  • Page 1 SB101-LB Storage Server Barebone User's Manual UM_SB101-LB_v1.4_052219...

  • Page 2: Table Of Contents

    Table of Contents Preface ������������������������������������������������������������������������������������������������� i Safety Instructions ������������������������������������������������������������������������������ ii About This Manual ������������������������������������������������������������������������������ iv Chapter 1� Product Features �������������������������������������������������������������� 1 1�1 Box Contents ������������������������������������������������������������������������������������1 1�2 Specifications������������������������������������������������������������������������������������2 1�3 Features ��������������������������������������������������������������������������������������������3 Chapter 2� Hardware Setup ���������������������������������������������������������������� 6 2�1 Central Processing Unit (CPU) �����������������������������������������������������������6 2.1.1 Removing the processor ..................6 2.1.2 Installing the processor ..................8 2�2 System Memory ������������������������������������������������������������������������������12...
  • Page 3 Chapter 3� Hardware Settings ���������������������������������������������������������� 27 3�1 Motherboard Block Diagram ������������������������������������������������������������27 3�2 Content List �������������������������������������������������������������������������������������28 3�3 Motherboard Layout ������������������������������������������������������������������������29 3�4 Connector and Jumper ��������������������������������������������������������������������30 3�5 System LEDs ����������������������������������������������������������������������������������38 3.5.1 Front Panel LED ....................38 3.5.2 Rear Panel LED ....................39 3.5.3 Internal LEDs ....................
  • Page 4 4.4.15 SPS ME ICC Configuration ................55 4.4.16 H2O IPMI Configuration ................55 4.4.17 OEMBoard Function ..................56 4�5 Security �������������������������������������������������������������������������������������������57 4.5.1 Set Supervisor password ................57 4�6 Power ����������������������������������������������������������������������������������������������58 4.6.1 Power ....................... 58 4�7 Boot ������������������������������������������������������������������������������������������������59 4.7.1 Boot ........................59 Chapter 5.
  • Page 5 Copyright © 2018 AIC, Inc� All Rights Reserved� This document contains proprietary information about AIC products and is not to be disclosed or used except in accordance with applicable agreements.
  • Page 6 Document Release History Release Date Version Update Content September User's Manual release to public. 2018 1. Motherboard Connector and Jumper update. January 2. Front panel and rear panel update. 2019 3. HDD BP update. April Website update 2019...

  • Page 7: Preface

    Disclaimer AIC shall not be liable for technical or editorial errors or omissions contained herein. The information provided is provided "as is" without warranty of any kind. To the extent permitted by law, neither AIC or its affiliates, subcontractors or suppliers will be liable for incidental, special or consequential damages including downtime cost;...

  • Page 8: Safety Instructions

    Safety Instructions Before getting started, please read the following important cautions: • All cautions and warnings on the equipment or in the manuals should be noted. • Most electronic components are sensitive to electrical static discharge. Therefore, be sure to ground yourself at all times when installing the internal components. •...
  • Page 9 • If one of the following situations arise, the equipment should be checked by service personnel: 1. The power cord or plug is damaged. 2. Liquid has penetrated the equipment. 3. The equipment has been exposed to moisture. 4. The equipment does not work well or will not work according to its user manual. 5.

  • Page 10: About This Manual

    This document pellucidly presents a brief overview of the product design, device installation, and firmware settings for SB101-LB. For the latest version of this user's manual, please refer to the AIC website: https://www.aicipc.com/en/productdetail/50953.

  • Page 11: Chapter 1� Product Features

    SB101-LB User Manual SB101-LB User Manual Chapter 1. Product Features SB101-LB is a high density storage server that includes mother board, chassis, power supply, and HDD backplane. For more information about our product, please visit our website at http://www.aicipc.com/en. Before removing the subsystem from the shipping carton, visually inspect the physical condition of the shipping carton.

  • Page 12: 1�2 Specifications

    SB101-LB User Manual Chapter 1. Product Features 1.2 Specifications 2 x 10GbE RJ45 mm : 438 x 680 x 43.5 Dimensions 1 x dedicated management RJ45 (W x D x H) inches : 17.2 x 26.8 x 1.7 2 x USB 3.0...

