- Page 1 Ride-on Scrubbers USER MANUAL READ USER MANUAL CAREFULLY BEFORE USE Please fill out & return your warranty card Model # Serial No.# VIPER INDUSTRIAL ESTATE LIANG BIAN, LIAO BU DONGGUAN, GUANGDONG VIPER…exceptional value CHINA VR10029 REV.01 TEL: (0769)83293988 2014-12-30 FAX: (0769)83280104...
- Page 6 USER MANUAL SAFETY PRECAUTIONS This machine is intended for commercial use. It is constructed for use in an indoor environment and is not intended for any other use. Use only with recommended accessories. All operators shall read, understand and exercise the following safety precautions: 1) DO NOT OPERATE MACHINE: Unless trained and authorized.
- Page 7 USER MANUAL Batteries emit hydrogen. Explosion or fire can result from hydrogen. Keep sparks and open flames away! It is recommended to push the button (C2) to turn recovery tank open before charging. Flammable materials can cause an explosion or fire. Do not use flammable materials in tanks.
- Page 9 USER MANUAL 7. Make sure solution tank water indicator (E10) is not on. If on, fill water in solution tank (A4). 8. Check that the water valve (D2) is not indicated “0”. INSTALLING PAD DRIVER OR BRUSH 1. Ensure that the machine is turned off (E5). 2.
-
Page 10: Machine Operation
USER MANUAL Use only low-foam and non-flammable detergents suitable for ride-on scrubber applications. Each time when you need to fill the solution tank, always empty and clean the recovery tank by removing the drain hose plug(C1). After each use, unscrew the drain cap (D1) to drain solution tank. -
Page 11: Battery Charging
USER MANUAL 5. Turn on the brush motor switch.(E3) 6. Depress the driver pedal slowly (C6) and turn steering wheel (A14) to forward. The speed can be controlled by a dial (E6), turning left decreases speed, and turning right increases speed. And to reverse, you can press the switch (E7). -
Page 12: Machine Storage
USER MANUAL 2. Turn machine off (E5). 3. Plug approved charger into grounded wall outlet. Open transparent cover (A9), and then connect the charging cable to the machine socket (F1). 4. The charger will automatically begin to charge the batteries. 5. - Page 13 USER MANUAL SCHEDULED MAINTENANCE TABLE Procedure After each use Weekly Every six mouths Annually Battery charging Clean Squeegee Clean Brush/Pad Clean Tank and vacuum grid with float, cover gasket check Squeegee blade check and replacement Recovery filter cleaning Clean solution pipe filter Screw and nut （...
- Page 14 USER MANUAL LED SCREEN DISPLAY INFORMATIONS STOP Machine doesn’t move and brush doesn’t work, vacuum motor can work 00012.3 Machine add up driver time is 12.3hours L0-18 Batteries voltage is lower 18V U-25.5 Batteries voltage is 25.5V ERR-01 Squeegee pulls down before machine reverse DRIVE MOTOR ERROR INDICATOR INFORMATION LED FLASH CODES EXAMPLE, ¤¤...
- Page 15 USER MANUAL Parameter Model AS710R 1580*760*1230 Machine length/width/height 120L Solution tank capacity 120L Recovery tank capacity 300MM Rear wheels diameter 2x300W Brush motor power Vacuum motor power 500W Drive motor power 500W Max. driver speed 6km/h Sound level 69dB(A) Batteries length/width/height(standard)
-
Page 16: Troubleshooting
USER MANUAL TROUBLESHOOTING Trouble Possible Cause Remedy The battery connector is disconnected Connect. The machine does not work, LED screen (E1 ) does not turns on The batteries are completely discharged Charge the batteries The machine does not work, The batteries are discharged Charge the batteries indicator light ( E11) is red The PCB or key board is broken... - Page 18 Company information: www.vipercleaning.eu info-eu@vipercleaning.com...
