7.4.2

User card request

7.4.2.1 Record a user card
Once the lock is configured, a user card will be written. For that, two steps will be
made
POST http://localhost:8086/serialization/userSimpleCard
JSON request:
{
"lock_type":"online",
"num_installation":"2222",
"num_subinstallation":"89",
"free_locks":8,
"dedicated_locks":[1]
}
JSON response:
{
"result": "ok",
"data":
"00051111B1B2C201248400000104FFFFFF04FFFFFF04FFFFFF04FFFFFF04
FFFFFF04FFFFFF04FFFFFF04FFFFFF03065100006100000A03010800FE02A
490"
}
POST http://localhost:8086/card/write
JSON request:
http://localhost:8086/card/read/cnreader/classic
JSON response:
{
"result": "ok",
"data_online":
"00051111B1B2C201248400000104FFFFFF04FFFFFF04FFFFFF04FFFFFF04
FFFFFF04FFFFFF04FFFFFF04FFFFFF03065100006100000A03010800FE02A
490",
"uid": "26F99832"
}
7.4.2.2 User card closing allowement
A user card is approached to the lock and lock sends following JSON to the socket.
{ "uid":"94FC6B4A",
