SB402-LB
Storage Server Barebone
User's Manual
UM_SB402-LB_v3.1_120716

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB402-LB and is the answer not in the manual?

Questions and answers

Related Manuals for AIC SB402-LB

Summary of Contents for AIC SB402-LB

  • Page 1 SB402-LB Storage Server Barebone User's Manual UM_SB402-LB_v3.1_120716...

  • Page 2: Table Of Contents

    CONTENTS PREFACE ������������������������������������������������������������������������������������������� i SAFETY INSTRUCTIONS �������������������������������������������������������������������� ii Chapter 1� Prodcut Introduction ������������������������������������������������ 1 1�1 Box Content ����������������������������������������������������������������������������������������1 1.2 Specifications �������������������������������������������������������������������������������������2 1�3 General Information ���������������������������������������������������������������������������3 Chapter 2� Hardware Installation ����������������������������������������������� 6 2�1 Central Processing Unit (CPU) �����������������������������������������������������������6 2�2 System Memory ��������������������������������������������������������������������������������14 2�3 Removing and Installing Top Cover �����������������������������������������������18 2�4 Installing/ Removing a Hard Disk Drive ������������������������������������������19 2�5 Removing and Installing a Fan Module �����������������������������������������21...
  • Page 3 5�3 Connect to BMC �������������������������������������������������������������������������������64 5�4 Web UI �����������������������������������������������������������������������������������������������65 5�4 Updating BMC Firmware ������������������������������������������������������������������72 Chapter 6� Hardware Introduction ������������������������������������������� 73 6�1 HARDWARE DESIGN SPECIFICATION �����������������������������������������������73 6�2 HARDWARE DESIGN SPECIFICATION �����������������������������������������������81 Chapter 7� Technical Support��������������������������������������������������� 90 contents...
  • Page 4 Copyright © 2016 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.

  • Page 5: Preface

    AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS • Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components.
  • Page 7 • product, voltage and current marked on the product’s electrical ratings label. The voltage and current rating of the cord should be greater than the voltage and current rating marked on the product. • If the equipment is not used for a long time, disconnect the equipment from mains to avoid being damaged by transient over-voltage.

  • Page 8: Chapter 1� Prodcut Introduction

    • Enclosure( Power supply, fan, 36 x 3.5'' HDD tray included) • 3.5’’ HDD Tray • Power cord • Screws kit x 1set • (Include console serial cable) • Slide rail x 1set ♦ PACKAGE CONTENT MAY VARY PER REGION. SB402-LB User's Manual...

  • Page 9: Chapter 1 Product Introduction

    FLASH Interface (with chassis ears) inches : 19 x 26.7 x 6.8 • ACPI • BIOS Boot • PXE Motherboard AIC Server Board Libra Specification • WOL System BIOS • BIOS Recovery • AC loss recovery Processor Two Intel® Xeon® Processors E5-2600...

  • Page 10: 1�3 General Information

    Chapter 1 Product Introduction 1�3 General Information SB402-LB is a 4U rackmount chassis with 36x3.5”HDD hot swap Bays at front and single 12G expander on HDD Backplane which is a high performance server storage product. • Front Panel 2 x USB3.0 ports 24 x 3.5”...
  • Page 11 Chapter 1 Product Introduction • Rear Panel SB402-LB User's Manual...
  • Page 12 Chapter 1 Product Introduction • Major Components SB402-LB User's Manual...

