SPX FLOW Universal 3 Series Instruction Manual page 105

Waukesha Cherry-Burrell
ITEM NO.
27
Shim Kit
29
Spacer, Gear to Rear Bearing
30
Bearing Spacer
32
Bearing Retainer, Front
33A
1/4-20 x 3/4" HHCS, Gear Case Cover
33B
1/4-20 x 3/4" HHCS, SS Bearing Retainer
33C
1/4" Flat Washer
34
Dowel Bushing, Upper
35
Dowel Bushing, Lower
006-015-018-U3 Cover Gasket, FKM
36 006-015-018-U3 Cover Gasket, FFKM
*
006-015-018-U3 Cover Gasket, EPDM
39
Lock washer, Gear
41
Locknut, Gear
42
Mounting Foot 006-015-018-U3 SS
43
Plastic Cap Plug
44
5/16-18 x 1" SHCS, SS
006-U3 Body Retaining Screw
45
015-U3 Body Retaining Screw
018-U3 Body Retaining Screw
46
Eye Bolt, 5/16-18 x 1/2" SS
Key, Coupling - 3/16 x 3/16 x 1-1/8"
47
Key, Coupling - Tru-Fit
48
Cleanout Plug, SS
56
006-015-018-U3 Seal Guard
61
Name Plate, Sanitary
62
#2 x .187" RHDS
65
Caution Plate
66
Warning Label
67
Grease Fitting, 1/8"
68
Plastic Cap, Grease Fitting
Notes:
* Recommended spare parts
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 127.
3. See "Replacement Labels" on page 12 for label detail.
11/2018
®
Brand Universal 3 Pump
006, 015, 018-U3 Parts
DESCRIPTION
95-03103
QTY.
PER PART NO. NOTES
PUMP
2 117889+
2 015055000+
2 101814+
2 120332+
6 30-58
8 30-58
6 43-27
1 AD0116000
1 AD0116100
1 137422+
1 137423+
1 137424+
2 STD136005
2 STD236005
1 102284+
6 000121003+
4 30-525
2 30-211
2 30-543
2 30-613
2 30-719
1 000037001+
1 119714+
2 102298+
2 138896+
1 135623+
4 30-355
2 121694+
2 33-63
4 LL118404
4 BD0093000
PL5060-CH153
Parts List
Page 105
