ENSURE THAT THESE INSTRUCTIONS ARE LEFT
UK
FOR THE USER AFTER COMPLETION OF THE
BENCHMARK SECTION
MERIDIAN
HE 30 C
Installation and

servicing instructions

199838
Please read the Important Notice within
this guide regarding your boiler warranty

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MERIDIAN HE 30 C and is the answer not in the manual?

Questions and answers

Related Manuals for Sime MERIDIAN HE 30 C

Summary of Contents for Sime MERIDIAN HE 30 C

  • Page 1: Servicing Instructions

    ENSURE THAT THESE INSTRUCTIONS ARE LEFT FOR THE USER AFTER COMPLETION OF THE BENCHMARK SECTION MERIDIAN HE 30 C Installation and servicing instructions 199838 Please read the Important Notice within this guide regarding your boiler warranty...

  • Page 2: Safe Handling

    For the first year all of our appliances are protected by our manufacturer’s guarantee which covers both parts and labour. As you would expect from Sime Ltd, it is our aim to provide our valued customers with the best in after sales and service.

  • Page 4: The Benchmark Scheme

    The Benchmark Scheme Sime Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimi- se safety, efficiency and performance.

  • Page 5: Table Of Contents

    IPX4D Meridian HE 30 C: Gas Council number 47-283-46 These appliances comply with the S.E.D.B.U.K. scheme, band “A” CONTENTS DESCRIPTION OF THE BOILER ............... . pag.

  • Page 6: Description Of The Boiler

    European Directives manual. The products manufactured and MERIDIAN HE 30 C are premixed gas con- 2009/142/CE, 2004/108/CE, sold by Sime do not contain any banned densation thermal modules that employ a 2006/95/CE and 92/42/CE.
  • Page 7 TECHNICAL FEATURES MERIDIAN HE 30 C Heat output Nominal (80-60°C) 28.9 Nominal (50-30°C) 31.6 Reduced G20 (80-60°C) Reduced G20 (50-30°C) Reduced G31 (80-60°C) Reduced G31 (50-30°C) Heat input nominal 29.5 Heat input reduced G20/G31 6.2/8.0 Max/min useful yield (80-60°C) 98.0/95. 1 Max/min useful yield (50-30°C) 107.
  • Page 8 FUNCTIONAL DIAGRAM (fig. 2) Expansion vessel Condensate drain trap Limit stat D.H.W. isolation valve Primary exchanger Gas isolation valve C.H. sensor (SM) C.H. flow isolation valve Gas valve C.H. return isolation valve D.H.W. exchanger D.H.W. sensor (SS) Diverter valve Safety thermostat CONNECTIONS Pump with air release vent C.H.
  • Page 9 MAIN COMPONENTS (fig. 3) 1 Control panel 2 Condensate drain trap 3 C.H. sensor (SM) 4 Safety thermostat 5 Ignition electrode NOTE: Analogue pressure gauge 6 Programming clock 7 Primary exchanger 8 Air release vent 9 Limit stat 10 Exhaust temperature sensor 11 Smoke chamber 12 Expansion vessel 13 Air inlet...

  • Page 10: Installation

    INSTALLATION Wall mounting bracket Plastic wall plug (2 Off) Woodscrew (2 Off) Washer (2 Off) Fig. 4 It is important that the boiler is initially FIXING THE WALL seamless steel or copper pipe. filled and started for the first time using MOUNTING BRACKET (fig.
  • Page 11 (H) greater than 3 m. The maxi- mately 30 minutes, regularly checking Sime Ltd recommend only the use of mum flow through the by-pass is about that trapped any air is released. and FERNOX products for the flushing and 300 l/h.
  • Page 12 Model Length of pipe Length of pipe ø 60/100 ø 80/125 H (Horizontal) m L (m) MERIDIAN HE 30 C 1.3 m 10 m 1.2 m 13 m LIST OF ø 60/100 ACCESSORIES LIST OF ø 80/125 ACCESSORIES Coaxial duct kit L. 790 code 8096250 Coaxial duct kit L.
  • Page 13 The boiler is supplied with an electric cable. The outlet terminals for forced-draught Should this require replacement, it must be NOTE: SIME declines all responsibility for injury appliances may be located in the external replaced with one of similar type and dimen- or damage to persons, animals or property, perimeter walls of the building.
  • Page 14 TABLE 4 – If the terminal discharges into a pathway or passageway check that combustion products will not cause nuisance and Terminal position Minimum spacing that the terminal will not obstruct the passageway. Directly below an openable window, air vent –...
  • Page 15 BASIC SYSTEM SYSTEM WITH A DIRECT ZONE AND ROOM THERMOSTAT, OR WITH A REMOTE CONTROL (Code 8092219), KIT EXPANSION REMOTE CONTROL (Code 8092240) AND EXTERNAL SENSOR (Code 8094101) BASIC SYSTEM MULTI-ZONE SYSTEM WITH VALVE, ROOM THERMOSTAT AND EXTERNAL SENSOR (Code 8094101) BASIC SYSTEM MULTI-ZONE SYSTEM WITH PUMP, ROOM THERMOSTATS AND EXTERNAL SENSOR (Code 8094101)
  • Page 16 2. 1 0 BOILER ELECTRICAL (fig. 11) EV 1-2 (24 VDC) (24 VDC) TA (24 VDC) SE (3.3 VDC) FL (12 VDC) (3.3 VDC) TL (3.3 VDC) SF (3.3 VDC) SM (3.3 VDC) TS (3.3 VDC) Fuse (1.6 AT) Room thermostat Ignition transformer External sensor (optional) Pump...