  • Page 13: Chapter 2� Hardware Installation

    • Proceed to screw 2 and loosen it by giving it two rotations and stop (see letter B). Similarly, loosen screws 3 and 4. Repeat steps A and B by giving each screw two rotations each time until all screws are loosened. • Lift the heatsink straight up (see letter C). SB402-LB User's Manual...
  • Page 14 2.1.2.1 Unlatch the CPU Load Plate • Push the lever handle labeled “OPEN 1st” (see letter A) down and toward the CPU socket. Rotate the lever handle up. • Repeat the steps for the second lever handle (see letter B). SB402-LB User's Manual...
  • Page 15 2.1.2.2 Lift open the Load Plate • Rotate the right lever handle down until it releases the Load Plate (see letter A). • While holding down the lever handle, with your other hand, lift open the Load Plate (see letter B). SB402-LB User's Manual...
  • Page 16 The processor must align correctly with the socket opening before installation. DO NOT DROP the processor into the socket. NOTE : When possible, a CPU insertion tool should be used when installing the CPU. SB402-LB User's Manual...
  • Page 17 Make sure the load plate tab engages under the socket lever when fully closed. • b.Repeat the steps to latch the locking lever on the other side (see letter C). Latch the levers in the order as shown. SB402-LB User's Manual...
  • Page 18 (see letter D). Similarly, engage screws 3 and 4. • Repeat steps C and D by giving each screw two rotations each time until each screw is lightly tightened up to a maximum of 8 inch-lbs torque (see letter E). CAUTION: Do not over-tighten fasteners. SB402-LB User's Manual...
  • Page 19 Remove the processor by carefully lifting it out of the socket, taking care NOT to drop the processor and not touching any pins inside the socket. Install the socket cover if a replacement processor is not going to be installed. SB402-LB User's Manual...
  • Page 20 Caution - Possible thermal damage. Avoid moving the heatsink after it has contacted the top of the CPU. Too much movement could disturb the layer of thermal compound, causing voids, and leading to ineffective heat dissipation and component damage. SB402-LB User's Manual...

  • Page 21: 2�2 System Memory

    2�2 System Memory This server board supports up to sixteen DDR4 1333/1600/1866/2133 Registered ECC SDRAM(RDIMM) / Load-Reduced DIMM (LRDIMM). JDIMMG0 JDIMMG1 JDIMMH0 JDIMMA0 JDIMMA1 JDIMMH1 JDIMMB0 JDIMMB1 JCPU1 JCPU0 JDIMMF1 JDIMMF0 JDIMME1 JDIMMD1 JDIMME0 JDIMMD0 JDIMMC1 JDIMMC0 JBMC_DP SB402-LB User's Manual...

  • Page 22: Chapter 2 Hardware Installation

    JDIMMD1 JDIMMF0 JDIMMD0 JDIMME1 JDIMMC1 JDIMMC0 JDIMME0 JDIMMG0 JDIMMA0 JDIMMG1 JDIMMA1 JDIMMB0 JDIMMH0 JDIMMB1 JDIMMH1 CPU1 CPU0 JDIMM_G0 JDIMM_A0 8 DIMMs JDIMM_H0 JDIMM_B0 CPU0 CPU1 JDIMM_F0 JDIMM_D0 JDIMM_E0 JDIMM_C0 JDIMMF1 JDIMMD1 JDIMMF0 JDIMMD0 JDIMME1 JDIMMC1 JDIMME0 JDIMMC0 SB402-LB User's Manual...
  • Page 23 JDIMMA0 CPU1 CPU0 JDIMMG1 JDIMMA1 JDIMMH0 JDIMMB0 JDIMM_G0 JDIMM_A0 JDIMMH1 JDIMMB1 JDIMM_G1 JDIMM_A1 JDIMM_H0 JDIMM_B0 16 DIMMs JDIMM_H1 JDIMM_B1 CPU0 CPU1 JDIMM_F1 JDIMM_D1 JDIMM_F0 JDIMM_D0 JDIMM_E1 JDIMM_C1 JDIMMF1 JDIMMD1 JDIMMF0 JDIMMD0 JDIMM_E0 JDIMM_C0 JDIMME1 JDIMMC1 JDIMME0 JDIMMC0 SB402-LB User's Manual...
  • Page 24 2.2.2 DIMM Installation Procedure Unlock a DIMM socket by pressing the retaining clips outward. Insert module vertically and press down until it snaps into place. Note: DIMM notch and socket bump must align as shown. DIMM notch SB402-LB User's Manual...

  • Page 25: 2�3 Removing And Installing Top Cover

    Chapter 2 Hardware Installation 2�3 Removing and Installing Top Cover Pushing release button on both side and slide forward the top cover to open cover. SB402-LB User's Manual...