  • Page 13: 1�3 Features

    Chapter 1. Product Features 1�3 Features SB101-LB is a reliable 1U storage server barebone with 4 hotswap drives bays. This prod- uct is designed to accommodate the AIC-patented serverboard, Libra, which supports two Intel® Xeon® Processors E5-2600 v3/v4 and 16 DDR4 DIMM to offer greater perfomance, efficiency, and utility for our customers.
  • Page 14 SB101-LB User Manual Chapter 1. Product Features Front Panel 4x 3.5" HDD tray System button and LED indicator Rear Panel...
  • Page 15 SB101-LB User Manual Chapter 1. Product Features Major Components...

  • Page 16: Chapter 2� Hardware Setup

    Chapter 2� Hardware Setup SB101-LB User Manual Chapter 2. Hardware Setup 2�1 Central Processing Unit (CPU) 2�1�1 Removing the processor Step 1 Remove the heatsink. The heatsink is attached to the server board or -processor socket with captive fasteners. Use a #2 Phillips* screwdriver to loosen the screws x 4 located on the heatsink corners diagonally using the following procedure (1a) to (1b).
  • Page 17 SB101-LB User Manual Chapter 2. Hardware Setup Step 2 Unlatch the CPU Load Plate by following procedures (2a) to (2b). (2a) Push the lever handle labeled “OPEN 1st” (see letter A) down and towards the CPU socket. Rotate the lever handle upward.

  • Page 18: Installing The Processor

    SB101-LB User Manual Chapter 2. Hardware Setup 2�1�2 Installing the processor CAUTION Processor must be appropriate: you may damage the server board if you install a processor that is inappropriate for your server. CAUTION ESD and handling processors: reduce the risk of electrostatic discharge (ESD) damage to the processor by doing the following: (1) Touch the metal chassis before touching the processor or server board.
  • Page 19 SB101-LB User Manual Chapter 2. Hardware Setup Step 1 Remove the processor from its package by following procedures (1a) to (1b). (1a) Carefully remove the protective cover from the backside of the CPU. Take care not to touch any CPU contacts (see letter A).
  • Page 20 SB101-LB User Manual Chapter 2. Hardware Setup Step 2 Remove the socket cover from the load plate. NOTE The socket cover should be saved and re-used should the processor need to be removed at any time in the furture. Save the protective cover.
  • Page 21 SB101-LB User Manual Chapter 2. Hardware Setup Step 5 Installing the heatsink on top of the processor. NOTE The processor heatsink for CPU1 and CPU2 is different.. FXXCA91X91HS is for CPU1, while FXXEA91X91HS2 is for CPU2. Mislocating the heatsink will cause serious thermal damage.

  • Page 22: 2�2 System Memory

    SB101-LB User Manual Chapter 2. Hardware Setup 2�2 System Memory This server board supports up to sixteen DDR4 1333/1600/1866/2133 Registered ECC SDRAM(RDIMM) / Load-Reduced DIMM (LRDIMM). JDIMMG0 JDIMMG1 JDIMMH0 JDIMMA0 JDIMMA1 JDIMMH1 JDIMMB0 JDIMMB1 JCPU1 JCPU0 JDIMMF1 JDIMMF0 JDIMME1 JDIMMD1...

  • Page 23: Dimm Installation Order

    SB101-LB User Manual Chapter 2. Hardware Setup 2�2�1 DIMM Installation Order Popoluate the DIMMs slots in the following order. JDIMMG0 JDIMMA0 JDIMMG1 JDIMMA1 JDIMMH0 JDIMMB0 JDIMMH1 JDIMMB1 DIMM Numbers DIMM Arrangement CPU1 CPU0 CPU1 CPU0 2 DIMMs JDIMM_G0 JDIMM _A0...
  • Page 24 SB101-LB User Manual Chapter 2. Hardware Setup JDIMMG0 JDIMMA0 JDIMMG1 JDIMMA1 JDIMMB0 JDIMMH0 JDIMMB1 JDIMMH1 CPU1 CPU0 JDIMM_ G0 JDIMM_A0 JDIMM_ G1 JDIMM_A1 10 DIMMs CPU1 CPU0 JDIMM_ H0 JDIMM_B0 JDIMM_ F0 JDIMM_D0 JDIMM_ E0 JDIMM_C0 JDIMMF1 JDIMMD1 JDIMMF0 JDIMMD0...

