Cross Line Detection - Interlogix TruVision 5 Series Configuration Manual

Notify Alarm Recipient
Send Email
Upload Snapshot
Trigger Channel
Trigger Alarm Output
7. Click Save to save changes.

Cross line detection

This function can be used to detect people, vehicles and objects crossing a pre-defined
line or an area on-screen. The line crossing direction can be set as unidirectional or
bidirectional. Unidirectional is crossing the line from left to right or from right to left.
Bidirectional is crossing the line from both directions.
A series of linkage methods can be triggered if an object is detected crossing the line.
TruVision Series 5 IP Camera Configuration Manual
Send an exception or alarm signal to remote management
software when an event occurs.
Sends an email to a specified address when there is a face
detection alarm.
Note: You must configure email settings before enabling this
option. See "To set up the email parameters" on page 17 for
further information. If you want to send the event snapshot
together with the email, check the Attached Snapshot option.
Capture the image when an alarm is triggered and upload the
picture to NAS or FTP server.
Note: To upload the snapshot to NAS, you must first configure
the NAS settings. See "NAS settings" on page 49 for further
information.
To upload the snapshot to an FTP, you must first configure the
FTP settings. See "To define the FTP parameters" on page 17
for further information. Enable the
To upload the snapshot to FTP and NAS when motion
detection or an alarm input is triggered, you must also enable
Enable Event-triggered Snapshot
parameters. See "Snapshot parameters" on page 48 for further
information.
Triggers the recording to start in the camera.
Trigger external alarm outputs when an event occurs. Check
"Select All" or each individual alarm output.
Note: This option is only supported by cameras that support
alarm output.
Upload Type option.
under the snapshot
41
