  6. Installation, commissioning & operating manual

Haes Excel-EN Installation, Commissioning & Operating Manual

En54 approved 2 - 12 zone conventional control panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

EN54 APPROVED 2 - 12 ZONE CONVENTIONAL CONTROL
PANEL
Installation, Commissioning &
Operating Manual
810a/04
S o f t w a r e V e r s i o n 4 . 0 & A b o v e
Approved Document UI-XLEN-01 Issue 7.0

Advertisement

Table of Contents
loading

Related Manuals for Haes Excel-EN

Summary of Contents for Haes Excel-EN

  • Page 1 EN54 APPROVED 2 - 12 ZONE CONVENTIONAL CONTROL PANEL Installation, Commissioning & Operating Manual 810a/04 S o f t w a r e V e r s i o n 4 . 0 & A b o v e Approved Document UI-XLEN-01 Issue 7.0...
  • Page 2 0832 Haes Systems Ltd, Columbia House, Packet Boat Lane, Cowley Peachey, Uxbridge, UB8 2JP Model Number CPD Number Excel-EN 2-12 zone conventional panel XLEN-2/4/6/8/12 0832-CPD-2177 European Standard EN54-2 : 1997 + A1 : 2006 Control and indicating equipment for fi re detection and fi re alarm systems for buildings.

  • Page 3: Table Of Contents

    FUNCTIONALITY DURING A SYSTEM FAULT SERVICE & MAINTENANCE DUTIES OF THE RESPONSIBLE PERSON ROUTINE MAINTENANCE & TESTING SCHEDULE OF TESTING LOG BOOK FALSE ALARMS, FAULTS & ENGINEER VISIT LOG BOOK USER INSTRUCTIONS Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 4: About This Panel

    Quality, reliability, ease of use and feature rich are attributes that are consistent across the entire range of Haes fi re alarm control panels. The Haes Excel-EN encompasses all of these attributes to provide the fi re Haes fi re alarm control panels. The Haes Excel-EN encompasses all of these attributes to provide the fi re alarm engineer’s panel of choice.

  • Page 5: Cabinet Details

    ABOUT THIS PANEL CABINET 85mm 60mm Fire Detection System 310mm 455mm 300mm 450mm Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 6: Circuit Boards

    ABOUT THIS PANEL CIRCUIT BOARDS Excel-EN panels comprise of two main circuit boards plus optional ancillary boards TPCA01-X2/X4 - Master PCB 28V 0V FIRE FAULT SNDR1 SNDR2 ZONE1 ZONE2 ZONE3 ZONE4 + - + - C NC NO C NC NO...
  • Page 7 COMS B SW -ve OUTPUTS + - + - ADDRESS • Piggy backs on Main PCB for connection to network & repeater panels • 6 programmable switch -ve outputs Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 8: Main Pcb Terminals

    Max load 40mA Relay Coil 28V 0V FIRE FAULT SNDR1 SNDR2 ZONE1 ZONE2 ZONE3 ZONE4 + - + - C NC NO C NC NO -OP -OP -IP -IP BATTERY Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 9: Zone Card Terminals

    ZONE A ZONE B ZONE C ZONE D + - + - TWIN OPA OPB SNDR A SNDR B Switched -ve outputs Max load 40mA Relay Coil Relay Coil Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 10: Technical Specification

    Repeater Comms, fused @ 20mA Supply output Fused @ 500mA Programmable outputs 1 - 6 Switched -ve outputs Overload voltage protected to 52vdc Current limited 680R Max load = 40mA Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 11: Power Supply Module

    Battery high impedance fault (Batt Hi Z) Resistance > 1 Ohm 1 hour reporting time Max current drawn from batteries 3.15 Amps with main power source disconnected. Battery fuse 3.15A LBC 20mm. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 12: Design Considerations

    For areas where people are sleeping, sounder devices should produce a minimum 75dB(A) at the bed-head with all doors shut. In buildings providing sleeping accomodation for a signifi cant number of people, all bedrooms should have both audible and visual alarms. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 13 All system wiring should be installed to meet BS5839 Pt 1 : 2002 and BS7671 (Wiring Regulations). Other national standards of installation should be used where applicable. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 14: General Conventional Wiriing Schematic

    RESISTOR MANUAL CALL POINT MCP1A-R-470 MOTORISED BELL POLARISED MOTORISED BELL POLARISED APOLLO S65 BASE 45681-201 ELECTRONIC SOUNDER POLARISED APOLLO S65 BASE 45681-201 ELECTRONIC SOUNDER POLARISED ZONE 1 SNDR1 Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 15: General Twin Wire Wiriing Schematic

    Or switches A, B, C & D on the zone the sounders are connected in reverse polarity extension PCBs. to the detectors and call points TWIN ZONE 1 Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 16: Installation

