Kenmore KM1000 Use & Care Manual

Freestanding purifier dispenser
Hide thumbs

Advertisement

Use & Care Guide
English
Freestanding
Water Optimizer
Freestanding Purifier·Dispenser
Model: KM1000(B)
Customer Assistance
1-844-374-6576
www.kenmore.com
Kenmore and the Kenmore logo are the registered
trademarks of KCD IP, LLC and/or Sears Brands, LLC
and are used under license by Drinkpod, LLC
All Rights Reserved.

Advertisement

Table of Contents
loading

  Also See for Kenmore KM1000

  Related Manuals for Kenmore KM1000

  Summary of Contents for Kenmore KM1000

  • Page 1 English Freestanding Water Optimizer Freestanding Purifier·Dispenser Model: KM1000(B) Customer Assistance 1-844-374-6576 www.kenmore.com Kenmore and the Kenmore logo are the registered trademarks of KCD IP, LLC and/or Sears Brands, LLC and are used under license by Drinkpod, LLC All Rights Reserved.
  • Page 2 KM1000 KM1000B...
  • Page 3: Table Of Contents

    Table Of Contents IMPORTANT SAFETY INSTRUCTIONS GETTING TO KNOW YOUR WATER OPTIMIZER Filters Technical Specifications Powering On/Off Your Optimizer Dispensing Water USING YOUR WATER OPTIMIZER Customizing QuickFill Mode Controlling Dispenser Light Using ECO Mode Replacing Your Water Optimizer’s Filters MAINTAINING YOUR WATER OPTIMIZER Storing &...
  • Page 4: Important Safety Instructions

    Ensure the power cord is always unplugged before performing any maintenance, troubleshooting, or filter upgrades. Only use Kenmore or Drinkpod accessories and filters to avoid causing damage and voiding product warranty. For all service and support related issues, please immediately contact support at 1-844-374- 6576, or email us at support@drinkpod.com.
  • Page 5: Getting To Know Your Water Optimizer

    Getting To Know Your Water Optimizer Behind Dispenser Nozzle Getting To Know Your Water Optimizer 1...
  • Page 6 Important Safety Instructions Important Safety Instructions 2...
  • Page 7 Important Safety Instructions Leak Detector Compartment Product Features Control Panel Dispenser Light Button - Toggles dispenser light. ECO Mode/Filter Rest Button - Press to toggle ECO Mode, hold to reset filter. Light Sensor - Light sensor that activates ECO Mode. Important Safety Instructions 3...
  • Page 8 Important Safety Instructions Heating System Status Light - When lit, indicates heating system is active. Cooling System Status Light - When lit, indicates cooling system is active. System Power Status Light - When lit, indicates is powered on. UV Sterilizer Status Light - When lit, UV sterilizer is active (ambient only). Pod Filter(s) Status Light - When light is red, pod filters needs replaced.
  • Page 9 Important Safety Instructions 110v Power Cord - Provides power to Water Optimizer. Standard U.S. 110v only. Accessory Output Port - Port to connect accessory appliances (i.e. ice-maker). Source Input Port - Port that connects to water source to provide water to Optimizer. Leak Detection Sensor - Detects internal leaks.
  • Page 10: Filters

    Important Safety Instructions Filters Shown above are the available pod filter options in Kenmore’s water purification product line. F1. ULTRA+3 Hybrid Filter (Included)- Recommended for internal filter slot. May be replaced by Polishing Filter for increased flow rate (at the cost of purification quality).
  • Page 11 Important Safety Instructions F3. Chemical Filter (Sold Separately)- This filter can be used as an alternative, replacing the secondary Particle Filter. The Chemical water filter replacement pod utilizes a activated carbon granules to improve the safety of drinking water by effectively removing common disinfection byproducts (THMs), organic contaminants like chlorinated solvents and other industrial pollutants, pesticides, and select heavy metals such as lead and mercury.
  • Page 12: Technical Specifications

    Kenmore Water Optimizer. These issues may include, but are not limited to: dry heating, low flow, water sloshing, etc. Kenmore and Drinkpod are in now way obligated to provide technical support, warranty service or replacement for any parts or components not included with your Optimizer, excluding OEM replacement filters.
  • Page 13: Powering On/Off Your Optimizer

    Using Your Water Optimizer This guide will explain how to use, maintain, and troubleshoot your new Water Optimizer. Be sure to complete all of the applicable instructions in the Installation Guide, included with your Optimizer prior to using the appliance. Powering On/Off Your Optimizer Be sure to never plug in your Optimizer, or power on either temperature mode before you’ve connected a proper water source, and enabled water flow.
  • Page 14: Customizing Quickfill Mode

