All parameters
No. Name/Value
0...120% of U
N
2617 USER
DEFINED F4
0.0...500.0 Hz
2618 FW VOLTAGE
0...120% of U
N
2619 DC
STABILIZER
DISABLE
ENABLE
29 MAINTENANCE
TRIG
2901 COOLING FAN
TRIG
0.0...6553.5 kh Time. If parameter value is set to zero, the trigger is
2902 COOLING FAN
ACT
0.0...6553.5 kh Time. Parameter is reset by setting it to zero.
2903 REVOLUTION
TRIG
0...65535 Mrev Millions of revolutions. If parameter value is set to zero, the
2904 REVOLUTION
ACT
0...65535 Mrev Millions of revolutions. Parameter is reset by setting it to
2905 RUN TIME
TRIG
0.0...6553.5 kh Time. If parameter value is set to zero, the trigger is
