POCi-W24C-ULT5 Medical Panel PC
MODEL:
POCi-W24C-ULT5
th
Medical Panel PC with 8
Gen. Intel® Core™ i5/i7 CPU,
Up to 64 GB DDR4 RAM, P-CAP Touchscreen, HDIM Output, M.2,
Isolated COM, Wi-Fi 802.11ax, Dual Isolated GbE, Audio and RoHS
User Manual
Page i
Rev. 1.01 - February 22, 2022
[MODEL NAME]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POCi-W24C-ULT5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology POCi-W24C-ULT5

Summary of Contents for IEI Technology POCi-W24C-ULT5

  • Page 1 POCi-W24C-ULT5 Medical Panel PC MODEL: POCi-W24C-ULT5 Medical Panel PC with 8 Gen. Intel® Core™ i5/i7 CPU, Up to 64 GB DDR4 RAM, P-CAP Touchscreen, HDIM Output, M.2, Isolated COM, Wi-Fi 802.11ax, Dual Isolated GbE, Audio and RoHS User Manual Page i Rev.
  • Page 2 POCi-W24C-ULT5 Medical Panel PC Revision Date Version Changes February 22, 2022 1.01 Updated Table 1-2: System Specifications Updated Section 3.1 Added a warning message in Section 3.3 Updated FCC warning message in Appendix A August 3, 2021 1.00 Initial release...
  • Page 3 POCi-W24C-ULT5 Medical Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 POCi-W24C-ULT5 Medical Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    POCi-W24C-ULT5 Medical Panel PC Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................3 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................4 RONT ANEL 1.4.1 Backlit Touch Buttons ..................5 1.5 B ......................
  • Page 6 POCi-W24C-ULT5 Medical Panel PC 4.1.1 Starting Setup ....................34 4.1.2 Using Setup ...................... 34 4.1.3 Getting Help ..................... 35 4.1.4 BIOS Menu Bar ....................35 4.2 M ........................36 4.3 A ....................... 37 DVANCED 4.3.1 CPU Configuration ..................38 4.3.2 PCH-FW Configuration ................... 40 4.3.2.1 PTT Configuration ..................
  • Page 7 POCi-W24C-ULT5 Medical Panel PC A REGULATORY COMPLIANCE ................70 B PRODUCT DISPOSAL ....................76 C MAINTENANCE AND CLEANING PRECAUTIONS .......... 78 C.1.1 Maintenance and Cleaning ................80 C.1.2 Cleaning Tools ....................80 D SYMBOL DEFINITIONS ..................81 E BIOS MENU OPTIONS ..................... 83 F WATCHDOG TIMER ....................
  • Page 8 POCi-W24C-ULT5 Medical Panel PC List of Figures Figure 1-1: POCi-W24C-ULT5 Medical Panel PC ................. 2 Figure 1-2: Front View ........................4 Figure 1-3: Backlit Touch Buttons ....................5 Figure 1-4: Bottom Panel ....................... 6 Figure 1-5: Bottom Panel – BP SKU ..................... 6 Figure 1-6: Side View........................
  • Page 9 POCi-W24C-ULT5 Medical Panel PC List of Tables Table 1-1: Model Variations ......................3 Table 1-2: System Specifications ....................10 Table 3-1: RS-232 Serial Port Pinouts ..................29 Table 4-1: BIOS Navigation Keys ....................35 Page ix [MODEL NAME]...
  • Page 10 POCi-W24C-ULT5 Medical Panel PC List of BIOS Menus BIOS Menu 1: Main ........................36 BIOS Menu 2: Advanced ......................37 BIOS Menu 3: CPU Configuration ....................38 BIOS Menu 4: PCH-FW Configuration ..................40 BIOS Menu 5: PTT Configuration ....................41 BIOS Menu 6: Trusted Computing ....................

  • Page 11: Introduction

    POCi-W24C-ULT5 Medical Panel PC Chapter Introduction Page 1...

  • Page 12: Overview

    LAN. NOTE: The POCi-W24C-ULT5 medical panel PC is intended to be used to display general purpose medical images. The device shall not be used for diagnosis purpose or life supporting system.

  • Page 13: Model Variations

    POCi-W24C-ULT5 Medical Panel PC 1.2 Model Variations There are six models in the POCi-W24C-ULT5 series. All models are preinstalled with one 4 GB DDR4 memory module and an 802.11ax Wi-Fi module. The model numbers and model variations are listed below.

