INSTALLING THE BATTERY PACK

Standard and Extended Battery Installation

The Infinea X is designed to support Standard and Extended external swappable
battery packs. The swappable battery pack design reduces down time of the
Infinea X. Follow the steps below to install or replace your Infinea X battery pack.
1. Check that the battery latch is in the
fully open position.
Take care not to force the battery into place if the latch is in the close/
lock position.
3. With slight pressure on the backside
of the battery pack, rotate the latch
counter-clockwise 90-degrees, or until
the battery is securely locked in place
as shown in the figure on the right.
2. Lower the battery pack into place as
shown in the figure on the left. The
battery should sit flat when installed
correctly.
Page 16
