  • Page 1 CLUX-31GAME 3×1 HDMI Switcher Operation Manual Operation Manual...
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
  • Page 5: Table Of Contents

    CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Top Panel ...........3 6.2 Front Panel .........3 6.3 Side Panels .........4 6.4 Rear Panel .........4 7.
  • Page 6: Introduction

    1. INTRODUCTION This 3×1 HDMI Switcher allows the user to input three HDMI sources and easily switch between these sources to provide a single HDMI output to a display or AV receiver. The CEC and EDID bypass function allows HDMI devices to turn both the source and display on or off with a simple touch.
  • Page 7: Features

    5. FEATURES • HDMI, HDCP 1.1 and DVI 1.0 compliant • Supports 30/36-bit color depth display • Supports High Definition audio – Dolby Digital TrueHD and DTS-HD Master Audio • Includes an Automatic Signal Enhancement feature that can improve signal quality over long distances. •...
  • Page 8: Operation Controls And Functions

    6. OPERATION CONTROLS AND FUNCTIONS 6.1 Top Panel CLUX-31GAME 3 x 1 HDMI v1.3 SWITCHER INPUT INPUT LED Indicators: These LEDs will light to indicate the currently selected input. 6.2 Front Panel INPUT INPUT Switch: Press this button repeatedly to cycle through the input sources, the LED on the top panel will illuminate to indicate the active input.
  • Page 9: Side Panels

    6.3 Side Panels INPUT INPUT HDMI INPUT 1/2/3: Connect to HDMI source devices such as a games console with HDMI cables or a DVI source device such as a PC (with DVI to HDMI cables, available separately). 6.4 Rear Panel DC 5V OUTPUT USB 5V...
  • Page 10: Connection Diagrams

    7. CONNECTION DIAGRAMS Example 1: USB power from a spare USB connection on an HDTV Set-top Box DVD or Blu-ray Player Game Console HDMI Input HDMI Input HDMI Input USB Power (Optional) HDMI Output HDTV...
  • Page 11 Example 2: Using an optional 5V/1A DC power supply (available separately) Set-top Box DVD or Blu-ray Player Game Console HDMI Input HDMI Input HDMI Input Power Supply (Optional) HDMI Output HDTV...
  • Page 12: Specifications

    8. SPECIFICATIONS Frequency Bandwidth 2.25 Gbps (single link) Input Ports 3×HDMI Female Ports (Type A Connector) Output Port 1×HDMI Female Port (Type A Connector) Power Supply Power over USB to Mini-B Cable* (Optional) OR 5 V/1 A DC Power Supply* (US/EU standards, CE/FCC/UL certified) (Optional) ESD Protection Human body model:...