  • Page 25: Dimm Installation

    SB101-LB User Manual Chapter 2. Hardware Setup 2�2�2 DIMM Installation Step 1 Unlock the DIMM socket by pressing the retaining clips outward. Step 2 Insert the memory module into the slot. Make sure that the DIMM notch is accurately positioned.

  • Page 26: 2�3 Removing And Installing The Top Cover

    SB101-LB User Manual Chapter 2. Hardware Setup 2�3 Removing and Installing the Top Cover Step 1 Press the release button x 2 on the top cover. Step 2 Slide the cover toward the rear panel and pull upward to remove.

  • Page 27: 2�4 Removing And Installing The Power Supply Unit Module

    SB101-LB User Manual Chapter 2. Hardware Setup 2�4 Removing and Installing the Power Supply Unit Module 2�4�1 Removing the Power Supply Unit Step 1 Press the latch and hold the tray on the module. Step 2 Pull the module out of the system barebone.

  • Page 28: 2�5 Removing And Installing The Fan Module

    SB101-LB User Manual Chapter 2. Hardware Setup 2�5 Removing and Installing the Fan Module 2�5�1 Removing the Fan Pull the fan module out of the fan slot. 2�5�2 Installing the Fan Insert the fan module into the fan slot. NOTE The fan should be blowing toward the rear end of the chassis.

  • Page 29: 2�6 Removing And Installing The Hard Disk Drive

    SB101-LB User Manual Chapter 2. Hardware Setup 2�6 Removing and Installing the Hard Disk Drive 2�6�1 Removing and Installing the Hard Disk Drive Tray Step 1 Press the release button the tray lever. The lever will be ejected from the tray.

  • Page 30: 2�7 Removing And Installing The Hdd Backplane Module

    SB101-LB User Manual Chapter 2. Hardware Setup 2�7 Removing and Installing the HDD Backplane Module 2�7�1 Removing the HDD Backplane Step 1 Detach the cables & HDDs from the system. Step 2 Adjust the hook on the side of the backplane to detach it from the system.

  • Page 31: 2�8 Removing And Installing The Riser Card

    SB101-LB User Manual Chapter 2. Hardware Setup 2�8 Removing and Installing the Riser Card 2�8�1 Removing the Riser Card Step 1 Loosen the captive screw. Step 2 Remove the riser card from the system. 2�8�2 Installing the Riser Card Step 1 Align and insert the riser card with bracket into the riser card slot.

  • Page 32: 2�9 Tool-Less Slide Blade Installation

    SB101-LB User Manual Chapter 2. Hardware Setup 2�9 Tool-less Slide Blade Installation 1. Release and detach the inner rail from the slide. PUSH...
  • Page 33 SB101-LB User Manual Chapter 2. Hardware Setup 2. Attach the inner rail to the barebone. Click!
  • Page 34 SB101-LB User Manual Chapter 2. Hardware Setup 3. Attach the outer rail to the rack. Click! Click! PUSH...
  • Page 35 SB101-LB User Manual Chapter 2. Hardware Setup 4. Pull out the middle channel until the ball bearing retainer is locked forward. CAUTION Verify ball bearing retainer is locked forward.
  • Page 36 SB101-LB User Manual Chapter 2. Hardware Setup 5. Slide the release tab and push barebone into rack. Make sure the barebone is completely installed onto the rack. NOTE Tool-less rails vary per order. The rail in this manaul may not exactly match the rail for...

  • Page 37: Chapter 3� Hardware Settings

    Chapter 3� Hardware Settings SB101-LB User Manual Chapter 3.Hardware Settings This section describes the jumpers, internal connectors, and internal LEDs settings in the server barebone. 3�1 Motherboard Block Diagram...

  • Page 38: 3�2 Content List

    Chapter 3.Hardware Settings SB101-LB User Manual 3�2 Content List Connector/Jumper/Header Location Connector/Jumper/Header Location Ethernet (Single LAN1, LAN2 Intruder JINTRUDER Port) Ethernet (Dual Port) RJ45 PMBUS JPMBUS USB Port (Dual Port ) USB3.0 SPI ROM Socket JSPI COM Port Speaker JSPKR1...

