- Page 1 User Manual ULTRA HIGH SPEED BURNISHER DR1500H-EU User Manual………………………….. English Dansk Brugermanual…………………………..… 10-18 Bruksanvisning…………………………… Svenska 19-27 Brukerhåndbok……………………………. Norsk 28-36 Käyttöopas....……………………… 37-45 Suomi Information om firmaet: www.vipercleaning.eu info-eu@vipercleaning.com 41528EU (1) – 2009-01-01...
-
Page 2: Table Of Contents
SYMBOLS ..............................3 GENERAL INSTRUCTIONS ........................4 MACHINE DESCRIPTION ....................6 MACHINE STRUCTURE ..........................6 TECHNICAL DATA ............................. 7 WIRING DIAGRAM FOR DR1500H-EU ....................8 OPERATION OF MACHINE ..................... 9 BASIC OPERATION ........................... 9 MAINTENANCE ............................9 STORAGE ..............................9... -
Page 3: Introduction
It contains information about technical data, safety, operation, storage, maintenance, spare parts and disposal. Before performing any procedure on the machine, the operators and qualified technicians must read this Manual carefully. Contact VIPER in case of doubts concerning the interpretation of the instructions and for any further information. -
Page 4: Changes And Improvements
ENGLISH CHANGES AND IMPROVEMENTS VIPER constantly improves its products and reserves the right to make changes and improvements at its discretion without being obliged to apply such benefits to the machines that were previously sold. Any change and/or addition of accessories must be approved and performed by VIPER. -
Page 5: General Instructions
To avoid any risk, if the power supply cable is damaged, contact VIPER Service Center or a qualified technician. Do not pull or carry the machine by the power supply cable and never use the power supply cable as a handle. Do not close a door on the power supply cable, or pull the power supply cable around sharp edges or corners. - Page 6 VIPER Service Center or a qualified technician. If parts must be replaced, require ORIGINAL spare parts from VIPER Dealer or Retailer. To ensure machine proper and safe operation, the scheduled maintenance shown in the relevant chapter of this Manual, must be performed by the authorised personnel or by VIPER Service Center.
-
Page 7: Machine Description
Folding handle Die-cast aluminum deck Handle grip Safety lock-out button Folding handle for easy storage Bumper Deck Safety lock-out switch Wheel Flexible pad driver Large rear transport wheels Handle-mounted circuit breaker DR1500H-EU 41528EU(1)2008-12 A... -
Page 8: Technical Data
USER MANUAL ENGLISH TECHNICAL DATA Model DR1500H-EU Voltage 220-240 V Power 1100 W Current 6.5 A Frequency 50-60 Hz 1500 20” (51 cm) Deck Size Length of Power cord 15 m Weight 39 Kg Dimensions L: 83.8 cm W: 53.3 cm H: 120.6 cm... -
Page 9: Wiring Diagram For Dr1500H-Eu
ENGLISH USER MANUAL WIRING DIAGRAM FOR DR1500H-EU Switch Housing Circuit Switch Breaker Brown Brown Black 220V 50/60Hz Blue Blue Motor Single Phase Green Power Supply H05VV-F 1.5/3C Handle Capacitor Power Cord 34μF/500V Supply Cord 41528EU(1)2008-12 A DR1500H-EU... -
Page 10: Operation Of Machine
