Medical Panel PC with 6th Gen. Intel® Core™ / Celeron® CPU,
4 GB DDR4 RAM, Wi-Fi 802.11a/b/g/n/ac, P-CAP Touchscreen,
Three Battery Bays, 5-Megapixel Camera and Microphone
POCm-W22C-ULT3
POCm-W24C-ULT3
Quick Installation Guide
Version 1.01
©2018 Copyright by IEI Integration Corp.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for IEI Technology POCm-W22C-ULT3
Summary of Contents for IEI Technology POCm-W22C-ULT3
-
Page 1: Quick Installation Guide
Medical Panel PC with 6th Gen. Intel® Core™ / Celeron® CPU, 4 GB DDR4 RAM, Wi-Fi 802.11a/b/g/n/ac, P-CAP Touchscreen, Three Battery Bays, 5-Megapixel Camera and Microphone POCm-W22C-ULT3 POCm-W24C-ULT3 Quick Installation Guide Version 1.01 ©2018 Copyright by IEI Integration Corp. All rights reserved. -
Page 2: Intended Use
Revision Date Version Changes September 11, 2018 1.01 Minor update August 28, 2018 1.00 Initial release Intended Use The POCm-W22/24C-ULT3 medical panel PC is intended to be used to display general purpose medical images. The device shall not be used for diagnosis purpose or life supporting system. - Page 3 Overview The POCm-W22/24C-ULT3 is a 6 generation Intel® Core™ i5-6300U processor powered medical-grade panel PC with a rich variety of functions and peripherals. All POCm-W22/24C-ULT3 models are designed for easy and simplified integration into point-of-care (POC) applications. The system comes with 4 GB of preinstalled DDR4 memory and supports a maximum of 32 GB ensuring smooth data throughputs with reduced bottlenecks and fast system access.
- Page 4 Front Panel Bottom Panel...
- Page 5 Side Panel Rear Panel...
-
Page 6: System Specifications
System Specifications POCm-W22C-ULT3 POCm-W24C-ULT3 LCD and Touchscreen LCD Size 21.5" (16:9) 23.8" (16:9) Max. Resolution 1920 (W) x 1080 (H) 1920 (W) x 1080 (H) Brightness (cd/m2) Contrast Ratio 1000:1 1000:1 LCD Color 16.7M (RGB 6-bit) 16.7M (RGB 6-bit + Hi-FRC) Pixel Pitch (mm) 0.24825 (H) x 0. - Page 7 TPM 2.0 (optional) Other Features 1 x Power on/off 1 x Brightness up Function Keys 1 x Brightness down 1 x Volume up 1 x Volume down 1 x Touch lock (clean mode) or LCD on/off 3 x Battery indicator LED Indicators 1 x Power indicator Cooling Method...
-
Page 8: Installation Precautions
Installation Precautions When installing the medical panel PC, please follow the precautions listed below: Manufacturer authorization: Do not modify this equipment without authorization of manufacturer. Certified Engineers: Only certified engineers should install and modify the hardware settings. Power turned off: When installing the medical panel PC, make sure the power is off. -
Page 9: Mounting The System
Mounting the System WARNING: Use suitable mounting apparatus and be sure to secure the screws of the mounting apparatus tightly to avoid risk of injury. NOTE: When mounting the POCm-W22/24C-ULT3 flat panel PC, it is better to have more than one person to help with the installation to make sure the POCm-W22/24C-ULT3 does not fall down and get damaged. -
Page 10: Powering On The System
Powering On the System WARNING: To avoid risk of electric shock, this equipment must only be connected to supply mains with protective earth. CAUTION: The FSP FSP150M-ABA power adapter came with the POCm-W22/24C-ULT3 is a forming part of the medical device. Step 1: Connect the power cord to the power adapter. -
Page 11: Troubleshooting
Troubleshooting If the following situations happen, contact your distributor, sales representatives or IEI customer service center for technical support. The HDD is installed correctly, but the POCm-W22/24C-ULT3 is unable to boot with AC power input after pressing the power button. ... -
Page 12: Optional Items
Accessories The medical panel PC is shipped with the following components: Quantity Item Image POCm-W22/24C-ULT3 medical panel Power cord (P/N: 32702-000200-100-RS) 150 W FSP FSP150M-ABA medical-grade power adapter (P/N: 63040-010150-400-RS) Round-head screw (M3*3) for HDD installation (P/N: 44003-030032-RS) Quick Installation Guide Optional Items The following components may be separately purchased: Item and Part Number... -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU) Low-Voltage Directive (2006/95/EC, 2014/35/EU) RoHS II Directive (2011/65/EU, 2015/863/EU) Medical Device Directive 93/42/EEC: EN 60601-1 If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply. -
Page 14: Rohs Statement
ROHS STATEMENT The label on the product indicates this product conforms to European (EU) Restriction of Hazardous Substances (RoHS) that set maximum concentration limits on hazardous materials used in electrical and electronic equipment. CHINA ROHS The label on the product indicates the estimated “Environmentally Friendly Use Period”... -
Page 15: Safety Precautions
Safety Precautions WARNING: The precautions outlined below should be strictly followed. Failure to follow these precautions may result in permanent damage to the POCm-W22/24C-ULT3 General Safety Precautions Please ensure the following safety precautions are adhered to at all times. To prevent the risk of electric shock, make sure power cord is unplugged from wall socket. - Page 16 DO NOT: Drop the POCm-W22/24C-ULT3 against a hard surface. Strike or exert excessive force onto the LCD panel. Touch any of the LCD panels with a sharp object In a site where the ambient temperature exceeds the rated temperature Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type.
-
Page 17: Emc Test Summary
The equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide: Not AP or APG Category. EMC Test Summary Guidance and manufacturer’s declaration – electromagnetic emissions The model POCm-W22/24C-ULT3 is intended for use in the electromagnetic environment specified below. - Page 18 For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
-
Page 19: Recommended Separation Distance
for 25 cycles for 25 cycles POCm-W22/24C-ULT3 be powered from an <5 % UT <5 % UT uninterruptible power (>95 % dip in (>95 % dip in supply or a battery. for 5 sec for 5 sec Power frequency 3 A/m 3 A/m Power frequency (50/60 Hz) -
Page 20: Contact Information
Field strengths from fixed RF transmitters, as determined by an electromagnetic site survey, should be less than the compliance level in each frequency range. Interference may occur in the vicinity of equipment marked with the following symbol: NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations.