  • Page 39: 3�3 Motherboard Layout

    SB101-LB User Manual Chapter 3.Hardware Settings 3�3 Motherboard Layout JPMBUS JDIMMG0 JPWR2 JDIMMG1 JDIMMH0 JDIMMA 0 JDIMMA 1 JDIMMH1 JDIMMB0 JPWR1 JDIMMB1 VG A RTL8201EL JVGA_INT RJ45& JCPU1 JCPU_XDP USB3.0 JCPU0 RJ45 (LAN2) RJ45 (LAN1) JDIMMF1 JDIMMF0 JDIMME1 JDIMMD1 JDIMME0...

  • Page 40: 3�4 Connector And Jumper

    Chapter 3.Hardware Settings SB101-LB User Manual 3�4 Connector and Jumper JDIMMG0 JDIMMG1 JDIMMH0 JDIMMA 0 JDIMMA 1 JDIMMH1 JDIMMB0 JDIMMB1 JDIMMD1 JDIMMD0 JCPU1 JDIMMC1 JDIMMC0 JCPU0 JPG_LOCK1 JDIMMF1 JDIMMF0 JDIMME1 JDIMMD1 JDOM_PWR JPWR3 JDIMME0 JDIMMD0 JDIMMC1 JDIMMC0 JPG_LOCK1 JBAT SATA2...
  • Page 41 SB101-LB User Manual Chapter 3.Hardware Settings 15 JUSB_INT 49 a J19 52 b J17 49 b J20 52 c J18 PWM4 HM_TD7- FAN7_TACH +12V HM_TD7+ 53 a J11 53 b J12 53 c J13 53 d J14 53 e J15...
  • Page 42 Chapter 3.Hardware Settings SB101-LB User Manual JDIMMG0 JDIMMG1 JDIMMH0 JDIMMA 0 JDIMMA 1 JDIMMH1 JDIMMB0 JDIMMB1 JCPU1 JTPM JCPU0 JSGPIO JSSGPIO JDIMMF1 JDIMMF0 JCMOS JDIMME1 JDIMMD1 JNTB JDIMME0 JDIMMD0 JDIMMC1 JDIMMC0 JSPI I210 I217 JSPKR1 JTPM JBAT JSGPIO JSSGPIO JCMOS...
  • Page 43 SB101-LB User Manual Chapter 3.Hardware Settings 40 JNTB 43 a JLAN1 43 b JLAN2 JNTB Setting Short Downstream port Open Upstream port (Default) 48 J10...
  • Page 44 Chapter 3.Hardware Settings SB101-LB User Manual 18 JLPC_DP JDIMMG0 JDIMMG1 JDIMMH0 JDIMMA 0 JDIMMH1 JDIMMA 1 JDIMMB0 JDIMMB1 JCPU1 JCPU0 JDIMMF1 JDIMMF0 JDIMME1 JDIMMD1 JDIMME0 JDIMMD0 JDIMMC1 JDIMMC0 JPCH_GPIO JLPC_DP CN 1 20 JBMC_DP JNGFF JBMC_DP JLCM JPCH_GPIO JLPC_DP CN 1...
  • Page 45 SB101-LB User Manual Chapter 3.Hardware Settings 47 J5 50 a CN1 50 b CN2 SFF-8643 CONN A1.NC C1.SIO1_SAS_DOUT A2.SIO1_SAS_CLK C2.GND A3.GND C3.GND A4.SAS_EXP_RX_P6 C4. SAS_EXP_TX_P6 A5. SAS_EXP_RX_N6 C5. SAS_EXP_TX_N6 A6.GND C6.GND A7. SAS_EXP_RX_P7 C7. SAS_EXP_TX_P7 A8. SAS_EXP_RX_N7 C8. SAS_EXP_TX_N7 A9.GND C9.GND...
  • Page 46 Chapter 3.Hardware Settings SB101-LB User Manual 51 JNGFF 1. GND 2. VCC3_3_2 3. GND 4. VCC3_3_4 5. PERn3 6. NC 7. PERp3 8. NC 9. GND 10. DAS_DSS#(O)(OD) 11. PETn3 12. VCC3_3_12 13. PETp3 14. VCC3_3_14 15. GND 16. VCC3_3_16 17.
  • Page 47 SB101-LB User Manual Chapter 3.Hardware Settings 6 JPWR 1 JDIMMG0 JPWR2 JDIMMG1 JDIMMH0 JDIMMA 0 +12V JDIMMA 1 JDIMMH1 JDIMMB0 JPWR1 +12V JDIMMB1 +12V JVGA_INT +12V RJ45& JCPU1 USB3.0 JCPU0 RJ45 (LAN2) RJ45 7 JPWR 2 (LAN1) JDIMMF1 JDIMMF0 JDIMME1...

