ASSEMBLING THE INFINEA X

iPhone Installation

1. Open the Infinea X by loosening the
socket head hex screws and gently
flipping open the top cover.
2. On the i0S device, set the Ring
Silent switch to Ring Mode. Slide
the iOS device* onto the Lightning
Connector until it clicks into place.
Note: Infinea X is molded specifically to
the compatible iOS devices listed at the
beginning of this manual. iOS devices are
not interchangeable.
4. Secure the cover by tightening the
(6) socket head hex screws in the
upper enclosure in the following
order:
• Top Left
• Bottom Right
• Top Right
• Bottom Left
• Center Left and Right
Note: Do not over tighten screws as it
may cause damage to the cover. The
recommended torque is 2 lbs. max.
Take care that the rubber bumper is properly aligned between the top and
bottom covers. Failure to do so will compromise the liquid protection features
of the Infinea X.
3. Close the top cover while maintaining
the position of the protective rubber
bumper.
Note: Before closing the top cover, wipe the
interior glass with a clean, lint-free cloth to
ensure your screen is clean and free from
moisture.
Page 15
