  • Page 1 SB401-LB Storage Server Barebone User's Manual UM_SB401-LB_v4_070218...

  • Page 2: Table Of Contents

    2.9 Removing and Installing the RJ45 Module ........27 2.10 Tool-less Blade Slide Installation Instruction ........30 Chapter 3. Motherboard Settings ..........32 3.1 Motherboard Block Diagram ............32 3.2 Motherboard Layout ................33 3.3 Motherboard Content List ..............34 3.4 Internal Connectors/Jumpers ............35 3.5 System LEDs ..................45 Chapter 4.

  • Page 3: Removing And Installing The Rj45 Module

    There two types of RJ45 Module. Type Step 1 Remove PCI Bracket Slot Cover. Step 2 Take the RJ45 module insert the either one slot onto the chassis. Be sure the RJ45 module insert to chassis properly. SB401-LB User's Manual...
  • Page 4 Step 1 Punch out additional flashing on the I/O shield to make room for RJ45 module. Step 2 Align the module to the top and botton of the I/O shield for correct direction. Step 3 Secure the RJ45 module on the I/O shield using the screws. SB401-LB User's Manual...
  • Page 5 2.9.2 Configure the RJ45 function setting Insert one end of the cable into port LAN3 of the barebone. Insert the other end of the LAN4 cable into the corresponding port on site of the barebone. 1. Type 2. Type SB401-LB User's Manual...

  • Page 6: Tool-Less Blade Slide Installation Instruction

    Chapter 2 Hardware Setup 2.10 Tool-less Blade Slide Installation Instruction 2.10.1 Release and detach the inner rail from the slide. PUSH SB401-LB User's Manual...
  • Page 7 Chapter 2 Hardware Setup 2.10.2 Attach inner rail to the system. Click! 2.10.3 Attach outer rail to the rack. Click! Click! PUSH SB401-LB User's Manual...

  • Page 8: Chapter 3. Motherboard Settings

    Chapter 3 Motherboard Settings Chapter 3. Motherboard Settings This section describes the jumpers, internal connectors, and internal LEDs setting on Libra motherboard. Motherboard layout and important jumper settings are listed below. 3.1 Motherboard Block Diagram SB401-LB User's Manual...

  • Page 9: Motherboard Layout

    PCIe slot3 JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB PCIe slot2 JLPC_DP SATA6 SATA5 I210 I217 JSPKR1 SATA8 SATA7 PCIe slot1 JUSB_INT JNGFF JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 SB401-LB User's Manual...

  • Page 10: Motherboard Content List

    Chapter 3 Motherboard Settings 3.3 Motherboard Content List SB401-LB User's Manual...

