Dacor Renaissance ER30D Planning Manual

Document # PG05-003
46 1/4" (117.5 cm)
1 9/16"
(4.0 cm)
Width at front panel:
29 7/8" (75.8 cm)
FREESTANDING MODELS ER30D AND ER30D-C
NOTE: Models ER30D and ER30D-C are NOT designed for
use with self-rimming installations or downdraft vents.
Use model ER30DSR for self-rimming and downdraft vent
installations.
1 9/16"
(4.0 cm)
1 5/16" (3.3 cm) to cooking
surface (top of grates) from
bottom of trim
Width at front panel:
29 7/8" (75.8 cm)
SELF RIMMING MODEL ER30DSR
SIDE DIMENSIONS
WITH OPTIONAL DOWNDRAFT VENT
TRIM KIT INSTALLED (ATK30SR)
All specifications subject to change without notice.
ER30D, ER30DSR
Renaissance
Dual Fuel Ranges
28 13/16" (73.2 cm)
27 5/16" (69.4 cm)
26 5/16" (66.8 cm)
24 1/4" (61.6 cm)
1 1/16" (2.7 cm)
3" (7.6 cm)
Backguard*
1 1/16" (2.7 cm) to cooking
surface (top of grates) from
top of trim
35 3/4"
(90.8 cm)
Finished side panel
37 7/8"
(96.2 cm)
Front of open door
46 1/8" (117.2 cm)
28 11/16" (72.9 cm) Front of handle
27 3/16" (69.1 cm) Front edge of bullnose
26 3/16" (66.5 cm) Front panel
24 1/8" (61.3 cm) Rear of front panel /oven door
23 1/8" (58.7 cm) Rear of front panel to
back of chassis
35 3/4"
(90.8 cm)
to
37 7/8"
(96.2 cm)
® 30" Wide
Product tolerances: ±1/16" (±1.6 mm) unless otherwise stated
•
•
6" (15.2 cm)
Backguard**
NOTE:
■
*
Standard
■
** Optional
to
1 9/16"
(4.0 cm)
Width at front panel:
29 7/8" (75.8 cm)
Range Model
ER30D/ER30DSR
* 4-wire, two 120 Vac hot (L1 and L2), one neutral, one ground
◊ The ratings above are for reference only - refer to the range rating
label.
◊ Model ER30D-C is a freestanding range that comes with a factory
installed 4-wire appliance cord and NEMA 14-50P plug. This wiring
configuration is required for freestanding ranges installed in Canada,
although they may be used elsewhere, if local codes permit. The plug
is designed to plug directly into a NEMA 14-50R electrical receptacle
installed by a licensed electrician according to specifications. Do not
modify the factory wiring on model ER30D-C.
www.dacor.com
PLANNING
WARNING
Observe all governing codes and ordinances during
planning and installation. Contact your local building
department for further information.
This appliance must be installed in accordance with
the accompanying installation instructions.
Self-rimming models are designed to allow the trim to
overlap the countertop when configured to the dimensions
shown on page 3/3.
Self-rimming models are not compatible with integral
backguards.
45 5/8" (115.9 cm)
28 3/16" (71.6 cm)
26 11/16" (67.8 cm)
25 11/16" (65.2 cm)
23 5/8" (60.0 cm)
23 1/8" (58.7 cm)
1 5/16" (3.3 cm) to cooking
surface (top of grates) from
bottom of trim
SELF RIMMING MODEL ER30DSR
SIDE DIMENSIONS
WITH STANDARD TRIM
ELECTRIC CIRCUIT REQUIREMENTS
Circuit Required
240 Vac, 4-wire*
60 Hz, 30 Amp.
Phone: (800) 793-0093
Revised 10/22/14 Page 1/3
GUIDE
Front of open door
Front of handle
Front edge of bullnose
Front panel
Rear of front panel /oven door
Rear of front panel to
back of chassis
35 3/4"
(90.8 cm)
to
37 7/8"
(96.2 cm)
Total Connected
Load
5.6 kW (24.2 Amp.)