  • Page 26: 2�4 Installing/ Removing A Hard Disk Drive

    Directly place HDD into tool-less HDD tray untli it snaps. Please check if the screw holes on HDD match the dimples on HDD tray. HDD can also be screwed on HDD tray by fastening two screws as picture showed. SB402-LB User's Manual...
  • Page 27 2.4.2 Insert the drive tray into chassis HDD cage. Make sure the drive tray is correctly secured in place when its front edge aligns with the bay edge. Push the tray lever until it reaches the end and clicks. SB402-LB User's Manual...

  • Page 28: 2�5 Removing And Installing A Fan Module

    Chapter 2 Hardware Installation 2�5 Removing and Installing a Fan Module 2.5.1 Removing a fan module Grabbing and removing the fan module from the fan slot. SB402-LB User's Manual...
  • Page 29 Pull the fan module up gently and taking out the fan module by removing rubbers out from the fan bar. 2.6.2 Installing a Fan Module Make sure the 4 rubbers and connector insert firmly while fan module is inserted. SB402-LB User's Manual...

  • Page 30: 2�6 Removing And Installing The Hdd Backplane Module

    • Unplugging all connectors & HDDs from HDD backplane. • Release the lock pin. 2.6.2 Installing a HDD backplane module • Slide the HDD backplane module into enclosures. • Secure the HDD backplane module onto the enclosures using the screws. SB402-LB User's Manual...
  • Page 31 Lift up and remove the blackplane to the a little bit up from hook then can get out. 2.6.3 Installing a HDD backplane module(follow the reverse order) • Align the backplane with the hooks, and insert it into the enclosure firmly. • Lock the backplane. Follow the reverse order. SB402-LB User's Manual...

  • Page 32: 2�7 Removing And Installing A Psu Module

    2. Pushing the latch and hold the tray handle. 3. Pull the PSU module tray handle out gently to slides out the PSU module. 2.7.2 Installing a PSU Module • To install PSU module, follow the reverse order. SB402-LB User's Manual...

  • Page 33: 2�8 Removing And Installing A Pcie Card

    1. Location to external connector side of card. 2. Location to fix right downside of the card . 3. PCI Slot to put card printedbord connectors.  SB402-LB User's Manual...
  • Page 34 • Insert the card gently rolling in the side "right" between the edge of the motherboard and the wall of the Storage Server Barbone. • Press firmly to completely plug the card into the PCI slot and the screws in Storage Server Barbone. SB402-LB User's Manual...
  • Page 35 Chapter 2 Hardware Installation • Check your earthing is working properly . • Turn on your Storage Server Barbone, system detects new hardware. • To remove PCIe Card, follow the reverse order. SB402-LB User's Manual...

  • Page 36: 2�9 Removing And Installing A Rj45 Module

    Turn off your Storage Server Barebone and disconnect the power supply. 2.9.1 Installing a RJ45 Module • Remove PCI Bracket Slot Cover. • Take the RJ45 module insert onto the chassis. • Be sure the RJ45 module insert to chassis properly. SB402-LB User's Manual...
  • Page 37 1. Punch out additional flashing on the I/O shield to make room for RJ45 module. 2. Align the module to the top and botton of the I/O shield for correct direction. 3. Secure the RJ45 module on the I/O shield using the screws. SB402-LB User's Manual...
  • Page 38 2.9.2 Configure the RJ45 function setting LAN3 Insert one end of the cable into port of the barebone. Insert the LAN4 other end of the cable into the corresponding port on site of the barebone. 1. Type 2. Type SB402-LB User's Manual...

