1 Introduction

The SAM3Gplus is a compact, light-weight, UMTS, HSPA based modem. It provides GSM, GPRS, EDGE
and WCDMA connectivity. The SAM3Gplus is a quad-band GSM/GPRS/EDGE 850MHz, 900MHz, 1800MHz,
1900MHz and a quad-band WCDMA/HSDPA : 850MHz, 900MHz,1900MHz, 2100MHz
The SAM3Gplus is designed for both mobile and fixed M2M applications. It has an RJ45 socket for both
input voltage and serial RS232 signals, a MiniB USB connector, a SMB-Jack for antenna connection, a SIM
holder and an LED indicator.
WARNING: You should never connect the USB and the RS232 at the same time.
The SAM3Gplus is capable of sending/receiving SMS; Circuit switched data and Packet-switched data.
SIM holder
LED indicator
Mini USB connector
Type Approval
Mobile station modem Version
TA code
EU approval
2
RJ45 for input power and serial RS232
GCF full type approval
Qualcomm's MSM6290
35362602
CE-0682
SMB-Jack antenna
connector