  • Page 48: 3�5 System Leds

    Chapter 3.Hardware Settings SB101-LB User Manual 3�5 System LEDs 3�5�1 Front Panel LED Green System is on. Power System is off. Yellow (Blinking) Disk activity detected. Hard Disk Drive No disk activity detected. LAN1 activity detected. Yellow (Blinking) LAN1 LAN1 is not active.

  • Page 49: Rear Panel Led

    SB101-LB User Manual Chapter 3.Hardware Settings 3�5�2 Rear Panel LED Green (Blinking) LAN* activity detected. LAN* (Right) LAN* is not active. LAN cable is not connected. 100M: Green LAN* (Left) Status LED 10M/ No connection: Off Green (Blinking) LAN1 activity detected.

  • Page 50: Internal Leds

    Chapter 3.Hardware Settings SB101-LB User Manual 3�5�3 Internal LEDs LED4 LED1 LED3 LED2 Heart Beat On (Blinking) BMC activity detected. (LED4) BMC is not active. SYS PG LED System power is ready. (LED2) System power is not ready. RSMRST PG LED Resume Well Reset is ready.

  • Page 51: 3�6 Hdd Backplane

    SB101-LB User Manual Chapter 3.Hardware Settings 3�6 HDD Backplane 3�6�1 Backplane Layout Top view JPWR2 JPWR1 SASHD JSGPIO_SET CPLD Bottom view HDD1 HDD2 HDD3 HDD4 3�6�2 Connector and Jumper Connector Description Comment Mini-SAS HD 36 pin vertical MiniSAS-HD SAS host connection...

  • Page 52: Chapter 4. Bios Configuration Settings

    Chapter 4. BIOS Configuration Settings Chapter 4 BIOS Configuration Settings SB101-LB User Manual This chapter demonstrates how to configure the UEFI BIOS settings in your system device. You can enter the BIOS screen during system startup. To enter BIOS configuration settings, •...

  • Page 53: 4�2 Bios Setup

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4�2 BIOS Setup 4�2�1 BIOS Menu Press  and  to select the options of the menu bar. Press Enter to access the option screen. Menu Description Displays system information such as CPU bus speed, system...
  • Page 54 Chapter 4 BIOS Configuration Settings SB101-LB User Manual Step 2 There will be a message “Entering SETUP” displayed on the diagnostics screen. CAUTION For the official released version, the last digit of the BIOS version must end in an “0.“...
  • Page 55 SB101-LB User Manual Chapter 4 BIOS Configuration Settings Step 4 Load Optimal Default setting. Step 5 Save the setting and exit the BIOS setup utility.

  • Page 56: 4�3 Main

    Chapter 4 BIOS Configuration Settings SB101-LB User Manual 4�3 Main Main Option Key: 4�3�1 Main Option Key Description Language Configures the language used for your BIOS settings. System time Configures the current time. System date Configures the current date.

  • Page 57: 4�4 Advanced

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4�4 Advanced Advanced Option Key: 4.4.1 Peripheral Configuration Configure periperhal devices. Peripheral Configuration Serial Port A Auto Enable Disable Serial Port B Serial Port C Auto Enable Disable Base I/O Address Interrupt...

  • Page 58: Pch Sata Configuration

    Chapter 4 BIOS Configuration Settings SB101-LB User Manual 4.4.2 PCH SATA Configuration Select the SATA controller and hard disk drive type installed in your system. PCH SATA Configuration SATA Controller Enable Disable HDC Configure As AHCI RAID SATA Speed 1.0 Gb/s 3.0 Gb/s...

