OWNER'S MANUAL
Two-Stage
Drinking Water Filter
MODEL NO. 625.384610
Caution:
Read and follow all safety rules and operating
instructions before first use of this product.
Questions ?
Visit www.KenmoreWater.com
or call toll free 1-800-426-9345 (M - F, 7 AM - 8 PM CST)
Repair or Parts ? Call toll free 1-800-469-4663
See back cover for other Sears service numbers.
SAVE THIS MANUAL
Sears, Roebuck and Co., 3333 Beverly Road, Hoffman Estates, IL 60179 U.S.A.
PRINTED IN U.S.A.
System Tested and Certified by NSF International against
NSF/ANSI Standard 42. See performance data sheet for details.
www.KenmoreWater.com
• Warranty
• Installation
• How It Works
• Care Of
• Specifications
• Repair Parts
Part No.7293858 (Rev. C 5/2/07)
Advertisement
Table of Contents
Related Manuals for Kenmore 625.384610
Summary of Contents for Kenmore 625.384610
- Page 1 OWNER'S MANUAL Two-Stage Drinking Water Filter MODEL NO. 625.384610 Caution: Read and follow all safety rules and operating • Warranty instructions before first use of this product. • Installation Questions ? • How It Works Visit www.KenmoreWater.com • Care Of or call toll free 1-800-426-9345 (M - F, 7 AM - 8 PM CST) •...
- Page 2 This warranty gives you specific legal rights, and you may have other rights which vary from state to state Sears, Roebuck and Co., Hoffman Estates, IL 60179 Dimensions 13" 9-5/8" 4-5/8" Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com...
-
Page 3: Table Of Contents
Follow your local codes if they differ with guides in this manual. In Massachusetts, plumbing codes of Massachusetts shall be adhered to. Consult with a licensed plumber. Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... -
Page 4: Unpack And Check Shipment
Massachusetts before proceeding with the installation. Packing List Bag Assembly Coin Battery 3/8” O.D. Tubing Mounting Screws Faucet Tee Feed Adaptor Two-Stage Drinking Water Filter Thread Sealing Tape Sump Wrench Electronics Base Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... -
Page 5: Plan Your Installation
Most sinks already have shutoff valves on the supply pipes. NOTE: Allow a minimum space of 1-1/2” under the Figure 2 system for removing the sumps (to change cartridges). Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... -
Page 6: Step 1-Install Supply Water Fitting
3/8” compression fitting insert ferrule cold water pipe 3/8” yellow tubing to cold water Water Filter inlet shutoff valve Figure 3 Figure 4 Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... -
Page 7: Step 2-Install Filtered Water Faucet
2. Give the faucet a 1/4 turn clockwise to attach the faucet to the base. 3. Install battery in faucet base (See “Change Battery” section Figure 7 on Page 9) then continue installation with Step 3 on Page 8. Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... -
Page 8: Step 3-Connect Tubes
2. Continue holding collet inward while pulling the tubing out. See Figure 13. Collet (Depress to Remove Tubing) O-Ring Seal Fitting Collet Tubing Figure 13 Figure 12 Collet and O-Ring Disconnect Tubing Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... -
Page 9: Maintenance
NOTE: If the LED repeatedly flashes just two times, it is not a fully charged battery and will need to be replaced. 5. Re-install the timer housing and firmly tighten the mounting screw. See Figure 14. Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... - Page 10 These cartridges have not been performance tested and cer- tified by NSF International. These cartridges have been performance tested and certified by NSF International in Model 625.384600. Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com...
- Page 11 This cartridge has not been performance tested and certified by NSF International. Head O-ring Seal Filter Cartridge Sump Filter II Turn to the left to remove Figure 15 Filter I Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com...
-
Page 12: Specifications
Reinsert in connection See Page 8. Remove tube from connection. Remove problem area Cause: Outer tubing surface not smooth. Correction: by cutting tube to shorter length. Reinsert in connection See Page 8. Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... - Page 13 Notes Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com...
-
Page 14: Exploded View & Parts List
Exploded View Manifold Housing PUSH-IN FITTINGS collet o-ring seal Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com... - Page 15 Sears Parts at 1-800-469-4663. Not included. These cartridges have not been performance tested and certified by NSF International. These cartridges have been performance tested and certified by NSF International in Model 625.384600. Questions? Call The Kenmore Water Line 1-800-426-9345 or visit KenmoreWater.com...
- Page 16 Get it fixed, at your home or ours! Your Home For repair – in your home – of all major brand appliances, lawn and garden equipment, or heating and cooling systems, no matter who made it, no matter who sold it! For the replacement parts, accessories and owner’s manuals that you need to do-it-yourself.