  • Page 14: Front Panel

    POCi-W24C-ULT5 Medical Panel PC 1.4 Front Panel The front side of the POCi-W24C-ULT5 is a flat-bezel panel with a TFT LCD screen surrounded by an aluminum frame (Figure 1-2). The bottom surface contains several backlit touch buttons, a power indicator and an optional RFID reader.

  • Page 15: Backlit Touch Buttons

    POCi-W24C-ULT5 Medical Panel PC 1.4.1 Backlit Touch Buttons The front panel of the POCi-W24C-ULT5 contains several backlit touch buttons that control reading light, LCD brightness and some other system components. Figure 1-3: Backlit Touch Buttons The following table describes the function of each button.

  • Page 16: Bottom Panel

    POCi-W24C-ULT5 Medical Panel PC 1.5 Bottom Panel The bottom panel of the POCi-W24C-ULT5 has the following connectors and components (Figure 1-4):  1 x DC input jack (standard) / Power inlet (BP SKU)  1 x HDMI output connector ...

  • Page 17: Side Panels

    POCi-W24C-ULT5 Medical Panel PC 1.6 Side Panels The right side panel has two USB 2.0 ports protected by a cover, and a power button. Figure 1-6: Side View 1.7 Rear Panel The rear panel contains the retention screw holes that support VESA 75/100 mounting (Figure 1-7).

  • Page 18: System Specifications

    POCi-W24C-ULT5 Medical Panel PC 1.8 System Specifications The technical specifications for the POCi-W24C-ULT5 systems are listed below. LCD and Touchscreen LCD Size 23.8" (16:9) Max. Resolution 1920 (W) x 1080 (H) Brightness (cd/m Contrast Ratio 1000:1 LCD Color 16.7M RGB 6-bit (Hi-FRC) Pixel Pitch (mm) 0.2745 (H) x 0.2745 (V)
  • Page 19 POCi-W24C-ULT5 Medical Panel PC 4 x USB 3.2 Gen 2 (10Gb/s, 5V / 1A) 2 x USB 2.0 (side panel, 5V / 0.5A) 1 x Audio out / Mic-in combo 1 x Accessible 2.5" SATA 6Gb/s HDD/SSD bay Storage 1 x M.2 2242/2260/2280 M-key slot (PCIe x4)

  • Page 20: Table 1-2: System Specifications

    POCi-W24C-ULT5 Medical Panel PC Environment Temperature -20ºC – 60ºC Storage/Transportation Humidity 10% – 95% (non-condensing) Pressure 700 hPa – 1060 hPa Temperature 0ºC – 40ºC Operating Humidity 10% – 95% (non-condensing) Pressure 700 hPa – 1060 hPa Vibration Operating Shock: 5G peak acceleration (11ms duration)

  • Page 21: Battery Specifications (B Sku Only)

    POCi-W24C-ULT5 Medical Panel PC 1.9 Battery Specifications (B SKU only) WARNING / AVERTISSEMENT  Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Risque d'explosion si la batterie n'est pas remplacée correctement.

  • Page 22: Figure 1-8: Battery Cover Retention Screws

    POCi-W24C-ULT5 Medical Panel PC Some SKUs of the POCi-W24C-ULT5 series are preinstalled with a Li-ion battery. The followings are some of the specifications of the optional Li-ion battery pack.  Capacity: 7800 mAh  Normal voltage: 11.1V  Charge voltage: 12.6 V ...

  • Page 23: Figure 1-9: Battery Pack And Battery Holder

    POCi-W24C-ULT5 Medical Panel PC Figure 1-9: Battery Pack and Battery Holder Step 4: Pull the ribbon on the battery to remove the battery. Step 5: To replace the battery, put a new battery in and connect it to the system (Figure 1-10).

  • Page 24: Dimensions

    POCi-W24C-ULT5 Medical Panel PC 1.10 Dimensions The POCi-W24C-ULT5 dimensions are shown below. Figure 1-11: Dimensions (mm) Page 14...

  • Page 25: Unpacking

    POCi-W24C-ULT5 Medical Panel PC Chapter Unpacking Page 15...

  • Page 26: Unpacking

    POCi-W24C-ULT5 Medical Panel PC 2.1 Unpacking To unpack the medical panel PC, follow the steps below: WARNING / AVERTISSEMENT The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the medical panel PC has been properly installed.

