  • Page 2: Warnings And Legal Information

    Warnings and legal information Legal information and responsibility DEIF takes no responsibility for installation or operation of the unit. If there is any doubt about how to install or operate the unit, the company responsible for the installation or the operation of the unit must be contacted.

  • Page 3: Installation

    Installation and terminals Installation Make sure the unit is installed in a dry and dust free environment. Avoid placing it near to heat, radiation and strong electrical interference sources. The working temperature range of the unit is from -25°C to 70°C. The unit can be installed into an IEC 92 mm DIN (square) or an ANSI C39.1 (4’’...

  • Page 4: Modbus Communication Settings

    Communication The default device address and the default baud rate of the DIN rail meter are 1 and 9600 respectively. Those two default values will always be used for the first minute after the meter is powered on. The device address and the baud rate of the meter will change to the user defined values after the first minute.

  • Page 5: Digital Input (Di)

    I/O module (option) Digital input (DI) An external power supply (16~30 V DC – max load 2 mA) is required for the digital inputs. DI can be used as a pulse counter to monitor switch status or to monitor event sequences. Digital output (DO) Two modes available: alarm output and energy pulse output.
  • Page 6 I/O module (option) Three types of I/O modules with different I/O combinations are available: Relay Output Digital Input AXM-IO1: 6 × DI, 2RO, 1 Power Supply for DI Digital Input Digital Output Analog Output AXM-IO2: AO1+ AO1- AO2+ AO2- DO1 4 ×...

  • Page 7: Din Rail Installation

    Utility software The free utility software DEIF View is a user-friendly real time monitoring and data logging for energy saving and power quality analysis. This software is intended for users to monitor multiple parameters continuously.

  • Page 8: Specifications

    FCT inputs Nominal voltage 100 mV Frequency Nominal frequency 50/60 Hz, Frequency range 45 Hz to 65 Hz Accuracy U, I and F Class 0.2 Harmonic U, I Class 5 DEIF reserves the right to change any of the above.
  • Page 9 Nominal voltage UN L-N 400 V AC, L-L 690 V AC Overload capacity 1500 V continuous, 3250 V for 1min Nominal frequency and range 50/60 Hz, 45 Hz to 65 Hz DEIF reserves the right to change any of the above.
