APPENDIX F - MODBUS REGISTER MAP
Absolute Register Address Description
30176/40176
30177/40177
30178/40178
30179/40179
30180/40180
30181/40181
30182/40182
30183/40183
30184/40184
30185/40185
30186/40186
30187/40187
30188/40188
30189/40189
30190/40190
30191/40191
30192/40192
30193/40193
30194/40194
30195/40195
192
Analog Input Trip Type
Analog Input Trip Level
Analog Input Trip Delay Time
Analog Input Span
Analog Input Offset
Analog Output Function
Analog Output Span
Analog Output Offset
Inline Enable
Inline Delay Time
Bypass Feedback Time
Keypad Stop
Modbus Timeout Enable
Modbus Timeout
CT Ratio
Auto Start
Energy Saver Enable
Heater / Anti-Windmill Enable
Heater / Anti-Windmill Level
Starter Type
Range
0: Low – Fault below preset level
1: High – Fault above preset level
0 – 100
1 – 900
1 – 100
0 – 99
0: Off (no output)
1: 0 – 200% Current
2: 0 – 800% Current
3: 0 – 150% Voltage
4: 0 – 150% Overload
5: 0 – 10kW
6: 0 – 100kW
7: 0 – 1MW
8: 0 – 10MW
9: 1 – 100% Analog Input
10: 0 – 100% Firing
11: Calibration (full output)
1 – 125
0 – 99
0: Disabled
1: Enabled
10 – 100
1 – 50
0: Disabled
1: Enabled
0: Disabled
1: Enabled
1 – 120
0: 72:1
1: 96:1
2: 144:1
3: 288:1
4: 864:1
5: 2640:1
6: 3900:1
7 5760:1
8: 8000:1
9: 14400:1
10: 28800:1
11: 50:5
12: 150:5
13: 250:5
14: 800:5
15: 2000:5
16: 5000:5
0: Disabled
1: Start after power applied
2: Start after fault reset
3: Starter after power applied and after
fault reset
0: Disabled
1: Enabled
0: Disabled
1: Enabled
1 – 40
0: Normal (Outside Delta)
1: Inside Delta
2: Wye-Delta
3: Phase Controller
4: Current Follower
5: Across the Line (Full Voltage)
Units
–
%
100 mSec
%
%
–
%
%
–
100 mSec
100 mSec
–
–
Sec
–
–
–
–
% FLA
–