  • Page 27: Packing List

    POCi-W24C-ULT5 was purchased from or contact an IEI sales representative directly by sending an email to ales@ieiworld.com. 3 2 6 H 3 7 8 H The POCi-W24C-ULT5 medical panel PC is shipped with the following components: Quantity Item Image POCi-W24C-ULT5 medical panel PC...

  • Page 28: Optional Ato Items

    POCi-W24C-ULT5 Medical Panel PC 2.3 Optional ATO Items The following are optional, assemble-to-order components: Item Part Number RFID reader MEDP-MF-RFID-R11 DICOM module MEDP-DICOM-R10 PoE card, 2-port 1000BASE-T, 802.3at GPoE-2P-R20 Cable cover POCP-CC06-R10 TPM module TPM-IN03-R10 Li-ion battery pack, 3S3P, 7800 mAh...

  • Page 29: Installation

    POCi-W24C-ULT5 Medical Panel PC Chapter Installation Page 19...

  • Page 30: Safety Precautions

     Electric shocks can occur if the POCi-W24C-ULT5 chassis is opened when the POCi-W24C-ULT5 is running. To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth.
  • Page 31  Never replace or repair any components on your own. If the components of the POCi-W24C-ULT5 fails or malfunctions it must be shipped back to IEI to be repaired. Please contact the system vendor, reseller or an IEI sales person directly.

  • Page 32: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the POCi-W24C-ULT5. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the POCi-W24C-ULT5 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 33: Installation Precautions

    WARNING / AVERTISSEMENT DO NOT power up the POCi-W24C-ULT5 while the front panel is facing down on a sheet of conductive foam. Doing so may cause the touch panel to malfunction due to the large surface area of contact between the conductive form and the touch panel.

  • Page 34: Installation And Configuration Steps

    POCi-W24C-ULT5 Medical Panel PC WARNING / AVERTISSEMENT This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

  • Page 35: Hdd Installation

    POCi-W24C-ULT5 Medical Panel PC 3.5 HDD Installation To install the HDD into the system, please follow the steps below: Step 1: Remove the two HDD cover retention screws on the rear panel (Figure 3-1). Figure 3-1: HDD Cover Retention Screws Step 2: Remove the HDD cover.

  • Page 36: Figure 3-3: Secure Hdd

    POCi-W24C-ULT5 Medical Panel PC Step 4: Insert an HDD into the HDD bracket, aligning the four retention screw holes on the bottom of the HDD bracket with the retention screw holes on the bottom of the HDD (Figure 3-3). Step 5: Insert four retention screws (M3*3) into the bracket (Figure 3-3).

  • Page 37: M-Key Module Installation

    POCi-W24C-ULT5 Medical Panel PC 3.6 M.2 M-Key Module Installation To install M.2 modules into the system, please follow the steps below: Step 1: Follow the Step 1 - Step 3 instruction described in Section 3.5 to remove the HDD cover and the HDD bracket.

  • Page 38: Figure 3-7: Inserting The M.2 Module Into The Slot At An Angle

    POCi-W24C-ULT5 Medical Panel PC NOTE: The latch position is adjustable for 2242 or 2260-sized modules. To change the latch position, rotate the latch 90° and lift the latch off the board. Insert the latch into the pre-drilled hole that matches the size of the M.2 module, and rotate the latch 90°...

  • Page 39: Serial Port Connection

    POCi-W24C-ULT5 Medical Panel PC 3.7 RS-232 Serial Port Connection The bottom panel of the POCi-W24C-ULT5 has one DB-9 male connector for RS-232 connection. It is 1.5kV isolated. The pinouts of the DB-9 connector are listed below. RS-232 Table 3-1: RS-232 Serial Port Pinouts...

  • Page 40: Vesa Mounting

    POCi-W24C-ULT5 Medical Panel PC 3.8 VESA Mounting The POCi-W24C-ULT5 is VESA (4 screws: M4 type, 8 mm length min.) compliant and can be mounted on a mounting device with a 75 mm or a 100 mm interface pad. The POCi-W24C-ULT5 VESA mount retention screw holes are shown below. Refer to the installation guide that came with the mounting device to mount the POCi-W24C-ULT5.