    This equipment is not guaranteed unless the complete system is installed and commissioned in accordance with the laid down national standards by an approved and competent person or organisation. This product has been manufactured in conformance with the requirements of all applicable EU Council Directives Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 17: Esd Precautions

    Knockouts should be removed with a sharp tap at the rim of the knockout using a fl at 6mm broad bladed screwdriver. Use of excessive force will damage the enclosure around the knockout. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 18: Mains Connections

    Suffi cient earth lead should be left to allow Live and Neutral connections to be accidentally pulled from the terminal block while leaving the earth connection intact. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 19: Connecting The Batteries

    When the panel is re-charging a low battery, it should be possible to see the voltage across the batteries increase gradually. If this is not occurring, the batteries or the panel may be faulty. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 20: Setup & Programming

    The system can support up to 8 networked control panels, 1 x Master and up to 7 x Slaves. Comms PCB To run a network, a Comms PCB (TPCA05) must be fi tted to each control panel. Any Excel-EN or Excel-32 panel from 2 to 32 zones with software version 4.0 and above may be used.
  • Page 21 If replacing an older system where the existing cabling cannot be confi gured in a loop as above, it is possible to change the panel settings to legacy, radial circuit comms monitoring. See panel wide programming settings, code 2-1-2-3, option 6, (Change Network/Repeater Comms Monitoring Type). Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 22: Twin Wire Mode

    A-D on the 4 way DIL switch located on the zone card to the ‘ON’ position. Each zone can be independantly set to Twin Wire, switch A relating to zone A etc. TWIN TWIN Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 23: Zone Interface Function

    3K3Ω Example connection 470Ω ZONE2 ZONE3 ZONE4 C NC NO C NC + - + - FAULT FIRE (optional) PANEL 1 PANEL 2 Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 24: Level 3 Engineering Mode

    Pressing ENTER again will exit ‘edit’ mode back to ‘review’ mode. Some programming modes are denoted with (EN54!). Where this symbol appears EN54 compliance may be affected by this setting. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 25 Alarms’, ‘Evacuate’, ‘Class Change’, ‘Alert’ and ‘Delay’ System Diagnostics Mode Tests system PCB confi g setup for fault diagnosis 3114 Repeater Programming Repeater panel setup & programming 4443 Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 26 Amber, fault LEDs 1 - 8 indicate which repeater had a PSU fault When fi nished, enter the next programming code or disable the controls and return DIL switch 6 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 27 Lamps The panel will bleep to acknowledge the reset. When fi nished, enter the next programming code or disable the controls and return DIL switch 6 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 28 2-1-2-3. (The panel will confi rm the new access code one more time before exiting the ENTER programming mode). Disable Test Mute Test Mode Mode Buzzer Lamps Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 29 Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3. RESOUND SILENCE RESET RESOUND SILENCE RESET ENTER ENTER Disable Test Mute Test Disable Test Mute Test Mode Mode Buzzer Lamps Mode Mode Buzzer Lamps Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 30 LEDs showing the new confi guration. Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 31 COMS B SW -ve OUTPUTS + - + - + - + - + - + - ADDRESS ADDRESS ADDRESS Main Panel Repeater/Network Panel 1 Repeater/Network Panel 2 Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 32 When fi nished press the ENTER button again and the zone 9 fi re LED will return to steady ‘view mode’. Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 33 Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3. When fi nished all panel wide programming, enter the next programming code or disable the controls and return DIL switch 2 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 34 LED is OFF. Setting the amber fault LED to ON in this option will provide the Gate Valve indication feature, setting the amber fault LED to PULSING in this option will provide the Fire Pump Running functionality. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 35 Mode Mode Buzzer Lamps When fi nished all the zone function programming, enter the next programming code or disable the controls and return DIL switch 2 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 36 Zone fi re LED on, exactly the same as the valve open signal above Pump Power Supply Fault: • Zone fault LED on, exactly the same as the valve closed signal above Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 37 Press the ENTER button to return back to the zone selection, indicated by a steady zone fi re LED When fi nished all the zone function programming, enter the next programming code or disable the controls and return DIL switch 2 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 38 Note: A 220Ω ‘Evacuate’ call point can be used on such zones to provide an instant un-delayed alarm. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 39 Each push will increase or decrease the time by 1 minute. AMBER LED 1 AMBER LED 2 AMBER LED 3 AMBER LED 4 AMBER LED 5 1 Minute 2 Minutes 4 Minutes 8 Minutes 16 Minutes Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 40 The above setting is only relevant if you are using Dependency mode AND Twin Dependency mode AND Twin Wire mode Wire mode but but NOT NOT using Apollo Series 65 detectors. using Apollo Series 65 detectors. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 41 When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 42 When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 43 When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 44 When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 45 ENTER Disable Test Mute Test Enter the next programming code or disable the controls and return DIL Mode Mode Buzzer Lamps switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 46 When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 47 When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode Enter the next programming code or disable the controls and return DIL switch 3 to ‘OFF’. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 48 Press the ENTER button to return back to the output selection, indicated by a steady zone fi re LED When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 49 Press the ENTER button to return back to the sounder circuit selection, indicated by a steady zone fi re LED. When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 50 Note:- The relay and output responses to a fi re condition from their own panel are set using programming option 4-2-4-2. If a local response has been programmed, consideration should also be given to the network response which may affect it. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 51 4-3-4-2 & 3-1-2-2. If a local response has been programmed, consideration should also be given to the network response which may affect it. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 52 Press the ENTER button to return back to the output selection, indicated by a steady zone fi re LED When fi nished, press and hold Button 1 for 3 seconds to save setting and exit programming mode. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 53 Note: After power up, the system should be allowed to initialise for 2 - 3 minutes before using this code otherwise false indications could occur. If in doubt, re-enter the code a second time to check. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 54 I.e. a repeater and a network slave panel can both have address 01 on the network. ADD 05 ADD 06 ADD 07 ADD 08 Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 55 O/P 1 - 6 Inputs For Controls Disable Battery Attribute Zonal (Zones Zonal (Zones Mimic Display Common Fire PSU Fault Passive Monitoring 1 - 6) 7 - 12) Mode Default Setting Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 56: Operating

