Smart SAM4Q User Guide V1.1
1 Introduction
The Smart SAM4Q is a compact, light-weight, 3G and LTE based modem. It provides CAT1 speed of 5Mbps
upload and 10Mbps download.
The Smart SAM4Q is designed for both mobile and fixed M2M applications. It has an RJ45 socket for input
voltage and the serial RS232 signals, an FME-male for antenna connection, a SIM holder and an LED indicator.
The Smart SAM4Q is capable of sending/receiving SMS, Circuit Switched Data in 3G mode and Packet-
Switched Data.
Mini-USB port
RJ45 socket for input power and serial RS232
Mobile station engine
EU approval
3GPP
RCM tick mark
2
FME male for antenna
EC21-AUT
CE-2202
CAT1
Ver1.1
Mini-SIM compartment
LED