  • Page 41: Powering On The System

    Connect the power adapter to the power connector of the POCi-W24C-ULT5. NOTE: The FSP FSP150M-ABA power adapter came with the POCi-W24C-ULT5 standard SKU is a forming part of the medical device. Figure 3-10: Power Input Connector...

  • Page 42: Figure 3-11: Power Input Connector

    Figure 3-11: Power Input Connector Step 2: Locate the power button on the right panel (Figure 1-6). Step 3: Short press the power button to turn on the POCi-W24C-ULT5. Step 0: NOTE: 1. The user can also long-press the touch button...

  • Page 43: Bios Setup

    POCi-W24C-ULT5 Medical Panel PC Chapter BIOS Setup Page 33...

  • Page 44: Introduction

    POCi-W24C-ULT5 Medical Panel PC 4.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 45: Getting Help

    POCi-W24C-ULT5 Medical Panel PC Decrease the numeric value or make changes F1 key General help, only for Status Page Setup Menu and Option Page Setup Menu F2 key Load previous values. F3 key Load optimized defaults F4 key Save changes and Exit BIOS Esc key Main Menu –...

  • Page 46: Main

    POCi-W24C-ULT5 Medical Panel PC 4.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc.

  • Page 47: Advanced

    POCi-W24C-ULT5 Medical Panel PC  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 4.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices...

  • Page 48: Cpu Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.3.1 CPU Configuration Use the CPU Configuration (BIOS Menu 3) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced CPU Configuration When enabled, a VMM can...

  • Page 49: Active Processor Cores [All]

    POCi-W24C-ULT5 Medical Panel PC  Active Processor Cores [All] Use the Active Processor Cores BIOS option to enable numbers of cores in the processor package.  Enable all cores in the processor package. EFAULT  Enable one core in the processor package.

  • Page 50: Pch-Fw Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.3.2 PCH-FW Configuration The PCH-FW Configuration menu (BIOS Menu 4) allows Intel® Active Management Technology (AMT) options to be configured. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced AMT BIOS Features [Enabled] When disabled AMT BIOS...

  • Page 51: Ptt Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.3.2.1 PTT Configuration Use the PTT Configuration menu (BIOS Menu 5) to configure settings related to the Trusted Platform Module (TPM). Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced PTT Capability / State...

  • Page 52: Trusted Computing

    POCi-W24C-ULT5 Medical Panel PC 4.3.3 Trusted Computing Use the Trusted Computing menu (BIOS Menu 6) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced...

  • Page 53: Acpi Settings

    POCi-W24C-ULT5 Medical Panel PC 4.3.4 ACPI Settings The ACPI Settings menu (BIOS Menu 7) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced ACPI Settings Select ACPI sleep state...

  • Page 54: Rtc Wake Settings

    POCi-W24C-ULT5 Medical Panel PC 4.3.5 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 8) configures RTC wake event. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event.

  • Page 55: Iwdd H/W Monitor

    POCi-W24C-ULT5 Medical Panel PC 4.3.6 iWDD H/W Monitor The iWDD H/W Monitor menu (BIOS Menu 9) shows the operating temperatures and voltages. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced PC Health Status CPU temperature : +36 °C...

  • Page 56: F81803 Super Io Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.3.7 F81803 Super IO Configuration Use the F81803 Super IO Configuration menu (BIOS Menu 10) to set or change the configurations for the serial ports. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced...

  • Page 57: Serial Port Console Redirection

    POCi-W24C-ULT5 Medical Panel PC  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.  Disable the serial port Disabled  Enabled Enable the serial port EFAULT 4.3.8 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 12) allows the console redirection options to be configured.

  • Page 58: Console Redirection Settings

    POCi-W24C-ULT5 Medical Panel PC 4.3.8.1 Console Redirection Settings Use the Console Redirection Settings menu ( B IOS Menu 13) to configure console 6 2 8 H redirection settings of the specified serial port. This menu appears only when the Console Redirection option is enabled.

  • Page 59: Data Bits [8]

    POCi-W24C-ULT5 Medical Panel PC  Sets the serial port transmission speed at 9600. 9600  19200 Sets the serial port transmission speed at 19200.  57600 Sets the serial port transmission speed at 57600.  115200 Sets the serial port transmission speed at 115200.

