- Page 1 TECHNICAL TECHNICAL STUDY SUPPORT SERVICE t e c h n i c a l Washer-Dryer PRODUCT Fagor /Edesa 2006 RANGE: Date: 13/11/06 Document No: 11238...
- Page 2 Important: correct understanding of the product. © Copyright by Fagor Electrodomésticos S.Coop. 2006. All rights reserved. The total or partial reproduction of this document, by any procedure and on any type of media, is prohibited without written authorisation from the holder of the usage rights.
-
Page 3: Table Of Contents
t e c h n i c a l Table of contents 1.- Warnings and precautions ........1 2.- Features ..............2 3.- Description of operation ........4 3.1.- General description ............. 4 3.1.1.- Start-up ..............5 3.1.2.- Locking ..............6 3.1.3.- Extra rinse ............6 3.1.4.- Flot/Anti-crease ............. -
Page 4: Warnings And Precautions
t e c h n i c a l Warnings and precautions 1.- Warnings and precautions The maximum recommended amount of clothes to be dried is the equivalent of 1.5 kg dry weight of delicate fabrics, and 2.5 kg dry weight of other fabrics. Therefore, if a full load of clothes is washed, and is then to be dried, this load must be divided into two loads for drying. -
Page 5: Description Of Operation
Description of operation 3.- Description of operation 3.1.- General description FAGOR 3FS-3611 Select Class Turbo Time 1100 r.p.m. Time ON/OFF delay Detergent button Programme button Drying time Start drawer selector Display Spin + flot... - Page 6 t e c h n i c a l Features 2.- Features The wash options must always be selected after selecting the wash programme. Any change of programme during the selection annuls the options which were previously selected. Select a) Spin selection and anti-crease (fl ot) button. The selected programme has an associated spin speed.
- Page 7 t e c h n i c a l Features Additional functions Button for selecting additional functions according to programmes. a) There are 3 options: easy iron, intensive wash, extra rinse. Press the button to display the required option. b) By clicking several times you can choose between various combinations, of one, two, Select and even three additional functions at the same...
-
Page 8: Start-Up
t e c h n i c a l Description of operation 3.1.1.- Start-up To select the wash and dry programme, follow these steps: a) Turn the machine on with the ON / OFF button. b) Pull the programme selector out to activate it. c) Select the wash programme by turning the pro- gramme selector control (see programme table). - Page 9 t e c h n i c a l Description of operation There are 4 types of programme available PROGRAMMES Normal Delicate Additional Drying Normal cold Delicate cold Rinses Normal drying Normal programmes Fast 30ºC Delicate 30ºC Spin Delicate drying Normal 30 ºC Delicate 40ºC Empty/End...
-
Page 10: Flot/Anti-Crease
t e c h n i c a l Description of operation 3.1.4.- Flot/Anti-crease Option - With this option the programme stops before emptying the last rinse; for the programme to continue, the Flot option must be unlocked Note: The wash options must always be selected after selecting the wash programme. -
Page 11: Diagram Of Drying Function
t e c h n i c a l Description of operation 3.2.- Diagram of drying function 700 + 700W drying elements Single cycled thermostat 85º Double cycled Thermostat 170º safety 95º Turbine Hot air Dry air Outer Drum Casing 0.35l/m Drum flow... -
Page 12: Programme Table
t e c h n i c a l Description of operation 3.3.- Programme table:... -
Page 13: Components
t e c h n i c a l Description of operation 3.4.- Components Function Features Component Used in machines with Motor Voltage: 220V / 50 Hz variable spin and makes rotating movements when Stator resistance: 1.3 Ω washing and spinning. Rotor resistance: 1.7 Ω... - Page 14 t e c h n i c a l Description of operation NTC Temperature / Resistance values Temperature(ºC) <30 Resistance (K Ω) >40 Component Function Features Drains the water from Voltage: 220 v / 50 Hz Drainage pump inside the drum Drainage rate: 16 litres/ minute Maximum drainage...
- Page 15 t e c h n i c a l Description of operation Function Features Component Heating element Resistance: 25,4 Ω Heating resistance Material: Real stain- less steel Power: 1850w Voltage: 220 v Display circuit Display Voltage: 220 v / 50 Hz Circuit Voltage: 220 v / 50 Hz Power circuit...
-
Page 16: Circuit Confi Guration
Description of operation 3.5.- Fagor circuit confi guration: 3.1.3.- Fagor circuit configuration: status as soon as it is plugged in If the circuit is not configured, it will go into (go to step no. 7). If the circuit is configured it enters the current configuration. - Page 17 t e c h n i c a l Description of operation Confi guring an Edesa Circuit: When a circuit is replaced or changed, it must be confi gured. To confi gure the circuit, follow these steps. 1.- Move the function selector knob to position 0. 2.- Set the r.p.m.
- Page 18 TSS programme entrando en el programa SAT (See table 1) • Fagor T.S.S. Programme: In order to check the operation of the washing machine’s electric components, the T.S.S. programme can be activated by following these steps: 1.- General ON / OFF switch (LCD off)
-
Page 19: Troubleshooting
t e c h n i c a l Description of operation 3.6.- Troubleshooting 3.6.1.- T.S.S. Programme TIME PROGRAMME SELECTION MODE (approx) Drying Motor Power supply + Resistance 1 (3.6 Amp) seconds Drying Motor Power supply + Resistance 1 and 2 (7 Amp) seconds Water input via Pre-wash electrically operated... - Page 20 t e c h n i c a l Description of operation 3.6.2.- Seguridades criterios SAFETY FAULT CONDITION WASHER ACTION RESET MECHANISMS (End of safety) FILLING EV ON 8 min. and PN It remains on pause with OFF (empty) door lock ON (except in reliability programme) UNBALANCED...
-
Page 21: Imbalance Detection
t e c h n i c a l Description of operation 3.6.3.- Imbalance Detection DETECTION LEVEL WHEN WASHING 650 gr. DETECTION LEVEL FOR LOW SPIN 750 gr. DETECTION LEVEL FOR HIGH SPIN 1520 gr. Note: These data are for a belt tension of 120 Hz and a SELNI motor Function in the stop programme end While PN is kept off Door lock OFF &... - Page 22 t e c h n i c a l Description of operation 3.6.4.- Imbalance Operation 1. - Spin attempts If an imbalance is detected, the present phase will restart at second 25. The number of attempts is limited to 18 (15 minutes). After 18 spin attempts, it checks whether the imbalance level is lower than the high imbalance level (1520 g).
- Page 23 t e c h n i c a l Description of operation Wash vibrations...
- Page 24 t e c h n i c a l Description of operation Easy iron phase...
- Page 25 t e c h n i c a l Description of operation Normal spin diagram...
-
Page 26: Assembly And Disassembly Instructions
t e c h n i c a l Description of operation 3.7.- Assembly and disassembly instructions (A) Disassembly of the Evoluta Condensation Chamber Undo the three screws that fi x the condensation chamber to the drum (Thor screws) Disconnect thermostat cables Disconnect fan motor cables Loosen the 2 screws which hold the Evoluta to the Muffl... - Page 27 t e c h n i c a l Description of operation (F) Changing the Muffl er Duct Loosen the screws which hold the Counterweight to the Muffl er Duct Loosen the two screws which hold the Chamber-Evoluta to the Muffl er Duct Undo the three fi...
- Page 28 t e c h n i c a l Description of operation 3.8.- Drawings and diagrams...
- Page 29 © FAGOR ELECTRODOMESTICOS, S.COOP. 2006 Bº San Andrés, s/n 20500 Mondragón (Gipuzkoa) Spain...