    After activation by code entry, controls will automatically deactivate again after 2 minutes and the panel will return to standby mode. The test lamps and mute buzzer functions are operational without the need to activate controls. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 57 This button is used to confi rm code entries. It can also be used for fault diagnosis (see FAULT ENTER: DIAGNOSIS section). Some buttons have other functions within the engineering facilities. These functions are described in the relevant sections. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 58: Disable Mode

    With the controls active, pressing the Disable Mode button briefl y will reveal which circuits are disabled (as opposed to in test mode). This is useful if using Disable Mode and Test Mode at the same time. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 59: Test Mode

    With the controls active, pressing the Test Mode button briefl y will reveal which circuits are in test mode (as opposed to disabled). This is useful if using Disable Mode and Test Mode at the same time. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 60: Fault Diagnosis

    Zone 1 - 4 Fault/ Zone # disabled or Disabled/Test LED in test mode (steady) Power Supply Mains failure Battery failure or Voltage fault Main PCB Fault LED (pulsing) high impedance Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 61: Functionality During A System Fault

    System Fault LED pulsing and General Fault LED pulsing along with a pulsed buzzer (fault tone) a system fault has occurred and the affected board has recovered. The indication will remain until the panel is reset. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 62: Service & Maintenance

    The result of the weekly test and the identity or location of the manual call point used should be recorded in the system log book. Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 63 Details of the service visit must be recorded in the log book EVERY FOUR YEARS Renew the sealed lead acid batteries and record the fact in the log book Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 64: Schedule Of Testing Log Book

    This Section To Be Used To Record ALL Weekly Tests Of The Fire Alarm System DDATE & DEVICE TESTED & COMMENTS INITIALS OF LOCATION (IF ANY) TESTER TIME OF TEST Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 65 This Section To Be Used To Record ALL Weekly Tests Of The Fire Alarm System DDATE & DEVICE TESTED & COMMENTS INITIALS OF LOCATION (IF ANY) TESTER TIME OF TEST Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 66 This Section To Be Used To Record ALL Weekly Tests Of The Fire Alarm System DDATE & DEVICE TESTED & COMMENTS INITIALS OF LOCATION (IF ANY) TESTER TIME OF TEST Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 67 This Section To Be Used To Record ALL Weekly Tests Of The Fire Alarm System DDATE & DEVICE TESTED & COMMENTS INITIALS OF LOCATION (IF ANY) TESTER TIME OF TEST Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 68: False Alarms, Faults & Engineer Visit Log Book

    FALSE ALARMS, FAULTS & ENGINEERS VISITS Fault/Reason For Action Taken Date Work Completed Engineer’s Details Call-Out Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 69 FALSE ALARMS, FAULTS & ENGINEERS VISITS Fault/Reason For Action Taken Date Work Completed Engineer’s Details Call-Out Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...
  • Page 70 FALSE ALARMS, FAULTS & ENGINEERS VISITS Fault/Reason For Action Taken Date Work Completed Engineer’s Details Call-Out Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0...

  • Page 71: User Instructions

    USER INSTRUCTIONS If an alarm condition is present YOU MUST FOLLOW YOUR NORMAL FIRE DRILL PROCEDURES. A responsible person should then:- 1. 1. Check the control panel to see which area or zone has caused the system to go into alarm. This Check the control panel to see which area or zone has caused the system to go into alarm.
