Design and function

3 1

Scope of supply

1
9
A T
S 3
0 8
0 P
o w
e r
0
P a
c k
Po
we r
Si gn
al
8 7
1 Autotool System 3080 (ATS3080)
2 Jaws diameter 30 mm, diameter 50 mm and diameter 80 mm
3 Service box
4 Case, complete with 2 keys
5 User video DVD for the Operating instructions
6 Operating Instructions
7 Connecting cable 2 m (for connecting power pack 3080 and ATS3080)
8 Power pack 3080
9 Power cable 1.8 m
Operating Instructions • ATS3080 • 02-2017 • v01 • 102-01002
2
6 5
3
4
Contents of the service box
10 Screwdriver 2 mm Allen screw
11 Screwdriver PH0 50
12 Tie head puller (5x)
13 Limit 80
For article numbers for the accessories, à "Accessories and
extras" on page 18
Checking scope of supply
f Check that nothing is missing and that there are no
visible signs of damage in transit or other damage.
f Have damage confirmed by the freight forwarder and
notify HellermannTyton immediately in writing.
Design and function
3
10
11
5x
12
13
9