  • Page 11: Internal Connectors/Jumpers

    JDIMMF1 JPWR3 JDIMMF0 JDIMME1 JDIMMD1 JDIMME0 JDIMMD0 JDIMMC1 JDIMMC0 JPG_LOOK1 JSPI JBUZZER JDOM_PWR JPWR3 JBMC_GPIO JTPM JSGPIO JSSGPIO JCMOS JPCH_GPIO JNTB JLPC_DP JUSB_INT JSPKR1 JNGFF JUSB_INT JFRNT_SSI JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 SB401-LB User's Manual...
  • Page 12 Chapter 3 Motherboard Settings JPG_LOOK1 JDOM_PWR JPWR3 JUSB_INT JFRNT_SSI SB401-LB User's Manual...
  • Page 13 JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB JLPC_DP SATA6 SATA5 JSPKR1 SATA8 SATA7 JNGFF JUSB_INT JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JTPM JSGPIO JSSGPIO JCMOS JNTB JSPKR1 JLAN1 JLAN2 SB401-LB User's Manual JCOM4...
  • Page 14 Chapter 3 Motherboard Settings JTPM JSGPIO JSSGPIO +3.3V PCH_SPI_MISO PCH_SPI_MOSI PCH_SPI_CLK PCH_GPIO23 PCH_SPI_CS1_N PCH_LDRQ0_N PCH_SPI_CS2_N RST_PLTRST_N JSPKR1 JLAN2 JLAN1 JCOM4 SB401-LB User's Manual...
  • Page 15 JDOM_PWR JPWR3 JBMC_GPIO JTPM JBAT JSGPIO SATA2 SATA1 JSSGPIO JCMOS JPCH_GPIO SATA4 SATA3 JNTB JLPC_DP SATA6 SATA5 JSPKR1 SATA8 SATA7 JNGFF JUSB_INT JBMC_RST JBMC_DIS JBMC_DP JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JINTRUDER JBMC_I2C1 JPCH_GPIO JLPC_DP JNGFF JBMC_DP JLCM SB401-LB User's Manual...
  • Page 16 Chapter 3 Motherboard Settings JLPC_DP PCH_GPIO21 JPCH_GPIO PCH_GPIO27 JBMC_DP JLCM SB401-LB User's Manual...
  • Page 17 Chapter 3 Motherboard Settings SB401-LB User's Manual...
  • Page 18 Chapter 3 Motherboard Settings JNGFF SB401-LB User's Manual...
  • Page 19 JBMC_I2C10 JBUZZER JPWR3 JDOM_PWR PCIe slot4 LSISA JBMC_GPIO JTPM S3008 PCIe slot3 JSGPIO JSSGPIO JCMOS JPCH_GPIO JNTB PCIe slot2 JLPC_DP I210 I217 JSPKR1 PCIe slot1 JUSB_INT JNGFF JBMC_RST JBMC_DIS JBMC_DP JINTRUDER JFRNT_SSI JLAN1 JLAN2 JCOM4 JLCM JBMC_I2C1 SB401-LB User's Manual...
  • Page 20 Chapter 3 Motherboard Settings JPWR1 JVGA_INT +12V DACROA DACGOA +12V DDC_DATAO +12V DACBOA AHSYNCO +12V DVO_5V AVSYNCO DDC_CLKO JBMC_I2C10 JBUZZER JBMC_GPIO BMC BUZZER- I2C10SDA I2C10SCL JBMC_I2C1 SB401-LB User's Manual...

  • Page 21: System Leds

    Chapter 3 Motherboard Settings 3.5 System LEDs 3.5.1 Front Panel LED 3.5.2 Rear Panel LED SB401-LB User's Manual...
  • Page 22 Chapter 3 Motherboard Settings 3.5.3 Internal LEDs LED4 LED1 LED3 LED2 SB401-LB User's Manual...

  • Page 23: Chapter 4. Bios Configuration Settings

    Press ESC to run the setup procedure. There will be a message “Entering SETUP” displayed on the diagnostics screen. Caution: For the official released version, the last digit of the BIOS Version must end in an "0." SB401-LB User's Manual...
  • Page 24 Chapter 4 BIOS Configuration Settings Identify the BIOS Version. Load Optimal Default setting. Save the setting and exit the BIOS setup utility. SB401-LB User's Manual...

  • Page 25: Updating Bios

    Chapter 4 BIOS Configuration Settings 4.1 Updating BIOS Important Notes: To identify the current BIOS version, please check the BIOS setup. SB401-LB User's Manual...
  • Page 26 To use this utility, you must include the flash.bat , H2OFFT-D.exe, and bin file in the same folder. Please follow the instructions to update whole flash part: Execute flash.bat to update Flash in the DOS environment. Reboot system. SB401-LB User's Manual...

