158 Program features


Settings

Parameter
Group 14 RELAY OUTPUTS
Group 18 FREQ IN & TRAN OUT
Group 44 PUMP PROTECTION
Group 81 PFC CONTROL;
8123


Diagnostics

Actual signal
0116
0162
0163
0173
Alarm
AUTOCHANGE
PFC I LOCK
INLET LOW, INLET VERY LOW
OUTLET HIGH, OUTLET VERY
HIGH
Fault
PAR PFC REF NEG
PAR PFC IO 1
PAR PFC IO 2
PAR PFC IO 3
INLET LOW, INLET VERY LOW
OUTLET HIGH, OUTLET VERY
HIGH
www.aotewell.com
Additional information
Selections of relay outputs for starting and stopping of
motors
Selections of relay outputs for starting and stopping of
motors (transistor output can be used as an additional
relay)
Pump protection (pressure monitoring) settings
PFC control settings;
PFC/SPFC enable/disable
Additional information
Application block output signal
RO 1 status
TO status
RO 2...4 status. With option MREL-01 only.
PFC Autochange function active
PFC interlocks active
Pressure at pump/fan inlet too low
Pressure at pump/fan outlet too high
Additional information
2007 < 0
Not enough relays parameterized for PFC.
Conflict between group
parameter 8117 and parameter 8118.
Parameter 8127 does not match the PFC motors in
group 14 RELAY OUTPUTS
Allocation of a digital input (interlock) for each PFC
motor not possible
Pressure at pump/fan inlet too low
Pressure at pump/fan outlet too high
sales@aotewell.com
14 RELAY OUTPUTS,
and parameter 8118
