Technical Data; Ats3080 - HellermannTyton Autotool System 3080 Operating Instructions Manual

9

Technical data

9 1

ATS3080

113,8
50,1
7,8
22 39
Max power draw
Input voltage
Weight
Bundle thickness
Dimensions
Operating Instructions • ATS3080 • 02-2017 • v01 • 102-01002
Ø d
Value Jaws diameter 30 mm
diameter d 30 mm
a 272 mm
b Max. 111 mm
c Max. 64 mm
e Max. 50 mm
a
Jaws diameter 50 mm
60 W
48 V
approx. 1900 g
50 mm
293 mm
Max. 134 mm
Max. 68 mm
Max. 50 mm
Technical data
Jaws diameter 80 mm
80 mm
329 mm
Max. 175 mm
Max. 80 mm
Max. 50 mm
22
