Pin on EXT4 SAM4E pin
8 [D4] PC4
9 [D5] PC5
10 [D6] PC6
11 [D7] PC7
12 [GND] -
13 [D8] -
14 [D9] -
15 [D10] -
16 [D11] -
17 [GND] -
18 [D12] -
19 [D13] -
20 [D14] -
21 [D15] -
22 [GND] -
23 [D16] -
24 [D17] -
25 [D18] -
26 [D19] -
27 [GND] -
28 [D20] -
29 [D21] -
30 [D22] -
31 [D23] -
32 [GND] -
33 [PCLK / PE5
CMD_DATA_SEL]
34 [VSYNC / CS] PA23
35 [HSYNC / WE] PC8
36 [DATA PC11
ENABLE / RE]
37 [SPI SCK] -
38 [SPI MOSI] -
Function Shared functionality
D4 SRAM, NAND, and EBI spare header
D5 SRAM, NAND, and EBI spare header
D6 SRAM, NAND, and EBI spare header
D7 SRAM, NAND, and EBI spare header
GND
-
-
-
-
GND
-
-
-
-
GND
-
-
-
-
GND
-
-
-
-
GND
GPIO
GPIO EBI spare header
NWE SRAM and EBI spare header
NRD SRAM and EBI spare header
-
-