  • Page 17: Characteristics

    CHARACTERISTICS 3. 1 CONTROL PANEL (fig. 12) 2 - DESCRIPTION OF CONTROLS 1 - DESCRIPTION OF DISPLAY ICONS SUMMER MODE ICON OPERATING MODE/RESET Press this key repeatedly to step from standby to summer to winter. The green LED will flash accompa- nied by a audible signal, to indicate that the key has WINTER MODE ICON been pressed.
  • Page 18 ACCESS TO INSTALLER'S PARAMETERS INSTALLER PARAMETERS FAST CONFIGURATION PAR DESCRIPTION RANGE UNIT OF INC/DEC DEFAULT For access to the installer's parameters, MEASUREMENT UNIT SETTING press simultaneously the ( ) keys 01 Combustion configuration -- = ND “--” for 5 seconds. 1 ...
  • Page 19 EXTERNAL SENSOR (fig. 13) If there is an external sensor, the heating settings SET can be taken from the climatic curves according to the external tempera- ture and, limited to with the range values described in point 3.2 (parameters PAR 13 and PAR 14).
  • Page 20 HE 30 - HE 30 C HE 25 1000 1200 PORTATA (l/h) FLOW RATE (l/h) HE 25 HE 30 - HE 30 C RESIDUAL HEAD PORTATA RESIDUAL HEAD PREVALENZA PORTATA FLOW RATE PREVALENZA FLOW RATE (l/h) RESIDUA (mbar) (l/h) RESIDUA (mbar) (l/h) (mbar) (l/h)

  • Page 21: Use, Maintenance (Including Benchmark) And Commissioning

    3) Determine the CO values at max power Capacity step stated below, if required adjust using the OFF-SET For a MERIDIAN HE 30 C boiler to func- capacity step (5 fig. 16): Fig. 16 tion with LPG, press until 05 appears.
  • Page 22 Fig. 20 extended warranty, it must be serviced regularly, dependant on usage, but at least Codice/Code 8111862 Modello/Model MERIDIAN HE 30 C Matricola/Serial n. 9999999999 PAR 1 = 02 (METANO) / 05 (GPL) PAR 2 = 13 Fig. 19...
  • Page 23 annually by a qualified Gas Safe Registered red led. Descriptions of the errors with AL07. If the problem persists for more engneer. relative alarms and solutions are given than one minute, the boiler will stop and During maintenance operations, it is below (if a error persists contact a authori- the red LED will turn on.
  • Page 24 than two minutes the boiler will stop for recorded in the Benchmark section of this – Carefully lift out the burner. thirty minutes and then attempt to resu- manual. – Check seals and replace if necessary me working. It is the law that a competent person such –...

  • Page 25: Gas Boiler System Commissioning Checklist

    GAS BOILER SYSTEM COMMISSIONING CHECKLIST This Commissioning Checklist is to be completed in full by the competent person who commissioned the boiler as a means of demonstrating compliance with the appropriate Building Regulations and then handed to the customer to keep for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty.

  • Page 26: Service Record

    SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. SERVICE 01 SERVICE 02 Date:...

  • Page 27: Fault Finding

    FAULT FINDING If an electrical fault occurs on the appliance SHORT CIRCUIT approx.: 240 V ac. the preliminary electrical system checks CHECK – Test leads from L to E “ ” meter reads must be carried out first. approx. 240 V ac. Switches turned FULL ON - meter set on Ω...
  • Page 28 – Refit in reverse order ensuring seals are replaced as required fit in reverse order ensuring seals are replaced as required – Setting the gas valve procedure for MERIDIAN HE 30 C: 1. Remove the heating sensor from the flow pipe. 2. Open the downstream test point (4 fig.
  • Page 29 – Isolate flow and return – Refit in reverse order – Turn on D.H.W tap – Close cold water supply isolation valve – Drain boiler using drain vent 6. 1 9 DHW FLOW SWITCH – Remove 2 screws securing plate heat exchanger –...