  • Page 27: Bios Features

    Sets passwords and security functions. Power Configures power management functions. Boot Sets boot options such as Quick Boot or USB Boot. Exit Allows user to save or discard BIOS changes, and load optimal or custom default settings. SB401-LB User's Manual...
  • Page 28 Chapter 4 BIOS Configuration Settings 4.2.1 Main 4.2.2 Advanced SB401-LB User's Manual...
  • Page 29 Console Redirection: Console Redirection Settings. System Event Log: Press Enter to view or change the event log configuration. SPS ME ICC Configuration: Config Integrated Clock Control, for overclocking operations and dynamic ICC control. H2O IPMI Configuration OEMBOARD Function: OEMBOARD Function. SB401-LB User's Manual...
  • Page 30 6.0 Gb/s SATA Port 0 HotPlug Disabled Enabled SATA Port 1 HotPlug Disabled Enabled SATA Port 2 HotPlug Disabled Enabled SATA Port 3 HotPlug Disabled Enabled SATA Port 4 HotPlug Disabled Enabled SATA Port 5 HotPlug Disabled Enabled SB401-LB User's Manual...
  • Page 31 On Board First USB Configuration USB BIOS Support Disabled Enabled UEFI Only XHCI Pre-Boot Driver Disabled Enabled XHCI Disabled Enabled Auto Smart Auto XHCI Streams Disabled Enabled EHCI 1 Disabled Enabled EHCI 2 Disabled Enabled Pre-Port Control Disabled Enabled SB401-LB User's Manual...
  • Page 32 Execute Disable Bit Disabled Enabled Enable LTSX Disabled Enabled Disabled Enabled Enable SMX Disabled Enabled MSR Lock Control Disabled Enabled Hardware Prefetcher Disabled Enabled Adjacent Cache Prefetch Disabled Enabled DCU Streamer Prefetcher Disabled Enabled AES-NI Disabled Enabled SB401-LB User's Manual...
  • Page 33 ENERGY_PERF_BIAS_CFG mode Tuning PERF Energy Perf Power Disabled Balanced Perf BIAS Performance Balanced Power Tuning Power Enabled Common RefCode Configuration MMIO High Base MMIO High Size 256G 128G 512G 1024G Isoc Mode Disabled Enabled Numa Disabled Enabled SB401-LB User's Manual...
  • Page 34 MMIOL Resources Allocation Step=1,Min=0,Max=8 Ratio IIO Disable Disable Ports and IIO without memory hotplug Disable Ports Only with memory hotplug Socket IO Alignment (Hex) Step=0x0,Min=0x0,Max=0x10 Socket IO Length (Hex) Step=0x0,Min=0x0,Max=0x10000 Socket Alignment (Hex) Step=0x0,Min=0x0,Max=0x20 SB401-LB User's Manual Socket Length (Hex) Step=0x0,Min=0x0,Max=0x100000000...
  • Page 35 Hardware Triggered ADR Memory Topology Memory Thermal Set Throttling Disabled OLTT CLTT Mode DIMM Temp Stat Step=0,Min=0,Max=255 Phase Auto Disabled Enabled Shedding Memory Disabled Mirror Lockstep RAS Mode Configuration Mode Patrol Scrub Disabled Enabled Demand Scrub Disabled Enabled SB401-LB User's Manual...
  • Page 36 4s to 13s 260ms to 17s to 64s 900ms Socket 0 PcieD01F0 - Port Link Speed Auto 0/DMI Gen 1 (2.5 GT/s) Gen 2 (5 GT/s) Gen 3 (8 GT/s) PCI-E Port -6.0 dB DeEmphasis -3.5 dB SB401-LB User's Manual...
  • Page 37 GT/s) PCI-E Port -6.0 dB DeEmphasis -3.5 dB Non-Transpar Transparent ent Bridge Bridge PCIe Port NTB to NTB Definition NTB to RP Disabled Enabled IOU0 Non-Posted Prefetch Disabled Enabled IOU1 Non-Posted Prefetch Disabled Enabled IOU2 Non-Posted Prefetch SB401-LB User's Manual...
  • Page 38 GT/s) PCI-E Port -6.0 dB DeEmphasis -3.5 dB Non-Transpar Transparent -ent Bridge Bridge PCIe Port NTB to NTB Definition NTB to RP IOU0 Non-Posted Prefetch Disabled Enabled SB401-LB User's Manual IOU1 Non-Posted Prefetch Disabled Enabled IOU2 Non-Posted Prefetch Disabled Enabled...
  • Page 39 Disabled Enabled enbaling PCI/PCI Error Enabling : PCI-Ex Error Enable No Corrected Error Disabled Enabled Enable Uncorrected Error Disabled Enabled Enable Fatal Error Enable Disabled Enabled PCIe Correctable Step=1,Min=0,Max=255 error threshold Enable SERR propagation Enable PERR propagation SB401-LB User's Manual...
  • Page 40 Disabled Enabled SDR List IPv6 AutoConfig Disabled Enabled IPv6 Prefix Length Step=1,Min=0, Max=255 SDR List Support Disabled Enabled OEMBoard Function Messiah Function SMBIOS Updated Auto By Utility Halt On Error Disabled Enabled SB401-LB User's Manual Manufacturing Test Mode Disabled Enabled...
  • Page 41 Password: Install or change the password and the length of the password must be greater than one character. Security Option Key: Set Supervisor password Please type in your new password [ Please confirm you new password [ SB401-LB User's Manual...
  • Page 42 PCI Power Management Enable wake up event occurs. Auto Wake on Auto Wake on S5, By Day of Month or Fixed time of every day. Power Option Key: Power Disabled Enabled Wake on PME Disabled Enabled Auto Wake on S5 SB401-LB User's Manual...
  • Page 43 Dual Boot Type Legacy Boot Type UEFI Boot Type Boot Type Disabled Enabled Quick Boot Disabled Enabled Quiet Boot Disabled Enabled Network Stack Disabled Enabled PXE Boot Capability Disabled Enabled USB Boot SB401-LB User's Manual Disabled Enabled EFI Device First...

