- Page 1 S E L E C T I O N T H E S T R E N G T H E V O L U T I O N Glute User manual All equipment...
-
Page 2: Table Of Contents
Contents Identification of the manufacturer and equipment ......3 Description of the equipment ............4 Technical data ................... 5 Safety devices and warnings ............6 Place of installation ................8 Fitting the cam covers ............... 9 Fitting the number holder ..............10 Lifting and moving the equipment ........... -
Page 3: Identification Of The Manufacturer And Equipment
Identification of the manufacturer and equipment The identification plate of the equipment and manufacturer, placed under the padding, gives the following details: A Manufacturer's name and address B CE Mark C Serial number D Maximum user weight E Equipment classification F Consultation of user manual required Glute... -
Page 4: Description Of The Equipment
Description of the equipment A Padding: the user rests his abdomen against it when exercising. B Lever: operated by the user by means of rollers (C); before starting to exercise, or between one set and the next, the ROM device may be used to adjust the starting position thus modifying the range of motion. -
Page 5: Technical Data
Technical data 1316 mm (52") 1240 mm 1307mm (48") (52") 262 kg (578 lb) 70 kg (140 lb) Glute... -
Page 6: Safety Devices And Warnings
Safety devices and warnings The maximum user weight is 180 kg (397 lb). The outside of the weight stack is covered by a protective panel. The equipment has no sharp corners. All parts which come into contact with the user's body are suitably protected with rubber coverings or padding. Pay particular attention to the parts of the equipment with labels indicating “BEWARE OF CRUSHING”. - Page 7 Safety devices and warnings WARNINGS Attention must be paid to the labels attached to the equipment, as they provide information about possible risks and hazards. We recommend immediately replacing the labels when they become damaged or difficult to read. Glute...
-
Page 8: Place Of Installation
Place of installation To ensure safe, comfortable and effective use of the equipment, the place of installation must comply with certain specific requirements; in particular, before choosing where to install the equipment we recommend that you check that the following conditions are available: a temperature between +10°C and +25°C;... -
Page 9: Fitting The Number Holder
Fitting the number holder The number holder must be installed immediately under the top: standing facing the equipment, attach the number holder on the left, on the cover of guide rail (A). Find the place where the two screws (B) are to be inserted. Attach the number holder using the two screws;... -
Page 10: Lifting And Moving The Equipment
Lifting and moving the equipment Use the castors (optional) to move the equipment. WARNING Move the equipment very carefully, because it may become unstable and tip over. The wheels for moving the equipment snap on underneath the feet of the equipment, after it has been raised, and are held in place by the special straps. - Page 11 Lifting and moving the equipment Proceeding in the same way, lift the equipment on the padding side and insert the castors. Lastly, lift the equipment again, remove the safety wedges and place the wheels on the floor. WARNINGS When moving the equipment, push it only from the weight stack side, and not from the other sides.
- Page 12 Lifting and moving the equipment WARNING Do not push against the range of motion (ROM) adjustment lever to move the equipment: this may lead to damage and instability. Glute...
-
Page 13: Adjusting The Equipment
Adjusting the equipment After the equipment has been positioned on the floor, check that it is level. An adjuster screw, indicated by two embossed arrows, is supplied for this purpose under foot (A). Raise the equipment and adjust the screw until the equipment is level. WARNING Given the weight of the equipment, we recommend that it should always be lifted by more than one person. -
Page 14: Routine Maintenance
Call the Technogym Technical Support Service for instructions on any maintenance operations not described in this manual. Glute... -
Page 15: Replacing The Padded Parts
Replacing the padded parts If any of the padding shows signs of wear, especially in the interests of hygiene, we recommend replacing them completely. To replace the rollers remove cover (A) and unscrew screw (B); then remove washer (C) and roller (D). Glute... -
Page 16: Replacing The Cable
WARNINGS Carefully check the state of the cables once a month. ALWAYS use cables supplied directly by Technogym. To replace the cable, proceed as follows: remove the protective panel covering the weight stack, following the instructions found in the paragraph headed Removing the front weight stack panel;... - Page 17 Replacing the cable insert the new cable from the adjuster side (ensuring that it follows the same route as the original cable, as shown in the illustration); insert screws (A), screw in adjuster (C), and tighten lock nut (B); refit the protective panel on the weight stack Glute...
-
Page 18: Adjusting Cable Tension
Adjusting cable tension It is possible to take up some of the slack in the weight stack cable using adjuster (C), after loosening lock nut (B). WARNING To pull the cable taut after replacement, it may be helpful, when tightening screws (A), to insert a thickness of approx. 10 mm (1/2 inch) under the first weight in the weight stack. -
Page 19: Removing The Front Weight Stack Panel
Removing the front weight stack panel The front protective panel on the weight stack is fixed to the frame by eight screws. To remove the panel, you must: remove the four screws (A); remove the four screws (B) while holding the panel with one hand; remove the panel. -
Page 20: Technical Service
When contacting the Technogym Technical Support Service, please specify the following details: equipment model, date of purchase, serial number, precise description of the problem. WARNING Any operations carried out by persons not authorized by Technogym on the equipment will invalidate the warranty. Glute... -
Page 21: Storage
Storage If the equipment is not expected to be used for a prolonged period, we recommend storing it: in a clean and dry place, covered with a cloth to protect it from dust; in an environment with a temperature between +10°C and +25°C and humidity between 20% and 90%. Use the original packing materials, to better preserve the equipment. -
Page 22: Disposal
Disposal It is always good practise to ensure that the equipment can never constitute a hazard; therefore do not leave the equipment where children may play with it. Do not dump the equipment in the environment, or in public areas or private areas accessible to the public. The equipment is made from recyclable materials such as steel, aluminium and plastic, which must be disposed of in the manner prescribed by the urban refuse collection regulations in force, by firms specialised in urban and environmental hygiene. -
Page 23: Using The Equipment
Using the equipment To access the platform comfortably, push the button on the end of ROM lever (A), and move rollers (B). Standing on platform (C) center your hip with the ROM lever rotation point. Select the workload with pin (D). Select the desired start position using ROM lever (A). - Page 24 Using the equipment With your hips firmly against the pad, grasp the handgrips and push your leg back. Maintain a smooth controlled speed; we recommend a slower speed during the return phase than during the approach phase. To exercise with the other leg, reverse sides and repeat from point 1. Glute...