  • Page 59: Usb Configuration

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4.4.5 USB Configuration Configure the USB support USB Configuration USB BIOS Support Enable Disable UEFI Only XHCI Pre-Boot Enable Disable Driver XHCI Enable Disable Auto Smart Auto XHCI Streams Enable Disable EHCI 1...

  • Page 60: 4.4.8 Advanced Power Management Configuration

    Chapter 4 BIOS Configuration Settings SB101-LB User Manual 4.4.8 Advanced Power Management Configuration Displays and provides option to change Power Management Settings. Advanced Power Management Configuration EIST (GV3) Enable Disable Config TDP Enable Disable IOTG Setting Enable Disable Uncore CLR Freq...

  • Page 61: 4.4.10 Qpi Configuration

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4.4.10 QPI Configuration Displays and provides option to change the QPI Settings. QPI Configuration Link Speed Mode Slow Fast Link Frequency Auto 6.4GT/s 8.0GT/s 9.6GT/s Auto Select Limited QPI General Legacy VGA...

  • Page 62: 4.4.11 Memory Configuration

    Chapter 4 BIOS Configuration Settings SB101-LB User Manual MMIOL Resources Min=0, Max=8 Allocation Ratio Disable Ports and IIO without memory hotplug IIO Disable Disable Ports Only with memory QPI Per Socket hotplug CPU 0/ CPU1 Configuration Socket IO Min=0x0, Max=0x10...

  • Page 63: Iio Configuration

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings RMT On Cold Fast Auto Enable Disable Boot BDAT Enable Disable ADR Mode Enable Disable Memory Topology Set Throttling Disable OLTT CLTT Mode DIMM Temp Stat Min=0,Max=255 Memory Thermal Auto Phase Enable...
  • Page 64 Chapter 4 BIOS Configuration Settings SB101-LB User Manual Auto PCI-E Port Enable Socket 0 Disable PcieD01F0 - Port PCI-E Port Enable Disable Link Socket 0 PcieD01F1 - Port Auto Gen 1 (2.5 GT/s) Socket 0 Link Speed Gen 2 (5 GT/s)

  • Page 65: Console Redirection

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4�4�13 Console Redirection Displays and provides Console Redirection Settings. Console Redirection Console Serial Enable Disable Redirect 4�4�14 System Event Log Press Enter to view or change the event log configuration. System Event Log...

  • Page 66: Oemboard Function

    Chapter 4 BIOS Configuration Settings SB101-LB User Manual BMC Warmup Time Min=0, Max=240 Boot Option Enable Disable Support Wait For BMC Enable Disable Virtual Device Watchdog Timer Enable Disable Support Watchdog Timer Min=0, Max=240 Timeout No Action Power Down Hard...

  • Page 67: 4�5 Security

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4�5 Security Security Option Key: 4�5�1 Set Supervisor password Set Supervisor Password: Install or change the password and the length of the password must be greater than one character. Set Supervisor password...

  • Page 68: 4�6 Power

    Chapter 4 BIOS Configuration Settings SB101-LB User Manual 4�6 Power Power Option Key: 4�6�1 Power Wake on PME: Determines the action taken when the system power is off and the PCI Power Management Enable wake up event occurs. Auto Wake on S5: Auto Wake on S5, By Day of Month or Fixed time of every day.

  • Page 69: 4�7 Boot

    SB101-LB User Manual Chapter 4 BIOS Configuration Settings 4�7 Boot Boot Option Key: 4�7�1 Boot Boot Type: Select boot type to Dual type, Legacy type or UEFI type. Quick Boot: Allows InsydeH20 to skip certain tests while booting. This will decrease the time to boot the system.
  • Page 70 Chapter 4 BIOS Configuration Settings SB101-LB User Manual Boot Boot Type Dual Boot Type Legacy Boot Type UEFI Boot Type Quick Boot Enable Disable Quiet Boot Enable Disable Network Stack Enable Disable PXE Boot Enable Disable Capability USB Boot Enable...

  • Page 71: Chapter 5. Bmc Configuration Settings

    Chapter 5. BMC Configuration Settings SB101-LB User Manual Chapter 5. BMC Configuration Settings Insert Ethernet LAN cable into the BMC LAN port. There are two methods to setup BMC IP: BMC management port 5�1 Method 1 (Use the BIOS Setup) Step 1 BIOS SETUP ...

