PROGRAMMING OPTIONS INDEX
Option/Setting
View History
Set Fault Buzzer Volume
Clear All Disablements
Initialise Factory Settings
Panel Wide Settings
Zone Function Settings
Dependancy Modes (False Alarm
Management)
EN54 Sounder Resound Options
Delays to Outputs
Input Functions
Output Programmability &
Miscellaneous
Panel Output Zonal Responses
Zone of Origin Setting
Panel Output Functional Options
Network Output Responses
Network Sounder Responses
Comms PCB Output Functional
Options
System Diagnostics Mode
Repeater Programming
Excel-EN Installation, Commissioning & Operating Manual
Description
View the last 40 events
Set the fault buzzer volume to high or low
Remove all disablements which have been set for any zone,
sounder circuit, output or delay
Restores all programming, test modes and disablements back to
factory default settings
• Change/remove keypad access code
• Set number of repeater panels on system
• Set time for panel delay timer
• Disable battery monitoring
• Setup internal PCB confi g (add/remove zone cards)
• Change network/repeater comms monitoring type
• Set number of output cards
• Inhibit muted tone beeps
• Inhibit network alarms & faults for panel
• Set number of network slave panels on system (Master Panel
only)
• Inhibit network slave panel fi re & fault buzzer
• Set zone to latching or non latching
• Set zone to old B.S (short circuit = fi re)
• Set zone for use with MTL5061 I.S. barrier
• Set zone to silent mode (provides visual & audible indication at
the panel but no sounder operation)
• Turn off priority alarm feature for zone
• Turn off detector removal monitoring for zone
• Set detector removal monitoring type for zone (Schottky or
Zener diode detector bases)
• Sprinkler/pump monitoring function
Set panel & zones to dependancy mode A, B or C
Set zones to not resound alarms after an initial fi re condition
Apply delays to outputs in response to selected zones
Change the default functions of the Class Change and Alert inputs
Set panel outputs to be programmable, switch on fault latching,
invert fault output
Set how each output and sounder circuit responds for each zone
(off, continuous or pulsing)
Quick set codes for zone of origin or zonal sounder ringing for
Twin Wire sounder circuits
Change the default panel output & sounder circuit responses to
'Silence Alarms', 'Evacuate', 'Class Change', 'Alert' and 'Delay'
Set local output & relay responses to network fi res
Set local sounder cct responses to network fi res
Change the default comms PCB o/p responses to 'Silence
Alarms', 'Evacuate', 'Class Change', 'Alert' and 'Delay'
Tests system PCB confi g setup for fault diagnosis
Repeater panel setup & programming
SETUP & PROGRAMMING
Approved Document Ref: UI-XLEN-01 Issue 7.0
23
Code(s) Page
1111 24
2224 25
1121 25
1113 25
2123 26
3121 32
2124, 2114, 2134 36
1114 39
2323 40
4141 41
4142 42
4242, 4342, 3122,
43
4243
3311, 3312 45
4244, 3123, 4344 46
4224 48
4324, 3224 49
4343 50
3114 51
4443 52
