Appendix C Fault Codes - BENSHAW RediStart EXEXMVRMX3 Series User Manual

Fault Code Description
F00 No fault
F01 UTS Time Limit Expired
F02 Motor Thermal Overload Trip
F03 Slow Speed Time Limit Expired
F04 Speed Switch Time Limit Expired
F05 Motor PTC Overtemperature
F06 Stator RTD Overtemperature
F07 Bearing RTD Overtemperature
F08 Other RTD Overtemperature
F10 Phase Rotation Error, not ABC
F11 Phase Rotation Error, not CBA
F12 Low Line Frequency
F13 High Line Frequency
F14 Input power not single phase
F15 Input power not three phase
F21 Low Line L1-L2
F22 Low Line L2-L3
F23 Low Line L3-L1
F24 High Line L1-L2
F25 High Line L2-L3
F26 High Line L3-L1
F27 Phase Loss
F28 No Line
F29 PORT Timeout
F30 Instantaneous over current (I.O.C.)
F31 Overcurrent
F34 Undercurrent
F35 Power Factor Leading
F36 Power Factor Lagging
F37 Current Imbalance
F38 Ground Fault
F39 No Current at Run
F40 Shorted / Open SCR
F41 Current at Stop
F46 Disconnect Fault
F47 Stack Overtemperature / P.S Failure
F48 Bypass/2M Contactor Fault
F49 Inline Contactor Fault
F50 Control Power Low
F51 Current Sensor Offset Error
F53 Tachometer Signal Loss
F54 BIST Fault
F55 BIST CT Fault
F56 RTD Open or Shorted
F60 External Fault on DI 1 Input
F61 External Fault on DI 2 Input
F62 External Fault on DI 3 Input
F63 External Fault on DI 4 Input
APPENDIX C - FAULT CODES
Controlled Fault Stop Shunt Trip Fault
- -
Y N
Y N
N N
Y N
Y N
Y N
Y N
Y N
N N
N N
N N
N N
N N
N N
Y N
Y N
Y N
Y N
Y N
Y N
N N
N N
N N
N Y
Y N
Y N
Y N
Y N
Y N
N Y
N N
N Y
N Y
N Y
N N
Y N
Y N
N N
N Y
Y N
N N
N N
Y N
N N
N N
N N
Y N
Fault Codes
Auto-Reset Allowed
-
Y
Y
N
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
N
Y
Y
Y
Y
Y
Y
Y
N
N
N
Y
N
N
Y
N
N
N
N
N
Y
Y
Y
Y
181
