710-21968-00A
©2020 Benshaw, Inc
Benshaw retains the right to change specifications and illustrations in text without prior notification.
The contents of this document may not be copied without the explicit permission of Benshaw.
DeviceNet
Communications option
for EMX4e/EMX4i soft starters
User Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BENSHAW EMX4e
Summary of Contents for BENSHAW EMX4e
- Page 1 Communications option for EMX4e/EMX4i soft starters User Guide 710-21968-00A ©2020 Benshaw, Inc Benshaw retains the right to change specifications and illustrations in text without prior notification. The contents of this document may not be copied without the explicit permission of Benshaw.
- Page 2 Product Compatibility This expansion card is suitable for use with EMX4e and EMX4i soft starters. Product description Soft starter name Basic model EMX4e Advanced model EMX4i Parameter Management Parameter lists vary according to the model and version of soft starter.
-
Page 3: Table Of Contents
DeviceNet Card Disclaimer Contents Disclaimer .......................... 1 Warnings ..........................1 Important User Information ....................1 Installation ......................... 2 Configuration ........................3 DeviceNet Polled I/O Structure ..................4 Trip Codes ......................... 6 Parameter Object ....................... 7 Specifications ........................8 Disclaimer The examples and diagrams in this manual are included solely for illustrative purposes. The information contained in this manual is subject to change at any time and without prior notice. -
Page 4: Installation
Installation DeviceNet Card Installation Installing the Expansion Card 1. Push a small flat-bladed screwdriver into the slot in the centre of the expansion port cover, and ease the cover away from the starter. 2. Line up the card with the expansion port. Gently push the card along the guide rails until it clicks into the starter. -
Page 5: Configuration
DeviceNet Card Configuration Feedback LEDs Module and Network LEDs The Module LED indicates the condition of the power supply and device operation. The Network LED indicates status of the communication link between the device and the network Master. LED name LED Status Description Network power off Green... -
Page 6: Devicenet Polled I/O Structure
DeviceNet Polled I/O Structure DeviceNet Card DeviceNet Polled I/O Structure NOTE The available features and parameter details may vary according to the model and software version of the starter. Refer to the soft starter user manual for details of parameters and supported features. Once the EDS file has been loaded, the device must be added to the scanner list with parameters shown in the following table: Parameter... - Page 7 DeviceNet Card DeviceNet Polled I/O Structure Byte Function Value 0 to 7 Status 0 = Unknown (menu open) 2 = Not ready (restart delay, restart temperature check, run simulation, reset input is open) 3 = Ready to start (including warning state) 4 = Starting or Running 5 = Stopping 7 = Tripped...
-
Page 8: Trip Codes
Trip Codes DeviceNet Card Trip Codes Code Trip Type No trip Input A trip Motor overload Heatsink overtemperature L1 phase loss L2 phase loss L3 phase loss Current imbalance Overcurrent Undercurrent Power loss Undervoltage Overvoltage Phase sequence Frequency Incorrect control card FLC out of range EEPROM fail (Parameter out of range) Motor thermistor... -
Page 9: Parameter Object
DeviceNet Card Parameter Object Code Trip Type Current Read Err L1 Current Read Err L2 Current Read Err L3 Remove Mains Volts (mains voltage connected in run simulation) Motor Connection T1 Motor Connection T2 Motor Connection T3 Firing Fail P1 Firing Fail P2 Firing Fail P3 VZC Fail P1... -
Page 10: Specifications
Specifications DeviceNet Card Specifications • Connections Network ....... 5-way male and unpluggable female connector (supplied) Maximum cable size ..................2.5 mm Settings • Address range ....................0 ~ 63 Data rate ................. 125 kB, 250 kB, 500 kB Power • Consumption steady state ................ - Page 12 BENSHAW 615 Alpha Drive Pittsburgh, PA 15238 Phones: (412) 968-0100 Fax: (412) 968-5415 BENSHAW Canada 550 Bright Street Listowel, Ontario N4W 3W3 Phone: (519) 291-5112 Fax: (519) 291-2595 È710-21968-00A|ËÍ 7 1 0 - 2 1 9 6 8 - 0 0 A...