  • Page 60: Legacy Console Redirection Settings

    POCi-W24C-ULT5 Medical Panel PC 4.3.8.2 Legacy Console Redirection Settings The Legacy Console Redirection Settings menu ( B IOS Menu 14) allows the legacy 3 7 9 H console redirection options to be configured. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc.

  • Page 61: Usb Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.3.9 USB Configuration Use the USB Configuration menu (BIOS Menu 15) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 62: Csm Configuration

    POCi-W24C-ULT5 Medical Panel PC  Legacy USB support enabled Enabled EFAULT  Disabled Legacy USB support disabled  Auto Legacy USB support disabled if no USB devices are connected 4.3.10 CSM Configuration Use the CSM Configuration menu (BIOS Menu 16) to configure Compatibility Support Module (CSM).

  • Page 63: Nvme Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.3.11 NVMe Configuration Use the NVMe Configuration (BIOS Menu 17) menu to display the NVMe controller and device information. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Advanced NVMe Configuration No NVME Device Found --------------------- : Select Screen...

  • Page 64: System Agent (Sa) Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 19) to configure the System Agent (SA) parameters. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Chipset System Agent (SA) Configuration...

  • Page 65: Memory Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.4.1.1 Memory Configuration Use the Memory Configuration submenu ( B IOS Menu 20) to display the memory 6 3 2 H information. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Chipset Memory Configuration Memory Frequency...

  • Page 66: Graphics Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.4.1.2 Graphics Configuration Use the Graphics Configuration menu ( B IOS Menu 21) to configure the graphics 6 3 2 H settings. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Chipset Graphics Configuration Keep IGFX enabled based on the setup options.

  • Page 67: Pch-Io Configuration

    POCi-W24C-ULT5 Medical Panel PC  DVMT Total Gfx Mem [MAX] Use the DVMT Total Gfx Mem option to select DVMT5.0 total graphic memory size used by the internal graphic device. The following options are available:  256M  128M ...

  • Page 68: Power Saving Function(Erp) [Disabled]

    POCi-W24C-ULT5 Medical Panel PC  Power Saving Function(ERP) [Disabled] Use the Power Saving Function(ERP) BIOS option to enable or reduce power consumption in the S5 state. When enabled, the system can only be powered-up using the power button.  Disabled...

  • Page 69: Pci Express Configuration

    POCi-W24C-ULT5 Medical Panel PC 4.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 23) to configure the PCI Express slots. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Chipset PCI Express Configuration PCI Express Root Port Settings.

  • Page 70: Sata And Rst Configuration

    POCi-W24C-ULT5 Medical Panel PC  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to enable or disable detecting if a non-compliance PCI Express device is connected to the PCI Express slot.  Disables to detect if a non-compliance PCI...

  • Page 71: Sata Mode Selection [Ahci]

    POCi-W24C-ULT5 Medical Panel PC  SATA Mode Selection [AHCI] Use the SATA Mode Selection option to configure how the SATA controller(s) operate.  AHCI EFAULT Configures SATA devices as AHCI device.  Intel RST Configures SATA devices as RAID device.

  • Page 72: Security

    POCi-W24C-ULT5 Medical Panel PC 4.5 Security Use the Security menu (BIOS Menu 25) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Password Description Set Administrator Password If ONLY the Administrator’s password is set,...

  • Page 73: Boot

    POCi-W24C-ULT5 Medical Panel PC 4.6 Boot Use the Boot menu (BIOS Menu 26) to configure system boot options. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Boot Configuration Select the keyboard...

  • Page 74: Quiet Boot [Enabled]

    POCi-W24C-ULT5 Medical Panel PC  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.  Normal POST messages displayed Disabled  Enabled OEM Logo displayed instead of POST messages EFAULT ...

  • Page 75: Save & Exit

    POCi-W24C-ULT5 Medical Panel PC 4.7 Save & Exit Use the Save & Exit menu (BIOS Menu 27) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2020 American Megatrends, Inc.

  • Page 76: Save As User Defaults

    POCi-W24C-ULT5 Medical Panel PC  Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults.  Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options.

  • Page 77: Driver Installation

    POCi-W24C-ULT5 Medical Panel PC Chapter Driver Installation Page 67...

