3D Systems ProX User Manual page 9

Ethernet Adaptor (3x): Network connections to service 1 printer and a laptop (for service personnel only) .
A
USB Adapter
B
4-Pin Connector for Oxygen Sensor
C
Nitrogen Inlet: Input for nitrogen supply .
D
Quick-Disconnect Air Fitting: Input for compressed air coming into the MQC System
E
Pressure Regulator (Nitrogen)
F
Pressure Regulator (Air)
G
Pressure Regulator (Air)
H
Transport Filter: The material filter for the ProX® MQC Single Use System .
I
PROX® MQC SINGLE USE SYSTEM COMPONENTS
ProX® MQC Single Use System User Interface
The User Interface, located on the front panel of the ProX
that allows the user to access the functionality of the system . An E-Stop control is located to the right of the screen and the
system power switch is located to the left .
A
3D Systems, Inc.
® MQC Single Use System, consists of a dial-operated menu screen
B
D
C
p/n 77-D005 Rev_A
