Digi XBee3-PRO Hardware Reference Manual page 30

XBee3 RF module
The following table shows the antennas approved for use with the XBee3 RF module.
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
Type
(description)
Part number
Integral antennas
29000313 Integral PCB antenna (surface-mount only)
29000710 Chip antenna (micro only)
Dipole antennas
A24-HASM- Dipole (Half-wave articulated RPSMA - 4.5")
450
A24-HABSM* Dipole (Articulated RPSMA)
29000095 Dipole (Half-wave articulated RPSMA - 4.5")
A24-HABUF- Dipole (Half-wave articulated bulkhead mount
P5I U.FL. w/ 5" pigtail)
A24-HASM- Dipole (Half-wave articulated RPSMA - 5.25")
525
Omni-directional antennas
A24-F2NF Omni-directional (Fiberglass base station)
A24-F3NF Omni-directional (Fiberglass base station)
A24-F5NF Omni-directional (Fiberglass base station)
A24-F8NF Omni-directional (Fiberglass base station)
Gain
(dBi) Application* Min. separation
0.0 Fixed/Mobile 20 cm
0.0 Fixed/Mobile 20 cm
2.1 Fixed 20 cm
2.1 Fixed 20 cm
2.1 Fixed/Mobile 20 cm
2.1 Fixed/Mobile 20 cm
2.1 Fixed 20 cm
2.1 Fixed/Mobile 20 cm
3.0 Fixed/Mobile 20 cm
5.0 Fixed 20 cm
8.0 Fixed 2 m
Required antenna cable loss (dB)
802.15.4 Based BLE (when
Protocols (Ex: ZigBee) available)
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