  • Page 44: Chapter 5. Bmc Configuration Settings

    Insert Ethernet LAN cable into the BMC LAN port. There are two methods to setup BMC IP: BMC management port 5.1 Method 1 (Use the BIOS Setup) Step 1 BIOS SETUP  Server Mgmt  BMC network configuration  Configuration Address source  Static SB401-LB User's Manual...
  • Page 45 Chapter 5 BMC Configuration Settings Step 2 Type in the IP address. Set static IP. SB401-LB User's Manual...
  • Page 46 Chapter 5 BMC Configuration Settings Step 3 Type in the subnet mask address. SB401-LB User's Manual...

  • Page 47: Method 2 (Use A Dos Tool - Syscheck)

    5.2 Method 2 (Use a Dos Tool - Syscheck) Step 1 Type in "sc –lanset." Step 2 Modify the IP setting. Note: type 1 for selecting static IP mode or type 2 for selecting DHCP mode. Step 3 Type in the IP address. SB401-LB User's Manual...

  • Page 48: Connect To Bmc

    Password: admin Note: The default user name and password are in lower-case characters. Note: Users who login with the admin user name and password will have full administrative power. The admin password can be changed after login. SB401-LB User's Manual...

  • Page 49: Web Ui

    5.4 Web UI Dashboard The Dashboord gives the overall information about the status of the deivce and remote server. Field Replaceable Unit (FRU) Information This page gives detailed information for the various FRU devices present in this system. SB401-LB User's Manual...
  • Page 50 This page displays logs of system and audit events for this device (if the options have been configured). Blue Screen of Death (BSOD) This page displays the snapshot of the blue screen captured if the host system crashed since last reboot. SB401-LB User's Manual...
  • Page 51 'Remote Media'. Local and Remote Media are currently disabled. To configure Local or Remote Media Settings. Click the 'Advanced Settings' button. LDAP/E-Directory Settings LDAP/E-Directory is currently disabled. To enable LDAP/E-Directory and configure its settings. Click on 'Advanced Settings' button. SB401-LB User's Manual...
  • Page 52 The following options are for configuring the channel number and package ID information for the NCSI interface. Network Settings Manage network settings of the device. For Windows OS environment, set mode to absolute. For Linux OS environment, set mode to relative SB401-LB User's Manual...
  • Page 53 This page is used to configure virtual media configuration settings for the next redirection session. Services Below is a list of services running on the BMC. It shows current status and other basic information about the services. Select a slot and press "Modify" button to modify the services configuration. SB401-LB User's Manual...
  • Page 54 "Add User." Virtual Media Devices The following option will allow to configure virtual media devices. Below, you can select the number of instances that are be supported for each type of virtual media devices. SB401-LB User's Manual...
  • Page 55 Power Control and Status The current server power status is shown below. To perform a power control operation, select one of the options below and press "Perform Action." Java SOL Press the button to launch the Java SOL. SB401-LB User's Manual...
  • Page 56 Chapter 5 BMC Configuration Settings Environmental setting: Press “ALT+C” for local and remote OS mouse control switching. SB401-LB User's Manual...
  • Page 57 This page shows a list of available recorded video files on the BMC. Select a video and click the "Play Video" button to play the video. Select a video and click the "Download" button to download and save the video. Click the "Delete" button to delete the selected video. SB401-LB User's Manual...
  • Page 58 If none are selected, all the configuration items will be restored to their default values, essentially restoring the device configuration to its factory defaults. System Administrator This page allows the user to enable/disable access and change the password for the System Administrator account. SB401-LB User's Manual...
  • Page 59 Chapter 5 BMC Configuration Settings Firmware Update Firmware Update Upgrade firmware of the device. Press "Enter Update Mode" to put the device in update mode. Image Transfer Protocol The following option allows you to configure firmware image protocol information. SB401-LB User's Manual...