  • Page 72: 5�2 Method 2 (Use A Dos Tool - Syscheck)

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�2 Method 2 (Use a Dos Tool - Syscheck) Step 1 Type in "sc –lanset." Step 2 Modify the IP setting. NOTE Type 1 for selecting static IP Mode and type 2 for selecting DHCP Mode.

  • Page 73: 5�3 Connect To Bmc

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�3 Connect to BMC NOTE This feature works with JAVA 6 Runtime installed Console Environment. The IP address below is an example using default IP setting. Users are allowed to change the IP address for individual purposes Step 1 Open the browser then type default BMC IP address: 192.168.22.22...

  • Page 74: 5�4 Web

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4 Web UI 5�4�1 Dashboard The Dashboard page gives the overall information about the status of a device. To open the Dashboard page, click Dashboard from the menu bar. A sample screenshot...

  • Page 75: Field Replaceable Unit(Fru)

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4�2 Field Replaceable Unit(FRU) The FRU Information Page displays the BMC FRU file information. The information displayed in this page is Basic Information, Common Header Information, Chassis Information, Board Information and Product Information of the FRU device.

  • Page 76: Server Health

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4�3 Server Health Sensor Readings All sensor related information will be displayed here. Double click on a record to toggle (ON / OFF) the live widget for that particular sensor. Event Log Events generated by the system will be logged here.

  • Page 77: 5.4.4 Configuration

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5.4.4 Configuration Active Directory Settings The 'Active Directory' is currently disabled. To enable Active Directory and configure its settings. Click on 'Advanced Settings' button. DNS Server Settings Manage DNS settings of the device.
  • Page 78 SB101-LB User Manual Chapter 5. BMC Configuration Settings Mouse Mode Settings Redirection console mouse mode settings can be modified here. NCSI Settings The following options are for configuring the channel number and package ID information for the NCSI interface. Network Settings...
  • Page 79 SB101-LB User Manual Chapter 5. BMC Configuration Settings Network Link Configuration Manage network link settings of the device. PAM Ordering This page is used to configure the PAM Ordering for the user authentication. PEF Management Use this page to configure Event Filter, Alert Policy and LAN Destination.
  • Page 80 SB101-LB User Manual Chapter 5. BMC Configuration Settings SMTP Settings Manage SMTP settings of the device. SSL Certificate Configuration This page is used to configure SSL certificate into the BMC. Using this, the device can be accessed in a secured mode. Upload SSL option is used to upload the certificate and private key file into the BMC.

  • Page 81: Remote Control

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4�5 Remote Control Console Redirection Press the button to launch the redirection console and manage the server remotely. Power Control and Status The current server power status is shown below. To perform a power control operation, select one of the options below and press "Perform Action."...
  • Page 82 SB101-LB User Manual Chapter 5. BMC Configuration Settings Environmental setting: Press “ALT+C” for local and remote OS mouse control switching.

  • Page 83: Auto Video Recording

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4�6 Auto Video Recording Triggers Configuration This page allows the user to configure the events that will trigger the auto video recording function of the KVM server. Video Recording This page shows a list of available recorded video files on the BMC. Select a video and click the "Play Video"...

  • Page 84: Maintenance

    SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4�7 Maintenance Preserve Configuration This page allows you to select the specific configuration items to be preserved in the cases of "Restore Configuration," and "Firmware Update without Preserve Configuration option." Restore Configuration This page allows you to restore the default configuration for your device.
  • Page 85 SB101-LB User Manual Chapter 5. BMC Configuration Settings 5�4�8 Firmware Update Firmware Update Upgrade firmware of the device. Press "Enter Update Mode" to put the device in update mode. Image Transfer Protocol The following option allows you to configure firmware image protocol information.

  • Page 86: Chapter 6� Technical Support

    Chapter 6� Technical Support Taiwain, Global Headquarters South California, United States Address: No� 152, Section 4, Address: 21808 Garcia Lane Linghang N� Rd, Dayuan District, City of Industry, CA 91789, Taoyuan City 337, Taiwan United States Tel: +886-3-433-9188 Toll free: +7-4997019998 Fax: +886-3-287-1818 Tel: +1-909-895-8989 Sales Email: sales@aicipc�com�tw...