    Using Your Water Optimizer on the Dispense Button. Water (of selected temperature mode) will continue to dispense until button is released, or 10 minutes has elapsed. Mode, when triggered, will dispense water for 10 seconds (this time is QuickFill customizable, see “Customizing QuickFill Mode”...
  • Page 15: Using Eco Mode

    Using Your Water Optimizer that can be toggled by pressing the Dispenser Light Button. By default, it is set to illuminate only when dispensing. 1. To toggle to illuminate, press once. Button will always Dispenser Light Button remain illuminated. 2. To toggle to never illuminate, press Dispenser Light Button...
  • Page 16 Using Your Water Optimizer Using Your Water Optimizer 12...
  • Page 17: Replacing Your Water Optimizer's Filters

    Maintaining Your Water Optimizer Replacing Your Water Optimizer’s Filters Your Water Optimizer is equipped with a to indicate Pod Filter(s) Status Light when you need to change your pod filters (based on typical usage). This reminder is controlled by a timer that will change the Pod Filter(s) Status Light from white to red every six months.
  • Page 18 Maintaining Your Water Optimizer 1/4 in. Quick Connect Shutoff Valve, until the water exiting the filter is clear. Be sure to aim the water outlet on the attachment into your container. 8. Now, disconnect the Filter Flushing Setup from the 1/4 in.
  • Page 19: Storing & Relocating Your Water Optimizer

    Maintaining Your Water Optimizer Storing & Relocating Your Water Optimizer At some point, you may need to store or relocate your Water Optimizer. Should one of these situations be the case for you, below are a few simple steps to prevent any damage from occurring.
  • Page 20 Maintaining Your Water Optimizer 6. Slide the blue Retainer Clip off of the Appliance Drain Port. 7. Press the dark gray Quick Connect Sleeve all the way up into the port then, while keeping the sleeve pressed in, pull down and remove the white Plug.
  • Page 21: Leaving Your Water Optimizer (Vacation)

    Maintaining Your Water Optimizer 12. Disconnect the tubing running between our Optimizer’s Source Input Port 1/4 in. Quick Connect Shutoff Valve you just shutoff, and place end of the tubing into a container to catch any water that drains back. 13.
  • Page 22: Troubleshooting Your Water Optimizer

    Solution 5: As a final solution, if your water source doesn’t require submicron filtration, you can swap your primary filter with a Polishing Filter (KMFLTEZ4) that can be purchased separately from the Kenmore website, Drinkpod.com, and select retailers. In comparison to the primary ULTRA+3 Filter (KMFLTEZ5) that was included with your Water Optimizer, it trades off submicron filtration capabilities for a higher flowrate, and extended lifespan.
  • Page 23: Issue #3: My Water Optimizer Isn't Powering On

    Troubleshooting Your Water Optimizer Solution 3: If you haven’t already, try attaching the secondary external Particle Filter and external attachment assembly to your Water Optimizer. It was included to specifically address scenarios a users water source has abnormally high levels of large particle contaminants, to extend the primary filters lifespan.
  • Page 24: Issue #7: My Dispenser Button Light Is Flashing

    Troubleshooting Your Water Optimizer Solution 2: Cold tank’s water level may have been drained and exhausted by above average use, and requires sufficient time to replenish. Solution 3: Compressor may have failed or lost the R-134A refrigerant. If compressor is running continuously and/or feels extremely hot to touch, power off Cold Mode Power Switch, and contact support at 1-844-374-6576, or support@...
  • Page 25 Troubleshooting Your Water Optimizer Solution 3: Check for broken, cracked or weak fitting connections. Solution 4: Contact support at 1-844-374-6576, or email us at support@drinkpod. com. Troubleshooting Your Water Optimizer 21...
  • Page 26: Notes

    Notes Notes 22...
  • Page 27: Warranty

    Warranty KENMORE LIMITED WARRANTY FOR TWO YEARS from the date of sale this appliance is warranted against defects in material or workmanship when it is correctly installed, operated and maintained according to all supplied instructions. WITH PROOF OF SALE a defective appliance will receive free repair or replacement at option of...
  • Page 28 Kenmore ® Customer Care Hotline For technical support, warranty repair service, or to order replacement parts. 1-844-374-6576 www. kenmore. com ® S/N STICKER GOES HERE...

This manual is also suitable for:

Km1000b