  • Page 60: Updating Bmc Firmware

    SB301C01 A:\ SB301C01>a.bat This is just an example. The latest BMC firmware version is available from the FAE or AIC website. Step 4 After updating the BMC firmware, please turn off and restart the system. Notes: 1. DO NOT USE EMM386 IN DOS ENVIRONMENT WHEN UPDATING FIRMWARE OR YOU WILL GET A FAIL.

  • Page 61: Chapter 6. Hardware Specification

    Chapter 6 Hardware Specification Chapter 6. Hardware Specification This chapter provides a detailed instruction guide on hardware specification. 6.1 HDD Backplane 6.1.1 Placement SB401-LB User's Manual...
  • Page 62 6.1.2 Connector Connector Location JFAN1 JI2C3 JI2C0 JEXP2 JEXP2 JFAN3 JFAN3 JFAN4 JFAN4 JFAN2 JFAN2 JI2C4 JI2C4 JEXP_UART JEXP_UART JMCU_DBG JMCU_DBG JMCU_UART JMCU_UART JPMBUS JPMBUS SASHD3 SASHD3 JPWR1 JPWR1 SASHD2 SASHD2 SASHD1 SASHD1 JPWR2 JPWR2 JFRONT JFRONT SB401-LB User's Manual...
  • Page 63 Chapter 6 Hardware Specification Power Connector – JPWR1 Description Description +12V +12V +3.3V MUTE_L +5VSTBY PSU_N1 PS_ON_L Power Connector – JPWR2 Description Description +12V +12V +12V +12V PMBUS Connector – JPMBUS Description PMBUS_CLOCK PMBUS_DATA SB401-LB User's Manual...
  • Page 64 I2C Connector – JI2C0, JI2C3, JI2C4 Description I2C_CLOCK I2C_DATA FAN Connector – JFAN1, JFAN2, JFAN3, JFAN4 Description I2C_CLOCK I2C_DATA Console for Expander – JEXP_UART Description Description DEBUG_RXD SMART_RXD +12V DEBUG_TXD SMART_TXD Remote Power Control – JMCU_UART Description Description DOWN_RXD UP_RXD DOWN_TXD UP_TXD SB401-LB User's Manual...
  • Page 65 For External LED(-) LED Cathode • FAN Fail LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode • Power Fault LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode SB401-LB User's Manual...
  • Page 66 MUTE Input(-) Active Low • Power/ID LED Description Remark For External LED(+) LED Anode For External LED(-) LED Cathode • Power SW Description Remark Power SW Input(-) Active Low • PMBUS Support Description Remark PMBUS_Disable_N Active Low SB401-LB User's Manual...
  • Page 67 Activity detected Link down Expander alive, 0.833Hz Expander Blink (LED2) Blue (Blinking) (12 seconds per cycle) Expander Heart Bit Blue (Blinking) Expander FW running (LED1) Yellow (On) MCU alive MCU Status (LED3) Yellow (Off) Boot loader mode SB401-LB User's Manual...
  • Page 68 Chapter 6 Hardware Specification 6.1.4 Jumpers JMCU_RST JMCU_RST JMD_SEL JMD_SEL Open Normal, default JMCU_RST Close Reset MCU Open Normal, default JMD_SEL Close Boot loader mode SB401-LB User's Manual...
  • Page 69 Chapter 6 Hardware Specification 6.1.5 Drive Slot Map SB401-LB User's Manual...

  • Page 70: Chapter 7. Technical Support

    Chapter 1 Product Introduction Chapter 1 Product Introduction Chapter 7. Technical Support www.aicipc.com • TAIWAN Tel: +886 3 433 9188 Fax: +886 3 287 1818 Email: sales@aicipc.com.tw • CHINA Tel: +86.21.54961421, +86.21.54961422 Fax: Extension: 608 Email Technical Support: support@aicipc.com • AMERICA - West coast Tel: +1.909.895.8989 Fax: +1.909.895.8999 Email: sales@aicipc.com...
