drive runs continuously from 18:00 (6 p.m.) on Friday evening to 06:30 (6:30 a.m.) on
Monday morning. Timed function is enabled on the rising edge of digital input DI1.
Parameter
3601 TIMERS ENABLE
3602 START TIME 1
3603 STOP TIME 1
3604 START DAY 1
3605 STOP DAY 1


Settings

Parameter
36 TIMED FUNCTIONS
1001, 1002
1102
1201
1209
1401
1402/1403/1410
1805
4027
4039
4139
4228
8126
www.aotewell.com
Setting
DI1 CMODE
18:00:00
06:30:00
FRIDAY
MONDAY
Additional information
Timed functions settings
Timed start/stop control
Timed EXT1/EXT2 selection
Timed constant speed 1 activation
Timed speed selection
Timed function status indicated through relay output RO 1
Timed function status indicated through relay output RO 2...4.
With option MREL-01 only.
Timed function status indicated through digital output DO
Timed PID1 parameter set 1/2 selection
Selection between different internal (constant) set points for
the process PID control (PID1 parameter set 1)
Selection between different internal (constant) set points for
the process PID control (PID1 parameter set 2)
Timed external PID2 activation
Timed Autochange activation