  • Page 39: 2�10 Tool-Less Blade Slide Installation Instruction

    2�10 Tool-less Blade Slide Installation Instruction Separate the tool-less slide rail 2.10.1 Pull the inner rail out of the outer rail until it is fully extended. Press the locking tab down to release the inner rail. Outer Rail Middle Rail Inner Rail SB402-LB User's Manual...
  • Page 40 2.10.2 Place the inner rail firmly against the side of the chassis. Make sure that the hooks are straight and aligned with the holes in the inner rail. Screw Screw Slide the inner rail forward until it clicks into the locked position. SB402-LB User's Manual...
  • Page 41 Chapter 2 Hardware Installation 2.10.3 Press the locking tab and push the middle rail back into the outer rail. SB402-LB User's Manual...
  • Page 42 Chapter 2 Hardware Installation 2.10.4 Hang the hooks of the rails on the rack holes and if necessary, secure with screws. Optional Screws SB402-LB User's Manual...
  • Page 43 Chapter 2 Hardware Installation 2.10.5 Repeat step 2.7.4 to mount the four ends, extending the rails as necessary. SB402-LB User's Manual...
  • Page 44 Ball Bearing Shuttle Align the inner rails with the middle rails and then push evenly on both sides of the chassis until it clicks into the fully extended position. SB402-LB User's Manual...
  • Page 45 2.10.7 Depress the locking tabs on both sides of the chassis simultaneously and push the chassis all the way into the rear of the rack. Screw Screw If additional security is required, secure the chassis handles to the front of the rack with two screws (optional). Complete SB402-LB User's Manual...

  • Page 46: Chapter 3� Motherboard Settings

    Chapter 3 Motherboard Setting Chapter 3� Motherboard Settings This section describes the jumpers, internal connectors, and internal LEDs setting on Libra motherboard. Motherboard layout and important jumper settings are listed as below. 3�1 Motherboard block diagram SB402-LB User's Manual...

  • Page 47: 3�2 Motherboard Block Diagram

    PCIe slot3 JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB PCIe slot2 JLPC_DP SATA6 SATA5 I210 I217 JSPKR1 SATA8 SATA7 PCIe slot1 JUSB_INT JNGFF JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JLAN2 JCOM4 JLCM JINTRUDERJ BMC_I2C1 SB402-LB User's Manual...

  • Page 48: 3�3 Motherboard Content List

    Chapter 3 Motherboard Setting 3�3 Motherboard Content List SB402-LB User's Manual...

  • Page 49: 3�4 Internal Connectors/Jumpers

    JDIMMD0 JDIMMC1 JDIMMC0 JPG_LOOK1 JSPI JBUZZER JDOM_PWR JPWR3 JBMC_GPIO JTPM JSGPIO JSSGPIO JCMOS JPCH_GPIO JNTB JLPC_DP JUSB_INT JSPKR1 JNGFF JUSB_INT JFRNT_SSI JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JPMBUS PWM4 FAN7_TACH +12V HM_TD7- HM_TD7+ SB402-LB User's Manual...
  • Page 50 Chapter 3 Motherboard Setting JPWR3 JDOM_PWR JPG_LOOK1 JUSB_INT SB402-LB User's Manual...
  • Page 51 JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB JLPC_DP SATA6 SATA5 JSPKR1 SATA8 SATA7 JNGFF JUSB_INT JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JTPM JSGPIO JSSGPIO JCMOS JNTB JSPKR1 SB402-LB User's Manual JLAN1 JLAN2 JCOM4...
  • Page 52 Chapter 3 Motherboard Setting JTPM JSGPIO JSSGPIO +3.3V PCH_SPI_MISO PCH_SPI_MOSI PCH_SPI_CLK PCH_GPIO23 PCH_SPI_CS1_N PCH_LDRQ0_N PCH_SPI_CS2_N RST_PLTRST_N JSPKR1 JLAN2 JLAN1 JLAN4 SB402-LB User's Manual...
  • Page 53 JDOM_PWR JPWR3 JBMC_GPIO JTPM JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB JLPC_DP SATA6 SATA5 JSPKR1 SATA8 SATA7 JNGFF JUSB_INT JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JPCH_GPIO JLPC_DP JNGFF JBMC_DP JLCM SB402-LB User's Manual...
  • Page 54 Chapter 3 Motherboard Setting JLPC_DP PCH_GPIO21 JPCH_GPIO PCH_GPIO27 JBMC_DP JLCM SB402-LB User's Manual...
  • Page 55 Chapter 3 Motherboard Setting SB402-LB User's Manual...
  • Page 56 Chapter 3 Motherboard Setting JNGFF SB402-LB User's Manual...
  • Page 57 JBMC_I2C10 JBUZZER JPWR3 JDOM_PWR PCIe slot4 LSISA JBMC_GPIO JTPM S3008 PCIe slot3 JSGPIO JSSGPIO JCMOS JPCH_GPIO JNTB PCIe slot2 JLPC_DP I210 I217 JSPKR1 PCIe slot1 JUSB_INT JNGFF JBMC_RST JBMC_DIS JBMC_DP JINTRUDER JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JBMC_I2C1 SB402-LB User's Manual...
  • Page 58 Chapter 3 Motherboard Setting JPWR1 JVGA_INT JPMBUS +12V DACROA DACGOA +12V DDC_DATAO +12V DACBOA AHSYNCO +12V DVO_5V AVSYNCO DDC_CLKO JBMC_I2C10 JBUZZER JBMC_GPIO BMC BUZZER- I2C10SDA I2C10SCL JBMC_I2C1 SB402-LB User's Manual...