  • Page 30: Exploded Views

    EXPLODED VIEWS...
  • Page 32 Code Position Description 6318350 Left hand side frame part 6318300 Right hand side frame part 6267161 Main exchanger rear brachet 6010833 Main exchanger supporting bracket 6112330 Bush thermostatic 6146728 Limit stat auto reset 80°C 6226624 Spring air vent knob 6278912 Main exchanger body 6277130 Probe NTC D.4X40...
  • Page 33 Position Code Description 6304853 Grey cover 6293006 Trap fixing bracket 6277205 Water trap 6034155 Condensate drainage pipe 2051122 Clamp diam. 22,1 1010215 Rubber pipe diam. 15x2,5 2051120 Clamp diam. 17,3 6034165 Condensate drainage rubber pipe 6001158 Air intake pipe 40 2051200 Hose clamp diam.
  • Page 34 Position Code Description 6227036 D.H.W. outlet pipe 6265821 Three-way assembly 6265822 Brass junction 6231357 D.H.W. temperature sensor 5185139 Conversion kit to LPG 6281576 Water pressure switch + spring 6281534 Gaskets kit 6319695 O-ring kit 5199630 Complete control panel 6323861 6 pole cable connector 6316253 9 pole Stocko connector 6323856...

  • Page 35: Appendix 1 (Guidance Hhic)

    APPENDIX A (GUIDANCE HHIC) INDUSTRY GUIDANCE FOR INSTALLERS ON CONDENSATE DRAINAGE PIPE INSTALLATION This guidance is endorsed by HHIC members. 1. BACKGROUND During recent winters the UK has experienced prolonged spells of extremely cold weather - down to minus 20 C and below in many areas.
  • Page 36 2.1 INTERNAL TERMINATION: Wherever possible, the condensate drainage pipe should be terminated at a suitable internal foul water discharge point such as (a) an internal soil and vent stack or (b) an internal kitchen or bathroom waste pipe, washing machine waste pipe etc. A suitable permanent connection to the foul waste pipe should be used.
  • Page 37 The use of fittings, elbows etc should be kept to a minimum and any internal “burrs” on cut pipework should be removed so that the internal pipe section is as smooth as possible. The customer/householder should be advised that even with the above measures this type of installation could freeze, and that if this were to occur then boiler shutdown could result, requiring remedial action - possibly involving a chargeable engineer call-out.
  • Page 38 NOTES The Benchmark Commissioning Checklist (located at the back of the boiler installation manual) should be completed as required to record details of the condensate drainage pipe installation. Where an external condensate drainage pipe is installed, the customer should be made aware of the risks and consequences of its freezing and offered the option to fit trace heating (or other measures approved by the boiler manufacturer or service organisation).
  • Page 39 Figure 1 – Connection of condensate drainage pipe to internal soil and vent stack Boiler Visible air break 75 mm trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 75 mm incorporated into the boiler Soil and vent stack Invert 450 mm minimum up to three storeys...
  • Page 40 Figure 2(a) – Connection of a condensate drainage pipe downstream of a sink, basin, bath or shower waste trap Boiler Visible air break 75 mm trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 75 mm incorporated into the boiler.
  • Page 41 Figure 2(b) – Connection of a condensate drainage pipe upstream of a sink, basin, bath or shower waste trap Boiler Visible air break at plug-hole 75 mm sink, basin, bath or shower waste trap Sink, basin, bath or shower with integral overflow Open end of condensate drainage pipe direct into gully 25 mm min below grating but above water level;...
  • Page 42 Figure 3 – Connection of a condensate pump - typical method (NB manufacturer’s detailed instructions should be followed). IND GUIDE INST 10-11 HHIC REF T11/0027BRev8...
  • Page 43 Figure 4 – Connection of condensate drainage pipe to external soil and vent stack Boiler 450 mm minimum up to three storeys Visible air break Minimum internal diameter 19 mm 75 mm trap Pipe size transition point Visible air break and trap not required if Minimum internal diameter 30 mm there is a trap with a minimum condensate Water/weather proof insulation...
  • Page 44 Figure 5 – External termination to rainwater downpipe (NB only combined foul/rainwater drain) Condensate discharge pipe from boiler Air gap Pipe size transition point 68 mm PVCu strap-on fitting Water/weather proof insulation Minimum internal diameter 19 mm 43 mm 90° male/female bend Minimum internal diameter 30 mm External rain water pipe into foul water End cut at 45 °...
  • Page 45 Figure 6 – External drain, gully or rainwater hopper Boiler Visible air break 38 mm minimum trap Visible air break and trap not required if there is a trap with a minimum condensate seal of 38 mm incorporated into the boiler External length of pipe 3 m maximum Open end of condensate drainage pipe direct into gully 25 mm min below grating but above water level;...
  • Page 46 Figure 7 – Example of a purpose-made soakaway Condensate discharge pipe from boiler Ground (this section of the condensate drainage pipe may be run either above or below ground level); End cut at 45 ° Diameter 100 mm minimum plastic tube Bottom of tube sealed Limestone chippings Two rows of three 12 mm holes at 25 mm centres, 50 mm from bottom of tube and...

  • Page 47: Appendix 2

    Turn off appliance and call SIME LTD Technical HelplIne for advice. NOTE - if no flue gas sampling point is present and the correct pro- cedure is not specified in the manual, contact SIME LTD Technical the appliance must not be commissio- Helpline for advice.
  • Page 48 Sime Ltd 1a Blue Ridge Park Thunderhead Ridge Glasshoughton, Castleford, WF10 4UA Phone: 0845 9011114 Fax: 0845 9011115 www.sime.co.uk Email: enquiries@sime.co.uk...
