Multi-instrument Communication,
MIC-2 MKII Quick Start Guide
A/S · Frisenborgvej 33 · DK-7800 Skive · Tel.: +45 9614 9614 · Fax: +45 9614 9615 · info@deif.com · www.deif.com
Document no.:
+45 9614 9614 · Fax: +45 9614 9615 · info@deif.com · www.deif.com
4189320028D
• Warnings and legal information
• Installation and terminals
• Display description
• Operation
• Settings
• Communication
• I/O options
• Alarming
• Utility software
• More information
• Specifications
DEIF A/S · Frisenborgvej 33 · DK-7800 Skive · Tel.: +45 9614 9614 · Fax: +45

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIC-2 MKII and is the answer not in the manual?

Questions and answers

Related Manuals for Deif MIC-2 MKII

Summary of Contents for Deif MIC-2 MKII

  • Page 1 • Specifications DEIF A/S · Frisenborgvej 33 · DK-7800 Skive · Tel.: +45 9614 9614 · Fax: +45 A/S · Frisenborgvej 33 · DK-7800 Skive · Tel.: +45 9614 9614 · Fax: +45 9614 9615 · info@deif.com · www.deif.com Document no.: +45 9614 9614 ·...

  • Page 2: General Information

    About the quick start guide The DEIF unit is not to be opened by unauthorised General purpose personnel. If opened anyway, the warranty will be lost. This quick start guide mainly includes general...

  • Page 3: Installation

    Installation and terminals Installation Make sure the unit is installed in a dry and dust free environment. Avoid placing it near to heat, radiation and strong electrical interference sources. The working temperature range of the unit is from -25°C to 70°C. The unit can be installed into an IEC 92 mm DIN (square) or an ANSI C39.1 (4’’...
  • Page 4 Display...

  • Page 5: Display Description

    Display description Display description Mode indication, shows different modes on the display Displays metering data Displays energy data and real-time clock Item label, U: voltage; I: current; P: active power, etc. Item icon, Unbalance, THD, TDD, MAX, MIN Display the percentage of the load current to the nominal current. Four quadrant energy icon and icon for inductive or capacitive load Display the three phases and N Energy icon: Imp, Total, Net, Exp...

  • Page 6: Operation

    Operation > Enter Mode selection Press simultaneously to enter the mode selection screen. > Enter > Enter Press to change the mode (Meter – Max/Min – Demand – Harmonic > Enter > Enter – Setting – Digital I/O). Enter the mode by pressing .
  • Page 7 Settings Enter the setting mode in the mode selection screen. Before accessing the parameter setting mode, a four digit password is required. The default password is 0000. Insert the correct password and press > Enter 4 options are available in the parameter selection page: •...
  • Page 8 Communication The unit has a standard RS485 communication port and optional Ethernet or Profibus communication modules. The unit supports dual communication which means the RS485 serial communication can be used together with either an Ethernet or a Profibus connection. Modbus communication settings The communication terminals are A, B, S (14, 15, 16).

  • Page 9: Digital Input (Di)

    I/O module (option) Digital input (DI) An external power supply (16~30 V DC – max load 2 mA) is required for the digital inputs. DI can be used as a pulse counter to monitor switch status or to monitor event sequences. Digital output (DO) Two modes available: alarm output and energy pulse output.
  • Page 10 I/O module (option) Three types of I/O modules with different I/O combinations are available: Relay Output Digital Input AXM-IO1: 6 × DI, 2RO, 1 Power Supply for DI Digital Input Digital Output Analog Output AXM-IO2: AO1+ AO1- AO2+ AO2- DO1 4 ×...

  • Page 11: Utility Software

    Please refer to MIC-2 MKII user’s manual section 4.4 for details. Utility software The free utility software DEIF View is a user-friendly real time monitoring and data logging for energy saving and power quality analysis. This software is intended for users to monitor multiple parameters continuously. It allows for real-time monitoring and maintenance.

  • Page 12: Specifications

    FCT inputs Nominal voltage 100 mV Frequency Nominal frequency 50/60 Hz, Frequency range 45 Hz to 65 Hz Accuracy U, I and F Class 0.2 Harmonic U, I Class 5 DEIF reserves the right to change any of the above.

  • Page 13: Auxiliary Power Supply

    Specifications Auxiliary power supply 100 to 415 V AC +/-10 % 50/60 Hz 100 to 300 V DC +/-10 % ≤ 5 VA Consumption DEIF reserves the right to change any of the above.