  • Page 78: Available Drivers

    POCi-W24C-ULT5 Medical Panel PC 5.1 Available Drivers All the drivers for the POCi-W24C-ULT5 are available on IEI Resource Download Center (https://download.ieiworld.com). Type POCi-W24C-ULT5, and press Enter to find all the relevant software, utilities, and documentation. Figure 5-1: IEI Resource Download Center 5.2 Driver Download...
  • Page 79 POCi-W24C-ULT5 Medical Panel PC Step 3: Click the driver file name on the page and you will be prompted with the  following window. You can download the entire ISO file ( ), or click the small  arrow to find an individual driver and click the file name to download (...

  • Page 80: A Regulatory Compliance

    POCi-W24C-ULT5 Medical Panel PC Appendix Regulatory Compliance Page 70...
  • Page 81 POCi-W24C-ULT5 Medical Panel PC DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU)  Low-Voltage Directive (2006/95/EC, 2014/35/EU)  RoHS II Directive (2011/65/EU, 2015/863/EU)  Medical Device Directive 93/42/EEC: EN 60601-1 ...
  • Page 82 POCi-W24C-ULT5 Medical Panel PC Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ...
  • Page 83 POCi-W24C-ULT5 Medical Panel PC Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU.
  • Page 84 POCi-W24C-ULT5 Medical Panel PC FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and  This device must accept any interference received, including interference ...
  • Page 85 POCi-W24C-ULT5 Medical Panel PC Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ROHS STATEMENT...

  • Page 86: B Product Disposal

    POCi-W24C-ULT5 Medical Panel PC Appendix Product Disposal Page 76...
  • Page 87 POCi-W24C-ULT5 Medical Panel PC CAUTION / ATTENTION Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Risque d'explosion si la batterie est remplacée par un type incorrect. Seuls les ingénieurs certifiés doivent remplacer la batterie embarquée.

  • Page 88: C Maintenance And Cleaning Precautions

    POCi-W24C-ULT5 Medical Panel PC Appendix Maintenance and Cleaning Precautions Page 78...
  • Page 89 POCi-W24C-ULT5 Medical Panel PC When maintaining or cleaning the POCi-W24C-ULT5, please follow the guidelines below. WARNING / AVERTISSEMENT If you dropped any material or liquid such as water onto the panel PC when cleaning, unplug the power cable immediately and contact your dealer or the nearest service center.

  • Page 90: Maintenance And Cleaning

    Some components in the POCi-W24C-ULT5 may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the POCi-W24C-ULT5. ...

  • Page 91: D Symbol Definitions

    POCi-W24C-ULT5 Medical Panel PC Appendix Symbol Definitions Page 81...
  • Page 92 POCi-W24C-ULT5 Medical Panel PC The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special definition, as defined below: Direct current Fragile, handle with care AC current Keep dry Protective earth (ground) This side up...

  • Page 93: Ebios Menu Options

    POCi-W24C-ULT5 Medical Panel PC Appendix BIOS Menu Options Page 83...
  • Page 94 POCi-W24C-ULT5 Medical Panel PC System Date [xx/xx/xx] ......................36 System Time [xx:xx:xx] ....................... 37 Intel (VMX) Virtualization Technology [Disabled] ............. 38 Active Processor Cores [All] ....................39 Hyper-Threading [Enabled] ....................39 ® Intel SpeedStep(tm) [Enabled] ..................39 CPU C State [Disabled] ......................39 AMT BIOS Features [Enabled] ....................
  • Page 95 POCi-W24C-ULT5 Medical Panel PC Detect Non-Compliance Device [Disabled] ............... 60 STAT Controller(s) [Enabled] ....................60 SATA Mode Selection [AHCI] ....................61 PCIe Storage Dev On Port M2_M1 [Not RST Controlled] ..........61 Administrator Password ..................... 62 User Password ........................62 Bootup NumLock State [On] ....................

  • Page 96: F Watchdog Timer

    POCi-W24C-ULT5 Medical Panel PC Appendix Watchdog Timer Page 86...
  • Page 97 POCi-W24C-ULT5 Medical Panel PC NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working.
  • Page 98 POCi-W24C-ULT5 Medical Panel PC NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 99: G Hazardous Materials Disclosure

    POCi-W24C-ULT5 Medical Panel PC Appendix Hazardous Materials Disclosure Page 89...

  • Page 100: Rohs Ii Directive (2015/863/Eu)

    POCi-W24C-ULT5 Medical Panel PC G.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 101: China Rohs

    POCi-W24C-ULT5 Medical Panel PC G.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 91...
