Sime Benchmark User Instructions page 7

– Presence button
PROGRAMMING
When programming, the regulator panel must be open.
You can set or display the following values:
• Temperature
• Heating programme
• Day of the week and time
• Current values
• Holiday length
• Return to default values
– Temperature control
– Heating/domestic hot
water programme
The current selection becomes permanent in manual mode
NOTE:
only lasts until the next heating programme switches-in.
1 3
up to
4 1 1
up to
12 14
up to
15 17
up to
18
19
Before correcting the temperature on the regulator, the thermostat valve temperatures
(if provided) must be set to the required temperature first.
In automatic mode, the apparatus switches between the set temperature and the reduced
temperature according to the timer programme. The switch-over of the temperatures in
manual mode is performed manually with the presence button.
Set temperature:
1
Temperature during occupation of the rooms
(basic setting).
Reduced temperature:
2
Temperature during periods of absence or at night.
Domestic hot water temperature:
3
Temperature required for domestic hot water.
The heating programme can be used to pre-set the temperature switch-over times for one
week.
The weekly programme consists of 7 daily programmes.
One day programme allows three heating phases to be set-up. Each phase is defined by a start
and finish time.
Day programme n.8 is for domestic hot water (for setting by the heating engineer only).
If one of the phases is not necessary, enter the same start and finish times.
If the rooms remain unused for long periods of time, you can reduce
the temperature with the presence button, thus saving energy.
When the rooms are occupied, they can be heated by re-pressing the
presence button.
The current selection is shown on the display:
Heating to the set temperature
Heating to the reduced temperature
, in automatic mode it
As soon as the cover is opened,
the display and the functions of
the buttons are switched. The
number in the box indicates the
programme line and can be
selected using the arrow but-
tons.
5
