INSTALLATION
3

3.6.10 Mounting position

Figure 3-15: Mounting position
• Install flow sensor in line with the pipe axis.
• Pipe flange faces must be parallel to each other.
18
www.krohne.com
OPTIFLUX 4000
08/2017 - 4000818505 - HB OPTIFLUX 4000 R05 en
