discard your changes when existing the system.

  • Page 94: Chapter 5. Bmc Configuration Settings

    Chapter 5. BMC Configuration Settings SB402-VG User Manual Chapter 5. BMC Configuration Settings Chapter 5. BMC Configuration Settings Insert Ethernet LAN cable into the BMC LAN port. There are two methods to setup BMC IP: BMC management port (Dedicated NIC channel 1 )
  • Page 95 SB402-VG User Manual Chapter 5. BMC Configuration Settings...
  • Page 96 SB402-VG User Manual Chapter 5. BMC Configuration Settings Step 3 Input the subnet mask address.

  • Page 97: Web Gui

    SB402-VG User Manual Chapter 5. BMC Configuration Settings 5�2 Web GUI The IP address below is an example using the default IP setting. The IP address is configurable. Step 1 Open the browser then type default BMC IP address: 192.168.22.22 Step 2 Use the default user name and password for first-time login to BMC WEB GUI.
  • Page 98 SB402-VG User Manual Chapter 5. BMC Configuration Settings Dashboard: The Dashboard page gives the overall information about the status of a device. Server Health - Sensor Readings: Then Sensors Readings page displays all the sensor related information. Settings: The Settings page allows you to access various configuration settings.
  • Page 99 SB402-VG User Manual Chapter 5. BMC Configuration Settings KVM Mouse Setting: The KVM Mouse Setting page displays the setting for mouse emulation from local window to remote screen. • For Windows OS environment, set mode to absolute. • For Linux OS environment, set mode to relative.
  • Page 100 SB402-VG User Manual Chapter 5. BMC Configuration Settings Environmental setting:...

  • Page 101: Chapter 6� Technical Support

    Chapter 6� Technical Support Taiwain, Global Headquarters South California, United States Address: No� 152, Section 4, Address: 21808 Garcia Lane Linghang N� Rd, Dayuan District, City of Industry, CA 91789, Taoyuan City 337, Taiwan United States Tel: +886-3-433-9188 Toll free: +7-4997019998 Fax: +886-3-287-1818 Tel: +1-909-895-8989 Sales Email: sales@aicipc�com�tw...