  • Page 59: 3�5 Leds

    Chapter 3 Motherboard Setting 3�5 LEDs 3.5.1 Front Panel LED SB402-LB User's Manual...
  • Page 60 Chapter 3 Motherboard Setting 3.5.2 Rear Panel LED SB402-LB User's Manual...
  • Page 61 Chapter 3 Motherboard Setting 3.5.3 Internal LEDs LED4 LED1 LED3 LED2 SB402-LB User's Manual...

  • Page 62: Chapter 4. Bios Configuration And Settings

    Press ESC to run the setup procedure. There will be a message “Entering SETUP” displayed on the diagnostics screen. Caution: For the official released version, the last digit of the BIOS Version must end in an "0." SB402-LB User's Manual...
  • Page 63 Chapter 4 BIOS Configuration and Settings Identify the BIOS Version Load Optimal Default setting Save the setting and exit the BIOS setup utility. SB402-LB User's Manual...

  • Page 64: 4�1 Updating Bios

    Chapter 4 BIOS Configuration and Settings 4�1 Updating BIOS Important Notes: To identify the current BIOS version, please check out on BIOS setup. SB402-LB User's Manual...
  • Page 65 H2OFFT-D utility. To use this utility, you must include the flash.bat , H2OFFT-D.exe, and bin file in the same folder. Please follow the instructions to update whole flash part: Execute flash.bat to update Flash in the DOS environment. Reboot system. SB402-LB User's Manual...

  • Page 66: Chapter 5

    BMC Configuration and Settings Insert Ethernet LAN cable into the BMC LAN port. There are two methods to setup BMC IP: BMC management port 5�1 Method 1 (Use the BIOS setup) • BIOS SETUPServer MgmtBMC network configurationConfiguration Address sourceStatic SB402-LB User's Manual...
  • Page 67 Chapter 5 BMC Configuration and Settings 2. Input IP address. Set static IP. SB402-LB User's Manual...
  • Page 68 Chapter 5 BMC Configuration and Settings 3. Input subnet mask address. SB402-LB User's Manual...

  • Page 69: 5�2 Method 2 (Use A Dos Tool - Syscheck)

    5�2 Method 2 (Use a Dos tool - Syscheck) 1. Type : sc –lanset 2. Modify IP setting Note: type 1 for selecting static IP mode or type 2 for selecting DHCP mode. 3. Input IP address SB402-LB User's Manual...
  • Page 70 Below IP address is an example using a default IP setting. User is allowed to change the IP address for realistic use. 5. Finish BMC IP configuration. Note: Type sc.exe –langet command to obtain BMC IP and MAC address. SB402-LB User's Manual...

  • Page 71: 5�3 Connect To Bmc

    Password: admin Note: The default user name and password are in lower-case characters. Note: Users who login with the admin user name and password will have full administrative power. The admin password can be changed after login. SB402-LB User's Manual...

