Charging Using an Electrical Outlet

1. Insert a Standard Battery into
the Infinea X device, and then
attach the Charging Cup to the
bottom of the Infinea X. Listen
for a click to ensure the device is
fully seated in the cup.
2. Plug the USB connector end
of the Charging Cup into an
AC wall adapter (2.1 A), and
then confirm the Infinea X LED
indicator on the left side of the
device turns green to indicate
charging is active.
3. To check the battery life, you
can press the Battery Status
button and look at the status
LEDs. Refer to the Battery
Status table on Page 17 to
determine the battery life in
relation to the LEDs.
To prevent electrical damage to the Infinea X and/or battery, please use the
approved Charging Cup shipped with device.
Page 18
