Viper AS6690T Series Use And Maintenance

Use and maintenance
Operating guidelines AS6690T / AS7690T / AS7190TO series
Turn on the key and verify there is enough battery
power to complete the work. Charge batteries
if required.
Disc version: install the brushes/pad holders manually, then press the One button start icon to enable scrubbing.
The deck will lower automatically, and the vacuum will start.
Orbital version: attach a pad to the fi xed pad holder, press the One button start icon and the deck will lower
automatically.
Press the One button start icon and then press and
hold any of the two red safety switches to activate
the machine.
Pressing either of the red safety switches and the
black reverse button together will put the machine
into reverse.
March 2020
Install the squeegee using the thumb nuts.
Attach squeegee hose.
Press the + or – buttons to increase / decrease the
water fl ow rate and/or brush pressure.
Press the Floor Finish Removal icon (orbital only) for
removing fi nish: pad pressure will be set to maximum,
solution fl ow will be set to minimum & machine speed
will be held at 1.0 km/h (0.6 mph).
Remove the red cover and fi ll the tank with water, max
temperature 40C/104F. Add appropriate low foaming
detergent. Maximum tank capacity 85L/22Gal. Check
solution level with red ball on the side of the machine.
Use the handle to lower or raise the squeegee to
the fl oor. Adjust the squeegee angle with the knob
to maximize solution pickup performance if necessary.
Use the turtle/rabbit knob to adjust the speed of
the machine.
On the disc version, the brush/pad holder can be
removed automatically by raising the deck and then
pressing the click off icon.