  • Page 72: 5�4 Web

    A graphical representation of all events incurred by the various sensors and % occupied/available space in logs. If you click on the color- coded rectangle in the Legend for the chart, you can view a list of those specific events only. SB402-LB User's Manual...
  • Page 73 • Product Part Number • Language • Product Version • Manufacture Date Time • Product Serial Number • Board Manufacturer • Asset Tag • Board Product Name • FRU File ID • Board Serial Number • Product Extra SB402-LB User's Manual...
  • Page 74 Chapter 5 BMC Configuration and Settings 5.4.3 Sensor Modification Enable/disable sensors to match your system configuration. After modify sensors, please clear all logs via this BMC WEB GUI. Server HealthgEvent LoggClear All Event Logs). SB402-LB User's Manual...
  • Page 75 Chapter 5 BMC Configuration and Settings 5.4.4 Sensor reading All sensor related information will be displayed here. Double click on a record to loggle(ON/OFF)the live widget for that particular sensor. SB402-LB User's Manual...
  • Page 76 Event Log. Clear All Event Logs Clear All Event Logs option will delete all existing records for all sensors. Save All Event Logs Save All Event Logs option will save all existing records for all sensors. SB402-LB User's Manual...
  • Page 77 Icon status Green: This slot inserted HDD and power on. Blue: This slot inserted HDD and power off. Red: This slot inserted HDD and got error. Gray: This slot not inserted HDD. Orange: This slot is rebuilding. SB402-LB User's Manual...
  • Page 78 Chapter 5 BMC Configuration and Settings 5.4.7 Remote Control: Environmental setting: Press “ALT+C” for local and remote OS mouse control switching. SB402-LB User's Manual...

  • Page 79: 5�4 Updating Bmc Firmware

    A:>cd SB301C01 A:\ SB301C01>a.bat This is just an example. The latest BMC firmware version is available from the FAE or AIC website. 4. After update BMC firmware, please power off and then power on system. Notes: 1. DO NOT USE EMM386 IN DOS ENVIRONMENT WHEN UPDATING FIRMWARE OR YOU WILL GET A FAIL.

  • Page 80: Chapter 6� Hardware Introduction

    Chapter 6 Hardware Instruction Chapter 6� Hardware Introduction This chapter provides detailed instruction guide on hardware instruction 6�1 HARDWARE DESIGN SPECIFICATION 6.1.1 Placement PCBA Placement SB402-LB User's Manual...
  • Page 81 6.1.2 Connector Location Connector Location JFAN1 JI2C3 JI2C0 JEXP2 JEXP2 JFAN3 JFAN3 JFAN4 JFAN4 JFAN2 JFAN2 JI2C4 JI2C4 JEXP_UART JEXP_UART JMCU_DBG JMCU_DBG JMCU_UART JMCU_UART JPMBUS JPMBUS SASHD3 SASHD3 JPWR1 JPWR1 SASHD2 SASHD2 SASHD1 SASHD1 JPWR2 JPWR2 JFRONT JFRONT SB402-LB User's Manual...
  • Page 82 Chapter 6 Hardware Instruction 6.1.3 Connectors Power Connector – JPWR1 Description Description +12V +12V +3.3V MUTE_L +5VSTBY PSU_N1 PS_ON_L Power Connector – JPWR2 Description Description +12V +12V +12V +12V PMBUS Connector – JPMBUS Description PMBUS_CLOCK PMBUS_DATA SB402-LB User's Manual...
  • Page 83 I2C Connector – JI2C0, JI2C3, JI2C4 Description I2C_CLOCK I2C_DATA FAN Connector – JFAN1, JFAN2, JFAN3, JFAN4 Description I2C_CLOCK I2C_DATA Console for Expander – JEXP_UART Description Description DEBUG_RXD SMART_RXD +12V DEBUG_TXD SMART_TXD Remote Power Control – JMCU_UART Description Description DOWN_RXD UP_RXD DOWN_TXD UP_TXD SB402-LB User's Manual...
  • Page 84 For External LED(-) LED Cathode • FAN Fail LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode • Power Fault LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode SB402-LB User's Manual...
  • Page 85 MUTE Input(-) Active Low • Power/ID LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode • Power SW Description Remark Power SW Input(-) Active Low • PMBUS Support Description Remark PMBUS_Disable_N Active Low SB402-LB User's Manual...
  • Page 86 Activity detected Link down Expander alive, 0.833Hz Expander Blink (LED2) Blue (Blinking) (12 seconds per cycle) Expander Heart Bit Blue (Blinking) Expander FW running (LED1) Yellow (On) MCU alive MCU Status (LED3) Yellow (Off) Boot loader mode SB402-LB User's Manual...
  • Page 87 Chapter 6 Hardware Instruction 6.1.5 Jumpers JMCU_RST JMCU_RST JMD_SEL JMD_SEL Open Normal, default JMCU_RST Close Reset MCU Open Normal, default JMD_SEL Close Boot loader mode SB402-LB User's Manual...

  • Page 88: 6�2 Hardware Design Specification

    Chapter 6 Hardware Instruction 6�2 HARDWARE DESIGN SPECIFICATION 6.2.1 Placement PCBA Placement SB402-LB User's Manual...
  • Page 89 JPWR1 SASHD2 SASHD2 JMCU_DBG JMCU_DBG JPWR2 JPWR2 JMCU_UART JMCU_UART SASHD1 SASHD1 JFRONT JFRONT HDD10 HDD10 HDD7 HDD7 HDD4 HDD4 HDD1 HDD1 HDD11 HDD11 HDD8 HDD8 HDD5 HDD5 HDD2 HDD2 HDD12 HDD12 HDD9 HDD9 HDD6 HDD6 HDD3 HDD3 SB402-LB User's Manual...
  • Page 90 Chapter 6 Hardware Instruction 6.2.3 Connectors Power Connector – JPWR1 Description Description +12V +12V +3.3V MUTE_L +5VSTBY PSU_N1 PS_ON_L Power Connector – JPWR2 Description Description +12V +12V +12V +12V PMBUS Connector – JPMBUS Description PMBUS_CLOCK PMBUS_DATA SB402-LB User's Manual...
  • Page 91 I2C Connector – JI2C0, JI2C3, JI2C4 Description I2C_CLOCK I2C_DATA FAN Connector – JFAN1, JFAN2, JFAN3, JFAN4 Description I2C_CLOCK I2C_DATA Console for Expander – JEXP_UART Description Description DEBUG_RXD SMART_RXD +12V DEBUG_TXD SMART_TXD Remote Power Control – JMCU_UART Description Description DOWN_RXD UP_RXD DOWN_TXD UP_TXD SB402-LB User's Manual...
  • Page 92 For External LED(-) LED Cathode • FAN Fail LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode • Power Fault LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode SB402-LB User's Manual...
  • Page 93 MUTE Input(-) Active Low • Power/ID LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode • Power SW Description Remark Power SW Input(-) Active Low • PMBUS Support Description Remark PMBUS_Disable_N Active Low SB402-LB User's Manual...
  • Page 94 Activity detected Link down Expander alive, 0.833Hz Expander Blink (LED1) Blue (Blinking) (12 seconds per cycle) Expander Heart Bit Blue (Blinking) Expander FW running (LED2) Yellow (On) MCU alive MCU Status (LED5) Yellow (Off) Boot loader mode SB402-LB User's Manual...
  • Page 95 Chapter 6 Hardware Instruction 6.2.5 Jumpers JMCU_RST JMCU_RST JMD_SEL JMD_SEL Open Normal, default JMCU_RST Close Reset MCU Open Normal, default JMD_SEL Close Boot loader mode SB402-LB User's Manual...
  • Page 96 Chapter 6 Hardware Instruction 6.2.6 Drive Slot Map SB402-LB User's Manual...

  • Page 97: Chapter 7� Technical Support

    Chapter 1 Product Introduction Chapter 1 Product Introduction Chapter 7� Technical Support www�aicipc�com • TAIWAN Tel: +886 3 433 9188 Fax: +886 3 287 1818 Email : sales@aicipc�com�tw • CHINA Tel: +86�21�54961421, +86�21�54961422 Fax: Extension: 608 Email Technical Support: support@aicipc�com •...
